PANEL SIZE
24.5"
PANEL RESOLUTION
1920 x 1080 (FHD)
REFRESH RATE
120Hz
RESPONSE TIME
1ms (MPRT) / 4ms (GTG)
PANEL TYPE
IPS
BRIGHTNESS (NITS)
250 cd/m2
VIEWING ANGLE
178°(H) / 178°(V)
ASPECT RATIO
16:09
CONTRAST RATIO
1500:01:00
sRGB
99% (CIE1976)
ACTIVE DISPLAY AREA (MM)
543.744(H) x 302.616(V)
PIXEL PITCH (H X V)
0.2832(H) x 0.2802(V)
SURFACE TREATMENT
Anti-glare
DISPLAY COLORS
16.7M
COLOR BIT
8 bits (6 bits + FRC)
VIDEO PORTS
1x HDMI™ 1.4b (FHD@120Hz)
1x D-Sub (VGA)
KENSINGTON LOCK
Yes
VESA MOUNTING
100 x 100 mm
POWER TYPE
External Adaptor 12V 2.5A
POWER INPUT
100~240V, 50~60Hz
DYNAMIC REFRESH RATE TECHNOLOGY
Adaptive-Sync
ADJUSTMENT (TILT)
-5° ~ 20°
DIMENSION (W x D x H)
557.2 x 192 x 413.9 mm
(21.94 x 7.56 x 16.30 inch)
CARTON DIMENSION (W X D X H)
630 x 142 x 411 mm
(24.80 x 5.59 x 16.18 inch)
WEIGHT (NW / GW)
2.84 kg (6.26 lbs) / 5.54 kg (12.21 lbs)
CERTIFICATES
CB/CE
Energy Star
VIDEO INPUT COMPATIBILITY
PC, Mac, PS5™, PS4™, Xbox, Mobile, Notebook
* All trademarks and the registered trademarks are the property of their respective owners.
ACCESSORIES
1x HDMI Cable (1.4), 1x Power Adaptor, 1x Quick Guide
Note
HDMI™: 1920 x 1080 (Up to 120Hz)
D-Sub (VGA): 1920 x 1080 (Up to 60Hz)
GeForce RTX™ 4060 VENTUS 2X BLACK 8G OC
WITH DLSS 3
Game, stream, create. The GeForce RTX™ 4060 lets you take on the latest games and apps with the ultra-efficient NVIDIA Ada Lovelace architecture. Experience immersive, AI-accelerated gaming with ray tracing and DLSS 3, and supercharge your creative process and productivity with NVIDIA Studio.
Boost Clock / Memory Speed
2490 MHz / 17 Gbps
8GB GDDR6
DisplayPort x 3 (v1.4a)HDMI™ x 1 (Supports 4K@120Hz HDR, 8K@60Hz HDR, and Variable Refresh Rate as specified in HDMI™ 2.1a)
Dual Fan Thermal Design
TORX Fan 4.0: A masterpiece of teamwork, fan blades work in pairs to create unprecedented levels of focused air pressure.
Zero Frozr: The fans completely stop when temperatures are relatively low, eliminating all noise.
Reinforcing Backplate
The reinforcing backplate features a flow-through design that provides additional ventilation.
MSI Center
The exclusive MSI Center software lets you monitor, tweak, and optimize MSI products in real-time.
SPECIFICATIONS
Model Name
NVIDIA® GeForce RTX™ 4060
Graphics Processing Unit
PCI Express® Gen 4 x 8
Interface
Extreme Performance: 2505 MHz (MSI Center)
Core Clocks
Boost: 2490 MHz
CUDA® CORES
3072 Units
Memory Speed
17 Gbps
Memory
8GB GDDR6
Memory Bus
128-bit
DisplayPort x 3 (v1.4a)
Output
HDMI™ x 1 (Supports 4K@120Hz HDR and 8K@60Hz HDR and Variable Refresh Rate (VRR) as specified in HDMI™ 2.1a)
HDCP Support
Y
Power consumption
115 W or 120 W
Power connectors
8-pin x 1
Recommended PSU
550 W
Card Dimension (mm)
199 x 120 x 41 mm
Weight (Card / Package)
546 g / 783 g
DirectX Version Support
12 Ultimate
OpenGL Version Support
4.6
Maximum Displays
4
G-SYNC® technology
Y
Digital Maximum Resolution
7680 x 4320
GeForce RTX™ 5060 8G VENTUS 2X OC
Powered by the NVIDIA Blackwell architecture and DLSS 4
Core Clocks:Extreme Performance: 2535 MHz (MSI Center)Boost: 2527 MHz
TORX Fan 5.0: Fan blades linked by ring arcs work to stabilize and maintain high-pressure airflow.
