Product naming
Model name
HP Smart Tank 580 All-in-One Printer
Product number
1F3Y2A
What's included and accessories
Accessories
None
Connectivity
Ports
1 Hi-Speed USB 2.0 (device); 1 Bluetooth Low Energy; 1 Wi-Fi 802.11b/g/n; 1 Wi-Fi Direct
Wireless capability
Yes, built-in Wi-Fi 2.4G, Wi-Fi Direct, Bluetooth Low Energy
Storage device and direct print support
Wireless Direct Printing
Copy
Copier settings
Number of Copies, Resize, Quality, Lighter/Darker, Papersize, Papertype, ID Copy, Enhancement
Color copy capability
Yes
Maximum number of copies
Up to 99 copies
Copy reduce / enlarge settings
Via HP Smart app
Copy resolution
Up to 1200 dpi
Environmental
Acoustic power emissions (active, printing)
6.4 B(A)
Acoustic pressure emissions
56.8 dBA (printing at 9ppm)
Recommended operating humidity range
20 to 80% RH
Non-Operating Humidity Range
5 to 90% RH (non-condensing)
Recommended operating temperature range (Celsius)
15 to 30°C
Recommended operating temperature range (Fahrenheit)
59 to 86°F
Storage temperature range (Celsius)
-40 to 60°C
Storage temperature range (Fahrenheit)
-40 to 140°F
Environmental specifications
45% post-consumer recycled plastic; EPEAT® registered
Memory
Memory
64 MB Integrated DDR1
Maximum Memory
64MB
Mobile printing capability
Mobile printing
services
HP Smart app; Apple AirPrint; Mopria Print Service; HP Print Service Plugin (Android printing); Wi-Fi Direct Printing
Paper handling
Input capacity
Up to 100 sheets
Standard input capacity (cards)
Up to 30 cards
Standard input capacity (envelopes)
Up to 10
Output capacity
Up to 30 sheets
Media sizes supported (metric)
A4; B5; A6; DL envelope, legal
Media sizes supported (U.S. standard)
Letter; legal; 4 x 6 in; 5 x 7 in; 8 x 10 in; No. 10 envelopes
Media sizes, custom (metric)
88.9 x 127 to 215.9 x 355.6 mm
Media sizes, custom (U.S. standard)
3.5 x 5 in to 8.5 x 14 in
Media types
Plain paper, Matte Brochure Papers, Glossy Brochure Papers, Photo papers, Envelopes, Other specialty inkjet papers
Media weight supported (metric)
Plain paper: 60 to 90 g/m²; Envelopes: 75 to 90 g/m²; Cards: up to 200 g/m²; Photo paper: up to 300 g/m²
Media weight supported (U.S. standard)
20 lb
Borderless printing
Yes (up to 8.5 x 11 in, 210 x 297 mm)
Paper handling - duplexer
Media sizes, duplex (U.S. standard)
Letter; Executive
Physical dimensions
Maximum dimensions (W x D x H, metric)
434.66 x 580.65 x 259.37 mm
Maximum dimensions (W x D x H, U.S. standard)
17.11 x 22.86 x 10.21 in
Weight (metric)
5.03 kg
Weight (U.S. standard)
11.09 lb
Power
Energy savings feature technology
HP Auto-Off Technology
Power supply type
Internal built in
Power supply
Input voltage 100 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3 Hz). High voltage: Input voltage 200 to 240 VAC (+/- 10%), 50/60 Hz (+/- 3Hz)
Power consumption
0.109 watts (manual-Off), 3.023 watts (ready), 1.096 watt (sleep)
Print cartridges
Number of print cartridges
4 (1 each black bottle, set of 3 color bottles)
Replacement cartridges
North America: HP GT53 90-ml Black Original Ink Bottle 1VV22AA; HP GT53XL 135-ml Black Original Ink Bottle 1VV21AA; HP GT52 Cyan Original Ink Bottle M0H54AA; HP GT52 Magenta Original Ink Bottle M0H55AA; HP GT52 Yellow Original Ink Bottle M0H56AA; Europe Middle East and Africa: HP GT53XL 135-ml Black Original Ink Bottle 1VV21AE; HP GT52 Cyan Original Ink Bottle M0H54AE; HP GT52 Magenta Original Ink Bottle M0H55AE; HP GT52 Yellow Original Ink Bottle M0H56AE; Asia Pacific: HP GT53 90-ml Black Original Ink Bottle 1VV22AA; HP GT53XL 135-ml Black Original Ink Bottle 1VV21AA; HP GT52 Cyan Original Ink Bottle M0H54AA; HP GT52 Magenta Original Ink Bottle M0H55AA; HP GT52 Yellow Original Ink Bottle M0H56AA; Latin America: HP GT53 90-ml Black Original Ink Bottle 1VV22AL; HP GT52 Cyan Original Ink Bottle M0H54AL; HP GT52 Magenta Original Ink Bottle M0H55AL; HP GT52 Yellow Original Ink Bottle M0H56AL; HP GT52 3-pack Cyan/Magenta/Yellow Original Ink Bottles X4E44AL. For more information about fill and yield, see http://www.hp.com/go/learnaboutsupplies .
