DESCRIPTION HYPER K Series Power Supply meets the market mainstream and provides efficiency more than 85%.With the +12 single rail design, SATA array cable, optimized the airflow in case, no-hassle with case side panel. KEY FEATURES Complies with ATX 12V v2.4 & EPS 12V v2.92 Meets 85% Efficiency Active PFC, Power Factor ≧ 99% +12V Single Rail Design PCI-Express 6+2 Pin Graphic Card Connectors SATA Array Cable 120mm Quiet Fan Complete Protections: OCP, OVP, SCP Meet ErP/EuP 2013 Standard Latest Intel Platform Ready Multiple Safety Approvals SPECIFICATIONS  Model  HP600S Form factor ATX 12V V2.4 & EPS 12V V2.92 Input Voltage 200-240Vac Input Current  4.5A Input Frequency  50-60Hz PFC Active PFC (>0.9 typical) Efficiency  Meet 85% @ Typical Load Fan type 120mm Sleeved Fan Noise  < 19dBA Dimensions  150 x 140 x 86 mm Weight  1657g Operation Temperature 0~40°C / 32°F~104°F Protection OVP/OCP/SCP Safety approval  CE/TUV/KC/RCM/EAC

Read more less

HYPER K 700W Complies with ATX 12V v2.4 & EPS 12V v2.92 Meets 85% Efficiency Active PFC, Power Factor ≧ 99% +12V Single Rail Design PCI-Express 6+2 Pin Graphic Card Connectors SATA Array Cable 120mm Quiet Fan Complete Protections: OCP, OVP, SCP Meet ErP/EuP 2013 Standard Latest Intel Platform Ready Multiple Safety Approvals HYPER K series comes ranging from 500W, 600W to 700W for your choice. Enthusiasts of Gamer and hardware, you won't miss HYPER series this time, the high stable performance but affordable price will be your BEST choice.HYPER K series comes with the +12 single rail design and the SATA array cable, optimized the airflow in case, no-hassle with case side panel. Also, 120mm long lasting fan provides superior cooling, noise <19dBA at 50% loading. Multiple PCI-Express 6+2 pin connectors equipped also 8 units of SATA cable provided. Model No. HP700S AC Input 200-240Vac ~ 5A 50-60Hz DC Output +3.3V +5V +12V -12V +5Vsb Max Output Current 20A 20A 53A 0.3A 3.0A Max Combined Power 150W 636W 18.6W Total Power 700W   Specifications Model HP700S Rated Output Power 700W Form Factor ATX 12V V2.4 & EPS 12V V2.92 Input Voltage 200-240Vac Input Current 5A Input Frequency 50-60Hz PFC Active PFC (>0.9 typical) Efficiency ≥85% at typical load Fan Type 120mm Sleeved Fan Noise < 19dBA Dimensions (Lx W x H) 150 x 140 x 86 mm Weight 1752g Operation Temp. 0~40°C / 32°F~104°F Protection OVP/OCP/SCP Safety Approval CE/TUV/KC/RCM/EAC

Read more less
