₱258.00
| Category | Specification |
|---|---|
| Range of Product | AvatarOn A |
| Product / Component Type | Socket-outlet |
| Device Presentation | Complete product |
| Colour Tint | Grey |
| Outlet Poles Configuration | 2 × 2P |
| Rated Current | 16 A at 250 V AC, 50…60 Hz |
| Socket Number | 2 |
| Clamping Connection Capacity | 2 × 1.5…4 mm² (solid cables); 2 × 1.5…4 mm² (stranded cables) |
| Connections – Terminals | Screwless terminals |
| Material | Polycarbonate grid plate; Polycarbonate cover |
| Device Mounting | Flush |
| Width | 120 mm |
| Height | 70 mm |
| Depth | 36.35 mm |
| Embedding Depth | 24.85 mm |
| IP Degree of Protection | IP20 |
| Maximum Ambient Temperature (Operation) | 35 °C |
| Ambient Temperature (Storage) | −5…45 °C |
| Relative Humidity | 0…95 % |
| Operating Altitude | < 2000 m |
| Standards | IEC 60884-1 |
| Product Certifications | IEC |
| Package | Unit Type | Units per Package | Height | Width | Length | Weight |
|---|---|---|---|---|---|---|
| Package 1 | PCE | 1 | 3.65 cm | 7 cm | 12 cm | 140 g |
| Package 2 | BB1 | 10 | 8.8 cm | 18.5 cm | 26.5 cm | 1.506 kg |
| Package 3 | S03 | 60 | 30 cm | 30 cm | 40 cm | 9.686 kg |
₱258.00
Estimated delivery between March 16 and March 18.
Delivery Information
Metro Manila: 2–3 days | Provincial: 3–7 days
Main Office Branch only
Same Day Delivery
Same-Day Delivery Available
Processing starts 1–2 hours after checkout Mon–Sat | Main Office Branch only
Processing only during office hours from Main Office 9am - 5pm
₱258.00
₱258.00
Authorized Seller
100% Original Authentic Product
| Category | Specification |
|---|---|
| Range of Product | AvatarOn A |
| Product / Component Type | Socket-outlet |
| Device Presentation | Complete product |
| Colour Tint | Grey |
| Outlet Poles Configuration | 2 × 2P |
| Rated Current | 16 A at 250 V AC, 50…60 Hz |
| Socket Number | 2 |
| Clamping Connection Capacity | 2 × 1.5…4 mm² (solid cables); 2 × 1.5…4 mm² (stranded cables) |
| Connections – Terminals | Screwless terminals |
| Material | Polycarbonate grid plate; Polycarbonate cover |
| Device Mounting | Flush |
| Width | 120 mm |
| Height | 70 mm |
| Depth | 36.35 mm |
| Embedding Depth | 24.85 mm |
| IP Degree of Protection | IP20 |
| Maximum Ambient Temperature (Operation) | 35 °C |
| Ambient Temperature (Storage) | −5…45 °C |
| Relative Humidity | 0…95 % |
| Operating Altitude | < 2000 m |
| Standards | IEC 60884-1 |
| Product Certifications | IEC |
| Package | Unit Type | Units per Package | Height | Width | Length | Weight |
|---|---|---|---|---|---|---|
| Package 1 | PCE | 1 | 3.65 cm | 7 cm | 12 cm | 140 g |
| Package 2 | BB1 | 10 | 8.8 cm | 18.5 cm | 26.5 cm | 1.506 kg |
| Package 3 | S03 | 60 | 30 cm | 30 cm | 40 cm | 9.686 kg |
Authencity Guaranteed
We only sell authentic products from verified brand partners and retail partners globally.