Replacement cartridges footnote
Black and composite color average per bottle (cyan/magenta/yellow) results based on HP methodology from the simulation of continuous printing of ISO/IEC 24712 test pages. Not based on ISO/IEC 24711 test process. An additional black ink bottle is required to print 8,000 color test pages. Actual yield varies based on content of printed pages and other factors. Some ink from included bottles is used to start up the printer. For more information about fill and yield, see http://www.hp.com/go/learnaboutsupplies.
Printing specifications
Print technology
HP Thermal Inkjet
Duplex printing
Manual (driver support provided)
Print speed black (ISO)
Up to 12 ppm
Print speed color (ISO)
Up to 5 ppm
Print resolution (best)
Up to 1200 x 1200 rendered dpi
Maximum print area (metric)
216 x 355 mm
Monthly duty cycle
Up to 3,000 pages
Print languages
HP PCL 3 GUI; HP PCLm (HP Apps/UPD); URF (AirPrint)
Regulatory specifications
Regulatory model number
SNPRC-2201-01
Safety
IEC 60950-1 & IEC62368-1 compliant; EU RED and EN 60950-1 & EN 62368-1 compliant; Singapore Safety; China CCC; Taiwan BSMI
Electromagnetic compatibility
EN 55032:2015+A11:2020 Class B; EN 55024:2010 +A1:2015; EN 55035:2017+A11:2020; EN IEC 61000-3-2:2019; EN 61000-3-2:2014; EN 61000-3-3:2013 +A1:2019; EN 301 489-1 V2.2.3; EN 301 489-17 V3.2.4
Telecom compliance (fax capability)
EN 300 328 V2.2.2; EN 301 893 V2.1.1; EN 300 440 V2.1.1
Scan
Scan technology
Contact Image Sensor (CIS)
Scan resolution, hardware
Up to 1200 x 1200 dpi
Levels of grayscale
256
Bit depth
24-bit
Scanning options (ADF)
Not Applicable
Maximum flatbed scan size (metric)
216 x 297 mm
Maximum flatbed scan size (U.S. standard)
8.5 x 11.69 in
Twain version
Version 2.4
Security
Security management
No
System requirements
Minimum system requirements for Windows
Microsoft® Windows® 11, 10, 7 SP1: 32-bit or 64-bit, Internet connection, Microsoft® Internet Explorer or Edge.
Recommended system requirements for Windows
Microsoft® Windows® 11, 10, 7 SP1: 32-bit or 64-bit, Internet connection, Microsoft® Internet Explorer or Edge.
Minimum System Requirements for Macintosh
Apple® macOS v10.15 Catalina, macOS v11 Big Sur, macOS v12 Monterey; 2 GB HD; Internet required
Recommended Macintosh system requirements
Apple® macOS v10.15 Catalina, macOS v11 Big Sur, macOS v12 Monterey; 2 GB HD; Internet required
Operating system (supported note)
Microsoft Windows 11, 10, 7 SP1: 32-bit or 64-bit; macOS v10.15 Catalina, macOS v11 Big Sur, macOS v12 Monterey;
Warranty
Manufacturer Warranty
One-year or 30,000 pages limited hardware warranty, whichever is earlier from the date of purchase. For more info please visit us at http://support.hp.com
SPECIFICATION
On-demand piezo-electric inkjet with Micro Piezo™ printheads.
Print Resolution:
Up to 5760 x 1440 dpi.
