Deco S7
AC1900 Whole Home Mesh Wi-Fi System
1900 Mbps WiFi Speed – Enjoy binge watching your favorite series in 4K with combined speeds of up to 1900 Mbps (600 Mbps on 2.4 GHz and 1300 Mbps on 5 GHz ) with 3×3 MU-MIMO technology.
Connect 100+ Devices – Deco handles traffic from even the busiest of networks, providing lag-free connections for over 100 devices.
Boosted Seamless Coverage – With advanced Deco Mesh Technology, units work together to form a unified network with a single network name. Devices automatically switch between Decos as you move through your home for the fastest possible speeds.
Full Gigabit Ethernet – 3× Gigabit WAN/LAN Ethernet ports provide solid internet access at high speeds.
Robust Parental Controls – Limit online time and block inappropriate websites according to unique profiles you create for each family member.
Two Modes in One – Works as a router or access point for a flexible home network.
Easy Setup – Setup is easier than ever with the Deco app there to walk you through every step.
| WIRELESS |
|
| Standards
|
| Wi-Fi 5 |
|
| IEEE 802.11ac/n/a 5 GHz |
| IEEE 802.11n/b/g 2.4 GHz |
|
|
| WiFi Speeds |
| AC1900 |
|
| 5 GHz: 1300 Mbps (802.11ac) |
| 2.4 GHz: 600 Mbps (802.11n) |
|
|
| WiFi Range |
| 3-5 Bedroom Houses (3-pack) |
| TP-Link Mesh Technology |
| Optional Ethernet backhaul works together to link Deco units to provide seamless coverage |
| 3× Antennas (Internal) |
| Multiple antennas form a signal-boosting array to cover more directions and large areas |
| Beamforming |
| Concentrates wireless signal strength towards clients to expand WiFi range |
|
|
| WiFi Capacity |
| Medium |
|
| Dual-Band |
| Distribute devices to different bands for optimal performance |
| MU-MIMO |
| Simultaneously communicates with multiple MU-MIMO clients |
| Working Modes Router Mode |
| Access Point Mode |
|
|
| SECURITY |
|
| Network Security
|
| SPI Firewall |
| Access Control |
|
|
| Guest Network
|
| 1× 5 GHz Guest Network |
| 1× 2.4 GHz Guest Network |
|
|
| WiFi Encryption
|
| WPA-Personal |
| WPA2-Personal |
|
|
| HARDWARE |
| Ethernet Ports |
| 3× Gigabit Ports |
| *Per Deco Unit |
| Supports WAN/LAN auto-sensing |
|
|
| Buttons |
|
| Reset Button |
|
|
| SOFTWARE |
| Protocol
|
| IPv4 |
|
| IPv6 |
|
|
|
| Parental Controls |
| URL Filtering |
| Time Controls |
|
|
| WAN Type
|
| Dynamic IP |
| Static IP |
|
| PPPoE |
|
| PPTP |
|
| L2TP |
|
|
|
| Quality of Service
|
| QoS by Device |
|
|
| Cloud Service
|
| OTA Firmware Upgrade |
| TP-Link ID |
| DDNS |
|
|
|
| NAT Forwarding
|
| Port Forwarding |
| UPnP |
|
|
|
| IPTV
|
|
| IGMP Proxy |
| IGMP Snooping |
| Bridge |
|
| Tag VLAN |
|
|
|
| DHCP
|
|
| Address Reservation |
| DHCP Client List |
| Server |
|
|
|
| DDNS
|
|
| TP-Link |
|
|
|
| Management
|
| Deco App |
|
|
|
| TEST DATA |
| WiFi Transmission Power CE: |
| <20 dBm (2.4 GHz) |
| <23 dBm (5 GHz) |
| FCC: |
|
| <30 dBm (2.4 GHz) |
| <30 dBm (5 GHz) |
|
|
| PHYSICAL |
|
| Dimensions (W×D×H) 6.4 × 3.6 × 3.6 in |
| (162.3 × 90.7 × 90.7 mm) |
|
|
| Package Contents
|
| Deco S7 (3-pack) |
| 3 Deco S7 Units |
| 1 RJ45 Ethernet Cable |
| 3 Power Adapters |
| Quick Installation Guide |
|
|
| Deco S7 (2-pack) |
| 2 Deco S7 Units |
| 1 RJ45 Ethernet Cable |
| 2 Power Adapters |
| Quick Installation Guide |
|
|
| Deco S7 (1-pack) |
| 1 Deco S7 Unit |
| 1 RJ45 Ethernet Cable |
| 1 Power Adapter |
| Quick Installation Guide |
|
|
| OTHERS |
|
| Certification
|
| CE, FCC, RoHS, NCC, BSMI, JRF, JPA, VCCI |
|
|
| System Requirements
|
| Android 5.0 or later |
| iOS 9.0 or later |
| *Note: The minimum system requirements will be updated alongside updates to the app, subject to official website information. |
|
|
| Environment
|
| Operating Temperature: 0?~40? (32? ~104?) |
| Storage Temperature: -40?~60? (-40? ~140?) |
| Operating Humidity: 10%~90% non-condensing |
| Storage Humidity: 5%~90% non-condensing |
