₱208.80
| Category | Specification |
|---|---|
| Range | Easy9 |
| Product or Component Type | Comb busbar |
| Accessory Category | Connection accessory |
| Mounting Mode | Horizontal |
| Lines Description | 1L |
| Length (18 mm Modules) | 12 |
| Number of Ways | 12 ways (1L) |
| Poles Configuration per Way | 1 × 1P |
| Connection Pitch | 18 mm |
| Distance Between Ways | 18 mm |
| Connector Type | Tooth |
| Insulation | Insulated |
| Device Presentation | Cuttable |
| Provided Equipment | 2 × end pieces |
| Rated Operational Current (Ie) | 63 A at 40 °C |
| Rated Operational Voltage (Ue) | 230 V AC, 50 Hz (Ph/N) |
| Rated Insulation Voltage (Ui) | 500 V AC (IEC 61439-1) |
| Mounting Location | Top on tunnel-type terminals |
| 9 mm Pitches | 24 |
| Width | 220 mm |
| Colour | Light grey (RAL 7035) |
| Range Compatibility | Easy9, Easy9 XP |
| Standards | IEC 60439-1, IEC 60664 |
| Fire Resistance | 850 °C (30 s) – IEC 60695-2-1 |
| Pollution Degree | 2 |
| Package Type | Quantity | Dimensions (H × W × L) | Weight |
|---|---|---|---|
| PCE | 1 | 1.5 × 1.5 × 21.5 cm | 35 g |
| BB1 | 15 | 5.9 × 8.5 × 24.8 cm | 583 g |
| S03 | 270 | 30 × 30 × 40 cm | 10.835 kg |
₱208.80
Estimated delivery between June 11 and June 13.