Print Speed (ISO/IEC 24734):
10 ipm (monochrome), 5 ipm (colour).
Draft Print Speed:
Up to 33 ppm (monochrome), 15 ppm (colour).
Ink System:
Integrated ink tank system for high yields and spill-free refills.
Connectivity:
L1210: USB 2.0.
L1250: Wi-Fi and Wi-Fi Direct.
Borderless Printing:
Available for 4R photos.
Paper Handling:
Input Capacity: Up to 100 sheets of plain paper.
Output Capacity: Up to 30 sheets of plain paper.
Power:
Epson Heat-Free Technology for lower power consumption.
Mobile Printing:
The L1250 supports mobile printing via the Epson Smart Panel app.
Model Comparison
Epson EcoTank L1210:
A more basic model with USB 2.0 connectivity.
Epson EcoTank L1250:
Includes all features of the
L1210 plus integrated Wi-Fi and Wi-Fi Direct for wireless printing from smart devices.
SPECIFICATION
Print Speed:
Up to 8.8 ipm (monochrome) and 5.0 ipm (color), based on ISO standards.
Resolution:
4800 (horizontal) x 1200 (vertical) dpi.
Ink System:
Uses GI-790 ink bottles with a Pigment Black and Dye-Based Cyan, Magenta, Yellow system.
Wireless Printing:
Supports IEEE 802.11b/g/n network connectivity.
Mobile Printing:
Compatible with the Canon PRINT Inkjet/
SELPHY application for direct printing from smartphones and tablets.
Scanning
Scanner Type:
Flatbed scanner using a Contact Image Sensor (CIS).
Optical Resolution:
600 x 1200 dpi.
Scanning Speed:
Approximately 19 seconds for A4 color at 300 dpi.
Maximum Document Size:
Supports up to A4 / Letter.
Copying
Copy Speed:
Up to 3.5 ipm (color).
Maximum Copies:
Can produce up to 20 copies.
Maximum Document Size:
Supports A4 and Letter sizes.
Other Specifications
Dimensions:
445 x 330 x 163 mm (W x D x H).
Weight:
Approximately 6.3 kg.
Connectivity:
USB 2.0 interface and Wireless network.
Design:
Features a spill-resistant ink bottle design for convenient ink refilling.
BOOST YOUR PRODUCTIVITY with DCP-L2640DW
Enjoy top-class print speeds, enhanced mobile connectivity and cost-saving innovations with DCP-L2640DW monochrome laser printers.
A4 print speed up to 34 ppm (Black)
WiFi, AirPrint, Mopria, WiFi Direct, LAN, USB 2.0
Auto 2-sided (Duplex) printing, 50 sheets Auto-Document Feeder (ADF), 2-line LCD
Full capacity toner included. Yield up to 1200 pages (black)*
Compatible with Mobile Connect app
SPECIFICATIONS
Basic Specifications
Functions
Print, Scan Copy
Printer type
Laser Printer
Product Dimensions
410 mm × 399 mm × 319 mm
Weight
10.3 kg
Print Speed
Up to 34 (A4) / Up to 36 (Letter) ppm
Paper Type
Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond, Label, Envelope, Env.Thin, Env.Thick
Paper Size
A4, Letter, B5 (JIS), B5 (ISO), A5, A5 (Long Edge), B6 (JIS), A6, Executive, 16K (195x270 mm), A4 Short (270mm Paper), COM-10, DL, C5, Monarch
Maximum paper capacity
Up to 250 sheets of 80 gsm plain paper
Print
Resolution
Up to 1200 x 1200 dpi
2-Sided (Duplex) - Printing Paper Type
Plain Paper, Thin Paper, Recycled Paper
2-Sided (Duplex) - Paper Size
Letter, Legal, Folio, Mexico Legal, India Legal (For Philippines) / a4 (Except for Philippines)
Paper Handling
Tray #1- Maximum Paper Capacity
Up to 250 sheets of 80 gsm plain paper
Manual Feed Slot- Maximum Paper Capacity
1 sheet
Manual Feed Slot- Maximum Paper Weight Capacity
60 to 230 gsm (16 to 61 lb)
image CLASS LBP6030
Great performance with a small footprint
Compact and efficient, the LBP6030 is designed to help save space and perform high-speed print jobs, with low energy consumption.
