Picture/Display
Panel Size 23.8 inch / 60.5 cm
Aspect ratio 16:9
LCD panel type VA LCD
Backlight type W-LED system
Pixel pitch 0.2745 x 0.2745 mm
Brightness 250 cd/m²
Display colors 16.7 M
Contrast ratio (typical) 3000:1
Smart Contrast Mega Infinity DCR
Response time (typical) 4 ms (GtG)*
Viewing angle
- 178º (H) / 178º (V)
- @ C/R > 10
Maximum resolution 1920 x 1080 @ 75 Hz*
Effective viewing area 527 (H) x 296.5 (V)
Scanning Frequency 30 - 85 kHz (H) / 48 - 75 Hz (V)
sRGB Yes
Flicker-free Yes
Pixel Density 93 PPI
LowBlue Mode Yes
Display Screen Coating Anti-Glare, 3H, Haze 25%
EasyRead Yes
Adaptive sync Yes
Connectivity
Signal Input
-
VGA (Analog)
-
HDMI (digital, HDCP)
Sync Input
-
Separate Sync
-
Sync on Green
Audio (In/Out) Audio out
Convenience
Plug & Play Compatibility
-
DDC/CI
-
Mac OS X
-
sRGB
-
Windows 10 / 8.1 / 8 / 7
User convenience
-
Power On/Off
-
Menu/OK
-
Brightness/UP
-
Input/Down
-
Smart Image/Back
Compliance and standards
Regulatory Approvals
- UKRAINIAN
- CB
- TUV Ergo
- TUV/GS
- CU-EAC
- EAEU RoHS
- CE Mark
- PSB
|
Stand
Tilt -5/20 degree
Power
Power supply
o Built-in
o 100-240VAC, 50-60Hz
Off mode 0.3 W (typ.)
On mode 20.4 W (typ.)
Standby mode 0.5 W (typ.)
Power LED indicator
o Operation - White
o Standby mode- White (blinking)
Dimensions
Packaging in mm (WxHxD): 608 x 415 x 121 mm
Product without stand (mm) 540 x 322 x 51 mm
Product with stand(max height) 540 x 416 x 220 mm
Weight
Product with packaging (kg) 4.25 kg
Product with stand (kg) 3.03 kg
Product without stand (kg) 2.64 kg
Operating conditions
Altitude Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
Temperature range (operation) 0°C to 40°C °C
MTBF 50,000 (Excluded backlight) hour(s)
Relative humidity 20%-80 %
Temperature range (storage) -20°C to 60°C °C
Sustainability
Environmental and energy
o RoHS
o Mercury Free
Recyclable packaging material
100 %
Cabinet
Color: Black
Finish: Textured
|
