β±1,996.68
| Category | Details |
|---|---|
| Range | Resi9 |
| Product Name | Resi9 MP |
| Product / Component Type | Enclosure |
| Enclosure Type | Modular Enclosure |
| Modules per Row (18 mm) | 12 |
| Number of Horizontal Rows | 2 |
| Door Type | Plain |
| Total Number of Modules (18 mm) | 24 |
| 9 mm Pitches | 24 |
| Rated Current | 63 A |
| Market Segment | Small Commercial, Residential |
| Dimension | Size |
|---|---|
| Width (Outside) | 268 mm |
| Height (Outside) | 353 mm |
| Depth (Outside) | 102 mm |
| Internal Depth | 80 mm |
| Category | Details |
|---|---|
| Enclosure Mounting | Surface |
| Type of Rail | 35 mm Asymmetrical Rail |
| Mounting Plate | Without Mounting Plate |
| Cable Entry | 1 Trunking Flange, 1 Bare Flange |
| Enclosure Material | Back Part: Technoplastic Door: Technoplastic Front Face: Technoplastic |
| Category | Details |
|---|---|
| Terminal Block Function | Earth / Neutral |
| Number of Terminal Blocks | 1 Earth (Screwed) with 16 Outgoers 1 Neutral (Screwed) with 16 Outgoers |
| Distribution Block Outgoers | Earth: 2 Γ 16 mmΒ², 6 Γ 6 mmΒ², 8 Γ 10 mmΒ² Neutral: 2 Γ 16 mmΒ², 6 Γ 6 mmΒ², 8 Γ 10 mmΒ² |
| Category | Details |
|---|---|
| Standards | IEC 60670-1, IEC 60670-24 |
| Quality Labels | IMQ |
| Fire Resistance | Door: 650 Β°C Back Part: 650 Β°C Front Face: 650 Β°C |
| IP Protection Rating | IP40 |
| IK Protection Rating | IK07 |
| Operating Temperature | -25 Β°C to +60 Β°C |
| Component | Color |
|---|---|
| Door | White (RAL 9003) |
| Front Face | White (RAL 9003) |
| Category | Details |
|---|---|
| Unit Type | PCE |
| Units per Package | 1 |
| Dimensions (HΓWΓL) | 10.2 Γ 26.8 Γ 35.3 cm |
| Weight | 1.194 kg |