Print
Print Speed (A4): Up to 18 ppm
Recommended Monthly Print Volume: 200 - 800 pages
Sleep Mode and Auto Shutdown Feature
SPECIFICATIONS
Print
Printing Method
Monochrome Laser Beam Printing
Print Speed
A4:
Up to 18ppm
Letter:
Up to 19ppm
Print Resolution
600 x 600dpi
Print Quality with Image Refinement Quality
2400 (equivalent) × 600dpi
Warm-Up Time(From Power On)
10secs. or less
First Printout Time (FPOT)
Approx. 7.8secs.
Recovery Time(From Sleep Mode)
Approx. 1secs.
Print Language
UFR II LT
Paper Handling
Paper Input (Standard)
150 sheets (based on 80g/m2)
Paper Output
100 sheets (face down)(based on 80g/m2)
Paper Size
A4, B5, A5, Legal*1, Letter, Executive, 16K, Envelope COM10, Envelope Monarch, Envelope C5, Envelope DLCustom: Width 76.2 to 216 x Length 188 x 356mm
Paper Weight
60 to 163g/m2
Paper Type
Plain paper, Heavy Paper, Transparency, Label, Envelope.
Connectivity and Software
USB Interface
USB 2.0 High Speed
Compatible Operating Systems*2
Win 8.1 (32 / 64bit), Windows 7 (32 / 64-bit), Windows Server 2012 (32 / 64bit), Windows Server 2012 R2 (64 bit), Windows Server 2008 (32 / 64-bit), Windows Server 2008 R2 (64-bit),Mac OS 10.7.x-10.9 *3, Linux*3, Citrix
General Specification
Operation Panel
2 LED Indicators, 2 Operation Key
Device Memory
32MB
Dimensions (W x D x H)
364 x 249 x 199mm
Weight
Approx. 5.0kg (Without Cartridge)
Noise Level*4
During Operation:
Sound Power Level:
6.53B or less
Sound Pressure Level:
Approx. 49.3dB
During Standby:
Sound Power Level:
Inaudible*5
Sound Pressure Level:
Inaudible*5
Maximum Power Consumption
870W
Average Power Consumption
During Operation:
Approx. 330W
During Standby:
Approx. 1.8W
During Sleep:
Approx. 0.8W
Energy Star TEC(Typical Electricity Consumption)
0.47kWh/week
Operating Environment
Temperature:
10~30°C
Humidity:
20% to 80% RH (no condensation)
Power Requirement
220 - 240V (±10%), 50 / 60Hz (±2Hz)
Toner Cartridge*6
Cartridge 325:
1,600 pages(Bundled Cartridge: 700 pages)
Monthly Duty Cycle*7
Up to 5,000 pages
Recommended Monthly Print Volume
200 - 800 pages
Specifications
Print Speed:
25 ISO ppm (black and color)
Duplex Print Speed:
16 ISO ppm (black and color)
Maximum Print Resolution:
4800 x 1200 optimized dpi
Print Technology:
PrecisionCore Heat-Free technology 4S
Scanner Type:
A4 flatbed with automatic duplex color scanning
Fax:
Color and monochrome support with a 550-page memory
Monthly Duty Cycle:
Up to 70,000 pages (maximum), with a recommended volume of 5,000 pages
Paper Handling:
Supports multiple sizes up to 8.5 x 236.2 inches (215.9 x 6000 mm)
Connectivity & Mobile Solutions
Network:
Ethernet and Wi-Fi
Direct Connectivity:
Wi-Fi Direct
USB:
USB 2.0
Mobile & Cloud:
Epson Connect features
(Smart Panel, Email Print), Apple AirPrint, Mopria Print Service, and Microsoft Universal Print
Physical Details
Dimensions:
Approximately 42.5 x 53.5 x 35.7 cm (W x D x H)
Weight:
18.7 kg
IMPROVE YOUR PRODUCTIVITY WITH OUR ALL-PURPOSE WORKFORCE SCANNERS
Focus on work that matters with the high-speed and all-purpose Epson WorkForce DS-530II scanner. Designed to handle a wide variety of media, you will be able to scan media printed on different mediums from fragile paper documents to plastic cards, and even thick books with its flatbed option.
