Description
Specifications
Model name: 24B30H2/BW
EAN: 697 398523 218 3
Panel: 23.8" / IPS
Pixel Pitch (mm): 0.2745 (H) × 0.2745 (V)
Effective Viewing Area (mm): 527.04 (H) × 296.46 (V)
Brightness (typical): 300 cd/m²
Contrast Ratio: 1300 : 1 (typical) 20 Million : 1 (DCR)
Response Time: 1ms MPRT / 4ms (GtG)
Viewing Angle: 178° (H) / 178° (V) (CR > 10)
Color Gamut: NTSC 95% (CIE1976) / sRGB 106% (CIE1931)
Color Accuracy -
Optimum Resolution: 1920 × 1080 @ 120Hz – HDMI (OC); 1920 × 1080 @ 75Hz – VGA
Display Colors: 16.7 Million
Signal Input: HDMI 1.4 × 1, VGA × 1
HDCP Version: HDMI : 1.4
USB Hub: No
Power Supply: External 19VDC, 1.31A
Power Consumption (typical): 20W
Speakers: No
Line in & Earphone: No
Wall-Mount: 100mm × 100mm
Adjustable Stand: Tilt: -5° ~ 23°
Product without Stand (mm): 321.2 (H) × 540.6 (W) × 34.8 (D)
Product with Stand (mm): 415.4 (H) ×540.6 (W) × 185.9 (D)
Packaging (mm): 372 (H) × 615 (W) × 93 (D)
Product without Stand (kg): 2.28
Product with Stand (kg): 2.54
Product with Packaging (kg): 4.12
Cabinet Color: Black & White
Regulatory Approvals: CE / FCC / RoHS
What's in the box: HDMI Cable 1.8m × 1
* Design and specifications are subject to change without notice.
