₱6,062.50
Prime B560 series is engineered with multiple onboard heatsinks and an array of hybrid fan headers to ensure your rig stays cool and stable under intense workloads.
The VRM heatsink with underneath thermal pad improve heat transfer from the MOSFETs for better cooling performance.
Prime B560 series is built to handle the additional cores and increased bandwidth of 11th Generation Intel® Core™ processors. ASUS B560 motherboards provide all the fundamentals to boost daily productivity, so your system will be ready for action with stable power, intuitive cooling and flexible transfer options.
| Category | Specification |
|---|---|
| CPU Socket | Intel® Socket LGA1200 |
| Supported CPUs | 11th Gen Intel® Core™, 10th Gen Intel® Core™, Pentium® Gold, Celeron® |
| CPU Process Support | Intel® 14nm |
| Turbo Boost Support | Intel® Turbo Boost 2.0 & Turbo Boost Max 3.0 |
| Chipset | Intel® B560 |
| Form Factor | microATX |
| Motherboard Dimensions | 24.4 × 21.1 cm |
| Estimated Weight | 0.75 kg |
| Estimated Weight with Packaging | 1.20 – 1.50 kg |
| Feature | Details |
|---|---|
| Memory Type | DDR4 Non-ECC, Un-buffered |
| Memory Speeds Supported | DDR4 5000(OC) / 4800(OC) / 4600(OC) / 4400(OC) / 4266(OC) / 4000(OC) / 3733(OC) / 3600(OC) / 3466(OC) / 3333(OC) / 3200(OC) / 2933 / 2800 / 2666 / 2400 / 2133 MHz |
| Port | Quantity |
|---|---|
| VGA / D-Sub | 1 |
| HDMI 2.0 | 1 |
| Slot Type | Quantity |
|---|---|
| PCIe 4.0/3.0 x16 | 1 |
| PCIe 3.0 x1 | 2 |
| Storage Option | Details |
|---|---|
| M.2 Slots | 2 |
| SATA Ports | 6 × SATA 6Gb/s |
| M.2_1 | PCIe 4.0 x4 (11th Gen CPUs only) |
| M.2_2 | PCIe 3.0 x4 & SATA support |
| Supported M.2 Sizes | 2242 / 2260 / 2280 |
| Port | Quantity |
|---|---|
| USB 3.2 Gen 1 Type-A | 4 |
| USB 2.0 Type-A | 2 |
| HDMI | 1 |
| VGA / D-Sub | 1 |
| Intel® I219-V Gigabit LAN | 1 |
| Audio Jacks | 3 |
| PS/2 Combo Port | 1 |
| Connector | Quantity |
|---|---|
| CPU Fan Header | 1 |
| Chassis Fan Header | 1 |
| 24-pin ATX Power | 1 |
| 8-pin CPU Power | 1 |
| USB 3.2 Gen 1 Header | 1 |
| USB 2.0 Headers | 2 |
| RGB Header | 1 |
| Clear CMOS Header | 1 |
| COM Port Header | 1 |
| Front Panel Audio Header | 1 |
| S/PDIF Out Header | 1 |
| Speaker Header | 1 |
| SPI TPM Header | 1 |
| System Panel Header | 1 |
| Feature | Details |
|---|---|
| LAN | Intel® I219-V 1Gb Ethernet |
| Audio | HD Audio with 3 audio jacks |
| OS | Support |
|---|---|
| Windows 10 | 64-bit |