Scanning speed of up to 35 ppm / 70 ipm
Automatic Document Feeder (ADF) of up to 50 sheets
Daily duty cycle of up to 5,500 sheets
One-pass duplex scanning
Paper protection function and image sensor glass dirt detection
Power:
Rated Voltage:AC 100 - 240 VRated Frequency:50 - 60 HzPower Consumption:Operating: 11WReady Mode: 5.4WSleep Mode: 1.0WPower Off: 0.1W
Supported OS and Applications:
Supported OS:Windows XP / Vista / 7 / 8 / 8.1 / 10 / Server 2003 / Server 2008 / Server 2012 / Server 2016Mac OS X 10.6.8 or laterScanner Driver Compatibility:TWAIN, SANE, WIA, ICA, ISISBundled Applications:Epson Scan 2, ISIS Driver (Web Download), Epson Scan OCR Component, Epson Scan PDF Extensions, Document Capture Pro (Win), Document Capture (Mac)
Scanning:
Scanner Type:A4 sheet-fed, one-pass duplex colour scannerSensor Type:Colour Contact Image SensorScanning Method:Fixed carriage and moving documentLight Source:RGB LEDOptical Resolution:600 x 600 dpiOutput Resolution:50 - 1,200 dpi (1 dpi increments)Bit Depth:Each colour (RGB): 10 bit input / 8 bit outputMin Document Size:50.8 x 50.8 mmMax Document Size:215.9 x 6096 mmSupported Paper Weight:27 - 413 g/m2 (A8 or less 127 - 413 g/m2)Output File Formats:Epson Scan 2: JPEG, TIFF, Multi-TIFF, PDF, Searchable PDF, BMP, PNGDocument Capture Pro (Win): JPEG, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTXADF Capacity:50 sheets (80g/m2)Daily Scan Volume:Up to 5,500 sheets / dayMulti-feed Detection:Ultrasonic Sensor and Length Detection
Scan Speed:
Resolution (Colour/Greyscale/Mono):200 dpi: 35 ppm / 70 ipm*2300 dpi: 35 ppm / 70 ipm*2600 dpi: 12 ppm / 24 ipm*2
Dimensions and Weight:
Dimensions (W x D x H):296 x 169 x 176 mm
Weight:3.7 kg
Options:
Options:Flatbed Dock - B12B819011Roller Assembly Kit: 200,000 scans - B12B819671Carrier Sheet - B12B819051Cleaning Kit - B12B819291
Environmental Conditions:
Temperature:Operating:5 - 35°CStorage: -25 - 60°CHumidity:Operating: 15 - 80% (No condensation)Storage: 15 - 85% (No condensation)
PIXMA G2010
Refillable Ink Tank All-In-One for High Volume Printing
Designed for high volume printing at low running cost
Print, Scan, Copy
Print Speed (A4, ISO): up to 8.8 / 5 ipm (mono/color)
USB 2.0
Recommended Monthly Print Volume: 150 - 1500 pages
High Page Yield Ink Bottles
With high page yield ink bottles up to 7,000* pages, users can enjoy printing without having to worry about cost of ink, or ink supplies running low.
Integrated Ink Tank System
Built-in integrated ink tanks create a compact printer body. Users can also view remaining ink levels easily at a glance.
Spill-Resistant Ink Bottle Design
The ink bottles come with a special tip design that reduces spillage during ink refilling.
SPECIFICATIONS
Operation Panel
Display
1.2" LCD Segment Mono
Interface
USB 2.0
Operating Environment*8
Temperature
5 - 35°C
Humidity
10 - 90% RH (no dew condensation)
Recommended Environment*9
Temperature
15 - 30°C
Humidity
10 - 80% RH (no dew condensation)
Storage Environment
Temperature
0 - 40°C
Humidity
5 - 95% RH (no dew condensation)
Quiet Mode
Available
Acoustic Noise*10
Plain Paper (A4, Mono)
53.5 dB(A)
Power Requirements
AC 100 - 240 V, 50/60 Hz
Power Consumption (Approx.)
OFF
0.2 W
Standby
0.6 W
Operation*11
9 W
Dimensions (W x D x H)
Factory Configuration
445 x 330 x 163 mm
Output Trays Extended
445 x 533 x 260 mm
Weight
6.3 kg
Page Yield
Plain Paper
A4 Colour Documents*13:
GI-790 PGBK: 6,000
GI-790 C, M, Y: 7,000
Photo Paper (PP-201)
4 x 6" Photos:
GI-790 PGBK: NA*14
GI-790 C, M, Y: 2,000
Fast Quality Printing Made Affordable.
