Description
Packaging dimensions : H 179 x L 159 x W43 mm
Main unit dimension
Neckband wearing style: H 157 x W 141 x D 35 mm (H 5.6 x W 5.6 x D 1.4 in)
Weight mono / duo : 48g with metal weight
Battery included : Yes (rechargeable lithium-ion)
Charging time : Approximately 2 hours
Certifications
Bluetooth® 4.1, CE, FCC, IC, GOST, RoHS, REACH, IP54
Supported Bluetooth® profiles
Headset profile v1.2 , hands free profile v1.6, A2DP v1.2, AVRCP v1.4
Bluetooth® compliance
IC, BQB, CE, FCC
Bluetooth® wireless technology
CSR8635
Operating range
Up to 10 meters (33 feet)
Headset bandwidth : 50Hz to 7kHz (Wide Band), 50Hz to 3.5kHz (Narrow Band)
Connection (mini jack, USB, etc) : Micro USB for charging
Talk time : Up to 18 hours
Standby time : Up to 22 days
Speaker size : 10 mm Neodymium magnet speaker
Speaker sensitivity : 92± 3db /mw (Input level:0.13V IEC-60318 at 1 KHz)
Speaker impedance : 16 Ω
Speaker max input power : 8m W
Speaker frequency range : 20Hz to 20kHz
Microphone type : Electret condenser (ECM) Omni-directional
Microphone Sensitivity : -40+/-3dB(0dB=1V/Pa at 1KHz)
Microphone frequency range : 50HZ~17KHZ
Speaker bandwidth (music mode) : 20Hz to 20kHz
Speaker bandwidth (speak mode) : 50Hz to 7kHz (Wide Band), 50Hz to 3.5kHz (Narrow Band)
Microphone bandwidth : 100Hz to 7.5kHz (Wide Band), 100 Hz to 3.5kHz (Narrow Band)
Cord length : 2 x 22.5 cm (8.9 in) / USB data cable: 31 cm (12.2 in)
Operating temperature : -10°C to +55°C (15 F to 140 F)
Storage temperature : -20°C to +85°C (-4 F to 185 F)
Paired devices : Up to 8 - connected to two at the same time (Multiuse™)
Current consumption microphone : 500uA
Charging plug dimensions : 5 PIN micro USB / B Type / W 8.7 x L 5.0 x H 2.4 mm (W 0.34 x L 0.2 x H 0.1 in)
Materials used : Silicone, PC/ABS, PMMA, PA, PET, TPE and TPU
Pairing PIN : 0
Features
Call vibration alert, magnetic in-ear headphones, voice button, answer/end call, reject call,
voice dialling*, last number redial*, volume control, track control, play/pause music, voice guidance
