₱2,772.84
| Feature | Description |
|---|---|
| Range | Resi9 |
| Product Name | Resi9 MP |
| Product or Component Type | Enclosure |
| Enclosure Type | Modular enclosure |
| Number of 18 mm Modules per Row | 12 |
| Number of Horizontal Rows | 3 |
| Type of Door | Plain |
| Dimension | Measurement |
|---|---|
| Width (Wall) | 270 mm |
| Width (Outside) | 294 mm |
| Height (Wall) | 478 mm |
| Height (Outside) | 502 mm |
| Depth (Outside) | 18 mm |
| Depth (Wall) | 80 mm |
| Total Depth | 98 mm |
| Feature | Description |
|---|---|
| Enclosure Mounting | Flush |
| 9 mm Pitches | 24 |
| Total Number of 18 mm Modules | 36 |
| Rated Current [In] | 63 A |
| Type of Rail | 35 mm asymmetrical rail |
| Mounting Plate | Without mounting plate |
| Cable Entry | Pre-cutted holes |
| Terminal Block Function | Earth / Neutral |
| Feature | Description |
|---|---|
| Number of Terminal Blocks | 1 earth (screwed) with 20 outgoers 1 neutral (screwed) with 20 outgoers |
| Distribution Block Outgoers | Earth: 2 × 16 mm², 9 × 10 mm², 9 × 6 mm² Neutral: 2 × 16 mm², 9 × 10 mm², 9 × 6 mm² |
| Feature | Description |
|---|---|
| Enclosure Material | Back part: technoplastic Door: technoplastic Front face: technoplastic |
| Internal Depth | 76 mm |
| Colour | Door: White (RAL 9003) Front face: White (RAL 9003) |
| Feature | Description |
|---|---|
| Market Segment | Residential Small commercial |
| Standards | IEC 60670-1 IEC 60670-24 |
| Quality Labels | IMQ |
| Feature | Description |
|---|---|
| Fire Resistance | Door: 650 °C Back part: 650 °C Front face: 650 °C |
| IP Degree of Protection | IP40 |
| IK Degree of Protection | IK07 |
| Operating Temperature | −25…60 °C |
| Feature | Description |
|---|---|
| Unit Type | PCE |
| Units per Package | 1 |
| Height | 9.000 cm |
| Width | 29.500 cm |
| Length | 50.000 cm |
| Weight | 1.950 kg |