Expect great efficiency when printing with the Eco Tank L121. Enjoy fast print performance and low cost per page, with high print yield of up to 4,500 pages for black-and-white, and 7,500 pages for color. Sleek and compact, this is the perfect fit for offices with limited space. Experience quality printing that is priced reasonably. Get this ideal printing solution for your home office today.
Print speed of up to 9.0 ipm (black) and 4.8 ipm (color)
Ultra-high page yield of 4,500 pages (black) and 7,500 pages (color)
Powered by Epson Heat-Free Technology
Epson Heat-Free Technology
Achieve high speed printing at low power consumption with Epson Heat-Free Technology as no heat is required during the ink ejection process.
Impressive Print Speed
Constantly improving to meet the printing needs of small business owners, Eco Tank L121 features printing speeds of up to 9.0 ipm for black-and-white, and 4.8 ipm for color to deliver reliable work productivity.
Superb Savings & Page Yield
Don’t compromise on cost as you print. With Eco Tank L121, you’ll be able to save costs as each set of bottle inks has an ultra-high yield of 4,500 for black and 7,500 pages for color.
Quality That Shines. Value That Lasts.
Epson genuine ink bottles are formulated to deliver outstanding high-volume print quality with Eco Tank printers. Every bottle is individually sealed to ensure the purity of ink and comes with a smart tip designed for mess-free refills. Choose Epson genuine ink bottles to enjoy lasting quality with your printer and low printing costs.
SPECIFICATIONS
Printer Type:
Print
ISO 24734, A4 Simplex (Black / Color):
Up to 9.0 ipm / 4.8 ipm
Paper Feed Method:
Friction Feed
Maximum Paper Size:
8.5 x 44"
Paper Sizes:
A4, Letter, Legal (8.5 x 14")
Print Margin
3 mm top, left, right, bottom via custom settings in printer driver
PC Printing / Plain Paper Default:
6.0 B(A), 47 dB(A)
Weight:
2.4 kg
Dimensions (W x D x H):
461 x 215 x 130 mm
Black Ink Bottle:
4,500 Pages
Cyan Ink Bottle:
7,500 Pages (Composite Yield)
Printing Technology:
Piezoelectric Printhead
Nozzle Configuration:
180 x 1 nozzles Black, 59 x 1 nozzles per Colour (Cyan, Magenta, Yellow)
Print Direction:
Bi-directional, Uni-directional printing
Maximum Print Resolution:
720 x 720 dpi
Minimum Ink Droplet Size:
3.0 pl
Automatic 2-sided Printing:
No
Printer Language:
ESC/P Raster
USB:
USB 2.0
Standby:
Approx. 2.0 W
Sleep:
Approx. 6.0 W
Power Off:
Approx. 0.3 W
Operating System Compatibility:
Windows XP / XP Professional / Vista / 7 / 8 / 8.1 / 10
Windows Server 2003 / 2008 / 2008 (R2) / 2012
Mac OS X 10.5.8 or later
STYLISH DESIGN, QUALITY PRINTS
Robust and reliable. This Eco Tank L6460 is compact in size, the printers fit into any given space in your office. Enjoy hassle-free, auto-duplex printing that lowers printing cost; and face down output for better security. DURABrite ET Ink uses pigment-based ink to deliver durable, water-resistant and extra-sharp print. You can also download the Epson Smart Panel app and transform your mobile devices into an intuitive control centre to set up, monitor and operate the printers. Improve business efficiency with enhanced print performance from this stylish printing solution today.
