Picture/Display
Panel Size: 15.6 inch / 39.6 cm
Aspect ratio: 16:9
LCD panel type: IPS technology
Backlight type: W-LED system
Pixel pitch: 0.17925 x 0.17925 mm
Brightness: 250 cd/m²
Display colors: 16.2 M (6 bit + FRC)
Color gamut (typical): NTSC 46%*,
sRGB 64%*
Contrast ratio (typical): 700:1
Smart Contrast: 50,000,000:1
Response time (typical): 4 ms (Gray to
Gray)*
Viewing angle
-170º (H) / 170º (V)
-@ C/R > 10
Picture enhancement: Smart Image
Maximum resolution: 1920 x 1080
@ 75 Hz
Effective viewing area: 344.16 (H)
x 193.59 (V)
Scanning Frequency: Landscape mode: 30 - 85
kHz (H) / 48 - 75 Hz (V);
Portrait mode: 30 - 150 kHz (H) /48 - 75 Hz (V)
sRGB: Yes
Flicker-free: Yes
Pixel Density: 141 PPI
LowBlue Mode: Yes
Display Screen Coating: Anti-Glare, 3H, Haze 25%
Easy Read: Yes
Power
ECO mode: 4.4 W
Off mode: 0.3 W
On mode: 6.2 W (EnergyStar test method)
Standby mode: 0.5 W
Power LED indicator: Operation - White
Standby mode- White (blinking)
Energy Label Class: C
Operating conditions
Altitude: Operation: +12,000ft (3,658m),
Non-operation: +40,000ft (12,192m)
Temperature range (operation): 0°C to 40 °C
Relative humidity: 20%-80 %
Temperature range (storage): -20°C to 60 °C
MTBF (demonstrated): 70,000 hrs.
(excluded backlight)
Compliance and standards
Regulatory Approvals:
- CB/ TUV/GS/ TUV Ergo/ CU-EAC/ EAEU RoHS
- CE Mark/ FCC Class B/ ICES-003/ cETLus
|
Connectivity
Signal Input: USB-C x 2 (DP Alt mode,
Data, Power delivery)
Sync Input: Separate Sync
Audio (In/Out): Audio out
HDCP: HDCP 1.4 (USB-C), HDCP
2.2 (USB-C)
Power Delivery
Version: PD version 3.0
USB-C (input): Up to 90 W (5V/3A,
7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A,
20V/4.5A)
USB-C (output): Up to 65 W (5V/3A,
7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A,
20V/3.25A)
Convenience
Plug & Play Compatibility
DDC/CI / Mac OS X/ sRGB/ Windows 11 / 10 /
8.1 /
User convenience
Smart Image/ Input/ Menu/ Power On/Off
Stand
Pivot: +90 degree
Tilt: 0 ~ 90 degree
Dimensions
Packaging in mm (WxHxD): 404 x 281 x 103 mm
Product with stand(max height): 359 x 232 x 119
mm
Weight
Product with packaging (kg): 2.08 kg
Product with stand (kg): 1.03 kg
Sustainability
Environmental and energy:
- EnergyStar 8.0
- EPEAT*
- RoHS
Post-consumer recycled plastic: 60%
Recyclable packaging material: 100 %
Specific Substances:
- Mercury free
- PVC / BFR free housing
Cabinet
Finish: Texture
Foot: Black
Front bezel: Black
Rear cover: Black
|
