Description
|
General Specifications
|
|
Platform
|
|
Boxed Processor
|
|
Product Family
AMD Ryzen™ Processors
Product Line
AMD Ryzen™ 7 Desktop Processors
# of CPU Cores
8
# of Threads
16
Max. Boost Clock
Up to 4.7GHz
Base Clock
3.8GHz
L2 Cache
4MB
L3 Cache
32MB
Default TDP
105W
Processor Technology for CPU Cores
TSMC 7nm FinFET
Unlocked for Overclocking
Yes
CPU Socket
AM4
Thermal Solution (PIB)
Not included
Recommended Cooler
Premium air cooler recommended for optimal performance
Max. Operating Temperature (Tjmax)
90°C
Launch Date
11/5/2020
*OS Support
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
PCI Express® Version
PCIe 4.0
System Memory Type
DDR4
System Memory Specification
Up to 3200MT/s
Graphics Capabilities
Integrated Graphics
No
Graphics Model
Discrete Graphics Card Required
Product IDs
Product ID Boxed
100-100000063WOF
Product ID Tray
100-000000063
Key Features
Supported Technologies
AMD StoreMI Technology
AMD "Zen 3" Core Architecture
AMD Ryzen™ Master Utility
AMD Ryzen™ VR-Ready Premium
4/4/2022
*OS Support
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.
Connectivity
USB Type-C® Support
Yes
Native USB 3.2 Gen 2 (10Gbps) Ports
4
Native USB 3.2 Gen 1 (5Gbps) Ports
0
Native USB 2.0 (480Mbps) Ports
0
Native SATA Ports
2
PCI Express® Version
PCIe 4.0
Native PCIe® Lanes (Total/Usable)
24 / 20
Additional Usable PCIe Lanes from Motherboard
AMD X570
16x Gen 4
AMD X470
2x Gen 3
AMD X470
8x Gen 2
NVMe Support
Boot, RAID0, RAID1, RAID10
System Memory Type
DDR4
Memory Channels
2
Max. Memory
128GB
System Memory Subtype
UDIMM
System Memory Specification
Up to 3200MT/s
Max Memory Speed
2x1R
DDR4-3200
2x2R
DDR4-3200
4x1R
DDR4-2933
4x2R
DDR4-2667
ECC Support
Yes (Requires mobo support)
Graphics Capabilities
Integrated Graphics
No
Graphics Model
Discrete Graphics Card Required
Product IDs
Product ID Boxed
100-100000926WOF
Product ID Tray
100-000000926
Key Features
Supported Technologies
AMD StoreMI Technology
AMD Ryzen™ VR-Ready Premium