Print, scan, copy with ADF
Print speeds up to 17ipm for black and 9.5ipm for color
Auto-Duplex printing
Wi-Fi & Wi-Fi Direct
Powered by Epson Heat-Free Technology
SPECIFICATIONS
Print Method:
Printhead
Printer Language:
/P-R, ESC/P Raster
Nozzle Configuration:
400 x 1 nozzles (Black)
128 x 1 nozzles per Color (Cyan, Magenta, Yellow)
Maximum Resolution:
4800 x 1200 dpi
Automatic 2-sided Printing:
Yes
PRINT SPEED
Draft, A4 (Black / Colour):
Up to 37.0 ppm / 23.0 ppm*2
ISO 24734, A4 Simplex (Black / Color):
Up to 17.0 ipm / 9.5 ipm*2
ISO 24734, A4 Duplex (Black / Colour):
Up to 17.0 ipm / 9.5 ipm*2
First Page Out Time from Ready Mode (Black / Colour):
Up to 7.0 sec / 11.0 sec*2
HP Smart Tank 520 3 in 1 Printer PN# 1F3W2A
Specifications
FunctionsPrint, copy, scan
Print ColoursYes
Print TechnologyHP Thermal Inkjet
Duplex PrintingManual (driver support provided)
Wireless CapabilityNo
Recommended Monthly Page Volume400 to 800
Product InfoSku1F3W2A
Product Types
Inkjet printersSeriesSmart tank
Perfect ForHome
FunctionsPrint scan and copy
Printer Specifications
FunctionsPrint scan and copy
Duty Cycle (Monthly, Letter)Up to 3,000 pages
Duty Cycle (Monthly, A4)Up to 3,000 pages
Recommended Monthly Page Volume400 to 800
Target User And Print VolumeFor teams up to 3 users; Prints up to 800 pages/month
Paper Trays, Standard1
Paper Trays, Maximum1
Print ColoursYes
Top Key FeaturesHigh-volume printer tank; Scan to PDF
Print TechnologyHP Thermal Inkjet
Envelope FeederNo
Duplex PrintingManual (driver support provided)
Automatic Paper SensorNo
Vertical Alignment Accuracy+/- 0.02 mm
Print Speed
Print Speed Black (ISO)Up to 12 ppm
Print Speed Color (ISO)Up to 5 ppm
Print Speed Black (Draft, A4)Up to 22 ppm
Print Speed Color (ISO)Up to 5 ppm
Print SpeedPrint speed up to 12 ppm (black) and 5 ppm (color)
Connectivity And Communications
Wireless CapabilityNo
Connectivity, Standard1 Hi-Speed USB 2.0 (device)
Cartridges And Printheads
Number Of Print Cartridges4 (1 each black bottle, set of 3 color bottles)
Ink TypesPigment-based (black); Dye-based (color)
Color(S) Of Printing SuppliesBlack; Cyan; Magenta; Yellow
Print Colors Maximum4
Replacement CartridgesNorth America: HP GT53 90-ml Black Original Ink Bottle 1VV22AA; HP GT53XL 135-ml Black Original Ink Bottle 1VV21AA; HP GT52 Cyan Original Ink Bottle M0H54AA; HP GT52 Magenta Original Ink Bottle M0H55AA; HP GT52 Yellow Original Ink Bottle M0H56AA; Europe Middle East and Africa: HP GT53XL 135-ml Black Original Ink Bottle 1VV21AE; HP GT52 Cyan Original Ink Bottle M0H54AE; HP GT52 Magenta Original Ink Bottle M0H55AE; HP GT52 Yellow Original Ink Bottle M0H56AE; Asia Pacific: HP GT53 90-ml Black Original Ink Bottle 1VV22AA; HP GT53XL 135-ml Black Original Ink Bottle 1VV21AA; HP GT52 Cyan Original Ink Bottle M0H54AA; HP GT52 Magenta Original Ink Bottle M0H55AA; HP GT52 Yellow Original Ink Bottle M0H56AA; Latin America: HP GT53 90-ml Black Original Ink Bottle 1VV22AL; HP GT52 Cyan Original Ink Bottle M0H54AL; HP GT52 Magenta Original Ink Bottle M0H55AL; HP GT52 Yellow Original Ink Bottle M0H56AL; HP GT52 3-pack Cyan/Magenta/Yellow Original Ink Bottles X4E44AL. For more information about fill and yield, see http://www.hp.com/go/learnaboutsupplies .
