₱420.84
| Category | Specification |
|---|---|
| Main | |
| Range | Easy9 |
| Device application | Distribution |
| Product or component type | Miniature circuit-breaker |
| Device short name | Easy9 MCB |
| Poles | 2P |
| Number of protected poles | 2 |
| Rated current [In] | 40 A |
| Network type | AC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 10000 A Icn at 220 V AC 50/60 Hz (IEC 60898-1) 6000 A Icn at 400 V AC 50/60 Hz (IEC 60898-1) |
| Suitability for isolation | Yes (IEC 60898-1) |
| Complementary | |
| Network frequency | 50/60 Hz |
| Rated operational voltage [Ue] | 220 V AC 50/60 Hz 400 V AC 50/60 Hz |
| Magnetic tripping limit | 5…10 × In |
| Rated service breaking capacity [Ics] | 6 kA (100% × Icn) at 230 V AC (IEC 60898-1) |
| Rated insulation voltage [Ui] | 500 V AC (IEC 60898-1) |
| Rated impulse withstand voltage [Uimp] | 4 kV (IEC 60898-1) |
| Contact position indicator | Yes |
| Control type | Toggle |
| Local signalling | Without |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| 9 mm pitches | 4 |
| Height | 81 mm |
| Width | 36 mm |
| Depth | 66.5 mm |
| Colour | Grey (RAL 7035) |
| Mechanical durability | 10,000 cycles |
| Electrical durability | 4,000 cycles |
| Connections – terminals | Tunnel type (top or bottom) 1–25 mm² flexible Tunnel type (top or bottom) 1–35 mm² rigid |
| Tightening torque | 3.5 N·m (top or bottom) |
| Earth-leakage protection | Without |
| Environment | |
| Standards | IEC 60898-1 |
| Product certifications | CE |
| IP degree of protection | IP20 (IEC 60529) |
| Pollution degree | 2 |
| Tropicalisation | 2 |
| Relative humidity | 95% at −5…60 °C |
| Ambient air temperature (operation) | −5…60 °C |
| Ambient air temperature (storage) | −40…85 °C |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.600 cm |
| Package 1 Width | 7.600 cm |
| Package 1 Length | 8.500 cm |
| Package 1 Weight | 240 g |
₱420.84
Estimated delivery between June 11 and June 13.
Delivery Information
Metro Manila: 2–3 days | Provincial: 3–7 days
Main Office Branch only
Same Day Delivery
Same-Day Delivery Available
Processing starts 1–2 hours after checkout Mon–Sat | Main Office Branch only
Processing only during office hours from Main Office 9am - 5pm
₱420.84
₱420.84
Authorized Seller
100% Original Authentic Product
