| specifications |
| CPU Socket:
|
LGA 1700
|
| CPU Support:
|
14th, 13th, and 12th Gen Intel Core, Pentium Gold, and Celeron processors
|
| Chipset:
|
Intel B760 Express Chipset
|
| Memory: |
|
| 4 x DDR4 DIMM sockets |
| Up to 128 GB total system memory
|
| Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s
|
| Dual Channel memory architecture
|
| Supports ECC/Non-ECC Un-buffered DIMM memory modules
|
| Supports Extreme Memory Profile (XMP)
|
| Onboard Graphics: |
| Supports integrated Intel HD Graphics (CPU dependent)
|
| 1 x HDMI 2.1 port (4096x2160@60Hz)
|
| 2 x DisplayPort 1.2 (4096x2304@60Hz)
|
| Up to quad-display support
|
| Storage: |
|
| 2 x PCIe 4.0 x4 M.2 connectors with M.2 Thermal Guard
|
| Multiple SATA ports (specific number may vary by revision, but typically multiple)
|
| Networking: |
| Realtek 2.5GbE LAN
|
| For models with "AX" in the name (like B760M-DS3H-AX), includes Wi-Fi 6E 802.11ax and Bluetooth
|
| Expansion Slots: |
| PCIe 4.0 x16 slot with EZ-Latch quick release design
|
| Rear Panel: |
| Includes USB-C® 10Gb/s (USB 3.2 Gen 2) port on some models
|
| USB 3.2 Gen 1 ports
|
| HDMI and DisplayPort ports
|
| Audio: |
|
| Realtek® Audio CODEC |
| Audio Noise Guard, high-end audio capacitors
|
| Support for 2/4/5.1/7.1-channel audio
|
| Cooling: |
|
| Smart Fan 6 with multiple temperature sensors and hybrid fan headers
|
| Fan Stop feature
|
| BIOS: Q-Flash Plus for updating BIOS without a CPU, RAM, or GPU installed
|