Print Head Nozzles704 (Black), 588 (Tri-color)
Print Heads2 (1 each black, tri-color)
Number Of Print Cartridges4 (1 each black bottle, set of 3 color bottles)
Ink TypesPigment-based (black); Dye-based (color)
Camera Specifications
Print Head Nozzles704 (Black), 588 (Tri-color)
Print Heads2 (1 each black, tri-color)
Printing Media Handling
Maximum Input Capacity (4x6 Photo)Up to 30 sheets
Maximum Input Capacity (Photo Paper)Up to 30 sheets
Maximum Input Capacity (Sheets)Up to 100 sheets
Maximum Input Capacity (Cards)Up to 30 cards
Input CapacityUp to 100 sheets
Standard Input Capacity (Cards)Up to 30 cards
Finished Output HandlingSheetfed
Maximum Output Capacity (Photo Paper)Upto 30 sheets
Maximum Output Capacity (Envelopes)Up to 10 envelopes
Maximum Output Capacity (Sheets)Up to 30 sheets
Output CapacityUp to 30 sheets
Standard Output Capacity (Envelopes)Up to 10 envelopes
Standard Output Capacity (Legal)Up to 30 sheets
Paper Handling Input, Standard100-sheet input tray
Paper Handling Output, Standard30-sheet output tray
Print Area
Top Margin (A4)3 mm
Left Margin (A4)3 mm
Right Margin (A4)3 mm
Bottom Margin (A4)3 mm
Print Resolution
Print Quality Black (Best)Up to 1200 x 1200 rendered dpi
Print Quality Color (Best)Up to 4800 x 1200 optimized dpi color when printing from a computer and 1200 input dpi
Supported Printing Media
Media Sizes Supported, Key10 x 15 cm; A4; Envelopes
Media Sizes SupportedA4; B5; A6; DL envelope, legal
Media Sizes, Custom88.9 x 127 mm to 215.9 x 355.6 mm
Standard Media Sizes (Duplex)A4; B5
Media TypesPlain Paper, HP Photo Papers, HP Matte Brochure or Professional Paper, HP Matte Presentation Paper, HP Glossy Brochure or Professional Paper, Other Photo Inkjet Papers, Other Matte Inkjet Papers, Other Glossy Inkjet Papers, Inkjet Hagaki, Plain Paper, Thick, HP Tri-fold Brochure Paper, Glossy, Plain Paper, Light/RecycledMedia Weight, SupportedPlain paper: 60 to 90 g/m²; Envelopes: 75 to 90 g/m²; Cards: up to 200 g/m²; Photo paper: up to 300 g/m²
Media Weight, Recommended75 g/m²
Copier Specifications
Copies, MaximumUp to 99 copies
Copier SettingsNumber of Copies; Black; Color; ID Copy
Copy Speed Black (ISO)Up to 10 cpm
Scanner Specifications
Scan TechnologyContact Image Sensor (CIS)
Color ScanningYes
Scan Input ModesCopy; HP Software
Scan Size, Maximum216 x 297 mm
Bit Depth24-bit
Levels Of Grayscale256
Twain VersionVersion 2.4
Scan File FormatJPEG; PDF
Scan Resolution
Enhanced Scanning ResolutionUp to 1200 dpi
Scan Resolution, HardwareUp to 1200 x 1200 dpi
Scan Resolution, OpticalUp to 1200 dpi
Scan Resolution Enhanced DisclaimerUp to 1200 dpi
Compatible Operating SystemsWindows 11; Windows 10; Windows 7
Memory64 MB Integrated DDR1
Memory SlotsNo
Control PanelPower On/Off, Cancel, Resume, Color Copy, Black copy andID copy button
Minimum System RequirementsMicrosoft® Windows® 11, 10, 7 SP1: 32-bit or 64-bit, Internet connection, USB, Microsoft® Internet Explorer or Edge
Number Of Users1-3 Users
Battery And Power
Power Consumption Description0.11 watts (manual-off), 2.588 watts (ready), 0.984 watts (sleep)
Power Supply TypeInternal built in
Software And Applications
Software IncludedHP Printer Software
Mac CompatibleNo
Warranty2 years Onsite Warranty
What's In The BoxHP Smart Tank 520 All-in-One Printer; HP GT53XL 135ml Black Original Ink Bottle; GT52 50ml Cyan Original Ink Bottle; GT52 50ml Magenta Original Ink Bottle; GT52 50ml Yellow Original Ink Bottle; HP Black Printhead; HP Tri-color Printhead; Power cord; Ink caution flyer; Setup guide; Reference guide; Regulatory flyers; Warranty flyers
Cable IncludedYes, 1m USB.
