Specifications
Model Parameters - C6N
Model
CS-C6N-A0-1C2WFR
Camera
Image Sensor
1/4" Progressive Scan CMOS
Shutter Speed
Self-adaptive shutter
Lens
4mm@ F2.4, view angle: 85° diagonal, 75° horizontal, 45° vertical
Lens Mount
M12
Day & Night
IR-cut filter with auto-switching
DNR
3D DNR
WDR
Digital WDR
Compression
Video Compression
H.264
Video Bit Rate
Full HD, HD, Standard. Adaptive bit rate.
Max. Resolution
1920 × 1080
Frame Rate
Max. 15fps; Self-adaptive during network transmission
Network
Smart Alarm
Motion detection
Wi-Fi Pairing
AP Pairing
Protocol
EZVIZ Cloud Proprietary Protocol
Interface Protocol
EZVIZ Cloud Proprietary Protocol
Interface
Storage
MicroSD card slot (Max. 256 GB)
Power
Micro USB
Wired Network
RJ45 X 1 (10M/100M self-adaptive Ethernet port)
Wi-Fi
Standard
IEEE802.11 b/g/n
Frequency Range
2.4 GHz ~ 2.4835 GHz
Channel Bandwidth
Supports 20MHz
Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Transmission Rate
11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps
General
Power Supply
DC 5V/1A
Power Consumption
5W max
IR Range
MAX. 10m (32.81 fts)
Dimensions
88 mm x 88.2 mm x 119 mm (3.46” x 3.47” x 4.69”)
Packaging Dimensions
103 mm x 103 mm x 168 mm (4.06” x 4.06” x 6.61”)
Bare Weight
218g (0.48lb)
Packaging Contents
Packaging Contents
C6N camera; Base; Screw Kit; Power Cable 3m (9.8 ft.); Drill Template; Power Adapter; Quick Start Guide
Operating Environment
Temperature
-10° C to 45° C (14° F to 113° F)
Humidity
95% or less (non-condensing)
Certifications
Certifications
FCC / UL / CE / WEEE / REACH / RoHS
