SilverStone SST-ST70F-ES230 Strider Essential 700W 80+ APFC Non-Modular PSU

Description


Designed for 80 PLUS level of efficiency to reduce wasted heat and save on electricity.   Built-in 120mm fan has excellent airflow and low noise, perfect for quiet home or office use.



Powerful single +12V rail design, perfect for future high-end component upgrades or overclocking.   Compact 140mm depth design for easier installation in small from factor.

Product Specifications
Product No.
SST-ST70F-ES230
Color
Black（Lead-Free Paint）
Max. DC Output
700W
Power density
388W per liter
Load Range
Output +3.3V +5V +12V +5VSB -12V
Max.(Amps) 22A 22A 54A 2.5A 0.3A
Peak (Amps) / / / / /
Min.(Amps) 0A 0A 0A 0A 0A
Range (%) ±5% ±5% ±5% ±5% ±10%
Line Reg.(%) ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p) 50mV 50mV 120mV 50mV 120mV
Combined +3.3V & +5V
130W
Combined +12V
648W
Input Voltage
180V~264V
Input Frequency Range
47Hz~63Hz
PFC
Active PFC（PF>0.9 at full load）
Efficiency
82% ~ 85% at 20% ~ 100% loading
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over power protection

Over voltage protection

Short circuit protection
Connectors
1 x 24 / 20-Pin motherboard connector（500mm）

1 x 8 / 4-Pin EPS / ATX 12V connector（750mm）

4 x 8 / 6-Pin PCIE connector（"500mm / 150mm" x 2）

4 x SATA connector（"500mm / 150mm" x 2）

3 x 4-Pin Peripheral connector（500mm / 150mm / 150mm）

1 x 4-Pin Floppy connector（500mm / 150mm / 150mm / 150mm）
Cooling System
Single 120mm silent fan
Noise Level
18 dBA minimum
Certification
80 PLUS
Form factor
ATX
Dimension
150 mm (W) x 86 mm (H) x 140 mm (D)
Weight
1.43 kg
Other
  • High efficiency with 80 PLUS certification
  • 24/7 continuous power output with 40℃ operating temperature
  • Class-leading single +12V rail
  • Active PFC Circuitry
  • PCI-E 8pin and PCI-E 6pin connector support
  • Silent running 120mm fan with 18dBA
