| Category | Specification |
|---|---|
| Main | |
| Range | Easy9 |
| Device application | Distribution |
| Product / component type | Miniature circuit-breaker |
| Device short name | Easy9 MCB |
| Poles | 2P |
| Number of protected poles | 2 |
| Rated current [In] | 32 A |
| Network type | AC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 10,000 A Icn @ 220 V AC 50/60 Hz (IEC 60898-1) 6,000 A Icn @ 400 V AC 50/60 Hz (IEC 60898-1) |
| Suitability for isolation | Yes (IEC 60898-1) |
| Complementary | |
| Network frequency | 50/60 Hz |
| Rated operational voltage [Ue] | 220 V AC 50/60 Hz 400 V AC 50/60 Hz |
| Magnetic tripping limit | 5β¦10 Γ In |
| Service breaking capacity [Ics] | 6 kA (100% Γ Icn) @ 230 V AC 50/60 Hz (IEC 60898-1) |
| Rated insulation voltage [Ui] | 500 V AC 50/60 Hz (IEC 60898-1) |
| Rated impulse withstand voltage [Uimp] | 4 kV (IEC 60898-1) |
| Contact position indicator | Yes |
| Control type | Toggle |
| Local signalling | Without |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| 9 mm pitches | 4 |
| Height | 81 mm |
| Width | 36 mm |
| Depth | 66.5 mm |
| Colour | Grey (RAL 7035) |
| Mechanical durability | 10,000 cycles |
| Electrical durability | 4,000 cycles |
| Connections β terminals | Tunnel terminal (top/bottom) 1β25 mmΒ² flexible Tunnel terminal (top/bottom) 1β35 mmΒ² rigid |
| Tightening torque | 3.5 NΒ·m (top/bottom) |
| Earth-leakage protection | Without |
| Environment | |
| Standards | IEC 60898-1 |
| Product certifications | CE |
| IP degree of protection | IP20 (IEC 60529) |
| Pollution degree | 2 |
| Tropicalisation | 2 |
| Relative humidity | 95% at β5β¦60 Β°C |
| Ambient temperature (operation) | β5β¦60 Β°C |
| Ambient temperature (storage) | β40β¦85 Β°C |
| Packing Units | |
| Unit Type Package 1 | PCE |
| Units in Package 1 | 1 |
| Package 1 (H Γ W Γ L) | 3.600 cm Γ 8.500 cm Γ 7.600 cm |
| Package 1 Weight | 198 g |