Heat Pipes are designed for efficient heat transfer, the heat pipes effectively draw thermal energy away from the GPU, improving overall cooling performance.
Reinforcing Backplate: The reinforcing backplate features an airflow vent that allows exhaust air to pass through directly.
MSI Center: The exclusive MSI Center software lets you monitor, tweak, and optimize MSI products in real-time.
Afterburner software takes full control with the world's most recognized and widely used graphics card overclocking software.
Specifications:
Marketing Name
GeForce RTX™ 5060 8G VENTUS 2X OC
Model Name
G5060-8V2C
Graphics Processing Unit
NVIDIA® GeForce RTX™ 5060
Interface
PCI Express® Gen 5 x16 (uses x8)
Core Clocks
Extreme Performance: 2535 MHz (MSI Center)Boost: 2527 MHz
CUDA® Cores
3840 Units
Memory Speed
28 Gbps
Memory
8GB GDDR7
Memory Bus
128-bit
Output
DisplayPort x3 (v2.1b)HDMI™ x1 (2.1b: up to 4K 480Hz / 8K 120Hz with DSC, Gaming VRR, HDR)
HDCP Support
Yes
Power Consumption
145 W
Power Connectors
8-pin x1
Recommended PSU
550 W
Card Dimensions (mm)
197 x 120 x 41 mm
Weight (Card / Package)
511 g / 829 g
DirectX Version Support
12 Ultimate
OpenGL Version Support
4.6
Maximum Displays
4
G-SYNC® Technology
Yes
Digital Maximum Resolution
7680 x 4320
Key specifications
Component
Specification
GPU Model
NVIDIA GeForce RTX 5070
CUDA Cores
6144
Boost Clock
2557 MHz (OC Mode)
Memory
12GB GDDR7
Memory Speed
28 Gbps
Memory Bus
192-bit
Interface
PCI Express 5.0 x16
Video Outputs
3x DisplayPort 2.1b, 1x HDMI 2.1b
Power Connector
1x 16-Pin PCI Connector
Max Power Consumption
250W
Recommended PSU
650W
Architecture
NVIDIA Blackwell
Cooling
Three-fan open fansink with features like a nickel-plated copper baseplate and a reinforcing backplate with a vent
Specifications
GPU:
NVIDIA GeForce RTX 5050
Architecture:
NVIDIA Blackwell
CUDA Cores:
2560
Boost Clock:
2617 MHz
Memory:
8GB GDDR6
Memory Speed:
20 Gbps
Memory Bus:
128-bit
Interface:
PCI Express Gen 5.0 x8
Display and Power
Display Outputs:
3x DisplayPort 2.1b, 1x HDMI™ 2.1b
Maximum Resolution:
7680 x 4320 (8K)
Power Connector:
1x 8-pin PCI
Recommended PSU:
550W
Features
AI Technologies:
DLSS 4 (including Multi Frame Generation, Enhanced Ray Reconstruction, Super Resolution)
Cooling:
TORX Fan 5.0 with heat pipes and a reinforcing backplate with airflow vent
Software:
MSI Center for monitoring and optimization, and Afterburner for overclocking
Specifications
Marketing Name:
GeForce RTX™ 5060 Ti 16G VENTUS 2X OC PLUS
GPU Architecture:
NVIDIA Blackwell
NVIDIA Blackwell
CUDA Cores:
4608 Units
4608 Units
Memory Size:
16 GB GDDR7
16 GB GDDR7
Memory Interface:
128-bit
128-bit
Core Clock (Boost):
2602 MHz
2602 MHz
Memory Speed:
28 Gbps
28 Gbps
Output Ports:
3x DisplayPort 2.1b, 1x HDMI 2.1b
3x DisplayPort 2.1b, 1x HDMI 2.1b
Power Connectors:
1x 8-pin
1x 8-pin
Recommended PSU:
600 W
Design and Cooling
Cooling System:
Features a dual-fan design with TORX 5.0 fans.
Airflow:
The fans use a ring arc design with tilted fan blades to improve airflow.
Heatsink:
A nickel-plated copper baseplate and square-shaped heat pipes facilitate efficient heat transfer from the GPU and VRAM.
Backplate:
A vented metal backplate adds structural integrity and aids in heat dissipation.
Other Features
MSI Center:
Software for monitoring and optimizing the graphics card.
MSI Afterburner:
Another tool for control and performance tuning.
ZERO FROZR:
Fan technology that stops the fans during low loads to reduce noise.
