H10
Dash Camera
> 2160P ultra high resolution image> Supports ADAS: Front Vehicle Starting Warning, Front Vehicle Collision Warning, Lane Departure Warning> Supports 24-hours parking monitoring (with hardwire kit)> Supports WDR> Built-in Wi-Fi AP module> G-Sensor module supports collision detection and video lock> Supports MicroSD card up to 256 GB Compatible with mobile client for setup, live view, recording search and backup> Supports voice control> Front and rear recording (Optional)
Camera
Image Sensor
1/2.7'' CMOS
Frame Rate
Dual-Channel: 3840Px2160P@30FPS; 1920Px1080P@25FPS (Optional)
Single-Channel: 3840Px2160P@30FPS
Field of View
H:118°,V: 62°,D:143°
Iris
F1.75
Video Compression
H.265
OSD
Display time, date, etc.
Image format
JPEG
Storage
1 TF card (up to 256GB)
Communication Module
5G WiFi AP
G-sensor
Built in, supports locking video after collision.
Interface
Power Supply
Type C
Audio Input
Build-in microphone
Audio Output
Build-in speaker
ADAS
Front Vehicle Starting Warning
Supported
Front Vehicle Collision Warning
Supported
Lane Departure Warning
Supported
General
Operating Temperature
-20°C to 70°C(-4°F to 158°F)
Operating humidity
<95%(No condensation)
Power Supply
DC 5V/2A
Power Consumption
<3.5W
Dimensions
106.0mm×49.5mm×39.8mm(4.17''×1.95''×1.57'')
Weight
≈120g
TF-W100-32GB/64GB/128GB/256GB
W100 Wide-Temperature Memory Card
> Adopts mainstream flash memory cell with P/E cycle up to 3,000;meets requirements of wide temperature range; superiorperformance and long service life.> Four types of protection: High and low temperature resistant, waterproof, anti-magnetic, and anti X-ray; adapts to various environments.> Meets various user needs such as recording monitoring videos and entertainment.> Compatible with various digital products.
Product Selector
Technical Specification
Product Model
DHI-TF-W100-32GB
DHI-TF-W100-64GB
DHI-TF-W100-128GB
DHI-TF-W100-256GB
Capacity
32GB
64 GB
128 GB
256 GB
Manufacturing Process
3D NAND FLASH
Read Speed
Up to 90 MB/s
Up to 90 MB/s
Up to 95 MB/s
Up to 95 MB/s
Write Speed
Up to 75 MB/s
Up to 45 MB/s
Up to 70 MB/s
Up to 85 MB/s
Speed Rating
C10/U1/V10
C10/U3/V30
C10/U3/V30
C10/U3/V30
UHS
UHS-I
TBW
60TB
120TB
240TB
500TB
File System
FAT32
FAT32
FAT32
FAT32
Operating Temperature
–25 °C to +85 °C (–13 °F to +185 °F)
Storage Temperature
–40 °C to +85 °C (–40 °F to +185 °F)
Operating Humidity
5%–95% (non-condensing)
Four Types of Protection
High and low temperature resistant, waterproof, anti-magnetic, and anti X-ray
Compatibility
Cameras, game consoles, laptops, tablets, digital stereo systems, and more.
Packaging Dimensions
120 mm × 800 mm × 5.8 mm (5.12" × 3.94" × 0.23")
Net Weight
0.16 g
Gross Weight
8.6 g
Reference Information
1. The capacity written on the product and package is nominal capacity.
2. 1 GB = 1 billion bytes, and the nominal capacity is not all for data storage. According to internal testing, the transmission speed varies with the devices, ports, environments, and other factors.
Dahua DHI-DAE-HC3511GW-S8. Dahua WiFi dashboard camera. High resolution 2160P. 3" touch screen. Built-in Wi-Fi AP module. G-Sensor module supports collision detection and video blocking. Supports MicroSD card up to 128 GB. Compatible with mobile client. Supports voice control. Supports GPS track playback. Front and rear recording Dhi-dae-hc3511gw-s8.
1/2.9" 8-megapixel CMOS sensor
H.265 compression format
Resolution: 8MP (3840x2160) at 30 fps, 4MP (2560x1440) at 30 fps
Viewing Angle: 123°(H), 56°(V), 106°(D)
3" (320x640) touch screen display
OSD: Time, date, etc.
Built-in microphone and speaker
MicroSD card slot up to 128GB (card not included)
Built-in WiFi access point
Built-in G-sensor with video lock support after collision
Power supply: 5V DC, 1.5A (Mini USB)
Power consumption: 5.5W
Operating temperature from -20°C ~ +70°C
Relative humidity: <95% (non-condensing)
Dimensions: 91.29 (W) x 57.5 (H) x 38.67 mm
Weight: 108.9 g
DAHUA-4323
High-resolution automotive dash camera
Easy installation and operation
Can be communicated with its DH Dashcam app through built-in Wi-Fi
2304P × 1296P ultra high resolution image Wide field of view F1.8 iris offers crisp night imaging Mini body Wi-Fi AP module G-Sensor module supports collision detection and video lock Supports MicroSD card up to 128 GB Compatible with mobile client for setup, live view, recording search and backup Voice control
M1pro
Dash Camera
> 1080P ultra high resolution image> F2.0 iris offers crisp night imaging> Built-in Wi-Fi AP module> G-Sensor module supports collision detection and video lock> Supports MicroSD card up to 128 GB> Compatible with mobile client for setup, live view, recording search and backup> HD night vision
Camera
Image Sensor
1/3.0'' CMOS
Resolution
1920×1080P@30FPS
Field of View
D: 121°, H: 101°, V: 53°
Iris
F2.0
Video Compression
H.265
OSD
Display time, date, etc.
Image format
JPEG
Storage
1 TF card (up to 128GB)
Communication Module
WiFi AP
G-sensor
G-Sensor
Interface
Power Supply
Mini USB
Audio Input
Build-in microphone
Audio Output
Build-in speaker
General
Operating Temperature
-20°C to 70°C(-4°F to 158°F)
Operating Humidity
<95%(No condensation)
Power Supply
5V DC/1.5A
Power Consumption
≤1.5W
Dimensions
80mm×48mm×28.8mm(3.15′′×1.89′′×1.13′′)
Weight
Approx. 42 g (0.093 lb.)
Technical Details
Brand
DAHUA
Manufacturer
DAHUA
Flash memory type
MicroSD
Special Features
G Sensor, Built In GPS
Mounting Hardware
Dash Cam
Number of items
1
Standing screen display size
3 Inches
Display Type
LCD
Batteries Included
No
Batteries Required
No
Connector Type
Wi-Fi
Product dimensions
4 x 6 x 9 cm; 600 Grams
Item Weight
600 g
