LS520
The DeepCool LS520 premium liquid CPU cooler maximizes cooling performance and low-noise efficiency with a 240mm radiator, two FC120 A-RGB PWM fans, and an infinity mirror cap design.
LS520 Elite performance
The DeepCool LS520 premium liquid CPU cooler maximizes cooling performance and low-noise efficiency with a 240mm radiator, two FC120 A-RGB PWM fans, and an infinity mirror cap design.
A New Era of DeepCool
Built on our 4th Generation high-performance water pump that maximizes cooling performance featuring:
Improved microchannel design ensures optimal coolant flow.
Powerful three-phase drive motor up to 3100 RPM.
Thick solid copper base with a seamless match.
Cool and Quiet
Get treated to excellent cooling and superb silent efficiency with the included FC120 fans boasting enhanced static pressure, concentrated airflow, and a fluid dynamic bearing.
500~2250 RPM *
Dynamic PWM Range
85.85 CFM
Supreme Airflow
TECHNICAL SPECIFICATIONS:
Net Weight
1305 g
Radiator Dimensions
282×120×27 mm(L×W×H)
Radiator Material
Aluminum
Tube length
410 mm(L×W×H)
Pump Dimensions
86×74×57 mm(L×W×H)
Pump Speed
3100 RPM±10%
Pump Noise
19 dB(A)
Pump Connector
3-pin
Pump Rated Voltage
12 VDC
Pump Rated Current
0.47 A
Pump Power Consumption
5.64 W
Fan Dimensions
120×120×25 mm(L×W×H)
Fan Speed
500~2250 RPM±10%
Fan Airflow
85.85 CFM
Fan Air Pressure
3.27 mmAq
Fan Noise
≤32.9 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Fluid Dynamic Bearing
Fan Rated Voltage
12 VDC
Fan Rated Current
0.29 A
Fan Power Consumption
3.48 W
LED Type
Addressable RGB LED
LED Connector
3-pin(+5V-D-G)
LED Rated Voltage
5 VDC
LED Power Consumption
2.2 W(PUMP)/ 3.6 W(FAN×2)
EAN
6933412727484
P/N
R-LS520-BKAMNT-G-1
Unlocked potential
Achieve peak performance on your CPU with substantial cooling capacity for high frequency overclocking. The AK620 features a maximum heat dissipation power of 260W and improved airflow to lower temperatures during demanding system applications.
Cool, quiet, and powerful
Two 120 PWM fans with superior fluid dynamic bearings offer low noise operation without losing cooling output for a perfect balance.
Exceptional cooling by design
The AK620 features a precision-machined convex copper base and six copper heat pipes that deliver improved heat transfer capabilities. The dense matrix fin array in a dual tower heat sink layout offers better efficiency for high performance systems.
Multi-platform simplicity
The all-metal mounting bracket kit provides a sturdy and easy installation process for both Intel and AMD platforms with additional tools included.
TECHNICAL SPECIFICATIONS:
Product Dimensions:
129×138×160 mm(L×W×H)
Heatsink Dimensions:
127×110×157 mm(L×W×H)
Net Weight:
1456 g
Heatpipe:
Ø6 mm×6 pcs
Fan Dimensions:
120×120×25 mm(L×W×H)
Fan Speed:
500~1850 RPM±10%
Fan Airflow:
68.99 CFM
Fan Air Pressure:
2.19 mmAq
Fan Noise:
≤28 dB(A)
Fan Connector:
4-pin PWM
Bearing Type:
Fluid Dynamic Bearing
Fan Rated Voltage:
12 VDC
Fan Rated Current:
0.12 A
Fan Power Consumption:
1.44 W
EAN:
6933412727316
P/N:
R-AK620-BKNNMT-G
AK620 DIGITAL
The era of digital air coolers has arrived, and DeepCool is proud to introduce the AK620 DIGITAL. Everything you loved about the AK620 ZERO DARK, but with a sleek low-profile magnetic status display and ARGB LED strips.
REAL-TIME STATUS SCREEN
The crystal-clear digital screen displays the temperature and usage of your system's CPU in real time, and there is also a high temperature warning. The display is controlled via a simple application that only requires an open USB 2.0 header.
PROVEN AK ZERO DARK DESIGN
An all-black edition of the dominant AK620 high-performance CPU cooler. The same premium quality materials, featuring six advanced copper heat pipes, a pure copper cold plate, a dense dual-tower heat sink, and two silent FDB fans, produce a powerful winning formula for high performance cooling in a ZERO DARK raven design.
COOL, QUIET, AND POWERFUL
Two powerful PWM fans with superior fluid dynamic bearings offer low noise operation without losing cooling output for a perfect balance.
SIMPLE AND SECURE INSTALLATION
The provided all metal mounting bracket provides an easy installation process that ensures proper contact and equal pressure on both Intel and AMD platforms.
TECHNICAL SPECIFICATIONS:
Product Dimension:
129×138×162 mm(L×W×H)
Heatsink Dimensions:
127×110×157 mm(L×W×H)
Net Weight:
1486 g
Heatpipe:
Ø6 mm×6 pcs
Fan Dimensions:
120×120×25 mm(L×W×H)
Fan Speed:
500~1850 RPM±10%
Fan Airflow:
68.99 CFM
Fan Air Pressure:
2.19 mmAq
Fan Noise:
≤28 dB(A)
Fan Connector:
4-pin PWM
Bearing Type:
Fluid Dynamic Bearing
Fan Rated Voltage:
12 VDC
Fan Rated Current:
0.12 A
Fan Power Consumption:
1.44 W
LED Type:
Addressable RGB LED
LED Connector:
3-pin(+5V-D-G) and 9-pin USB 2.0
LED Rated Voltage:
5 VDC
LED Power Consumption:
4.75 W
EAN:
6933412728221
P/N:
R-AK620-BKADMN-G
Application For:
Intel:
LGA2066/2011-v3/2011/1700/1200/1151/1150/1155
AMD:
AM5/AM4
Technical Specifications:
Product Dimensions:
127×1117×160 mm(L×W×H)
Heatsink Dimensions:
127×92×156 mm(L×W×H)
Net Weight:
1291 g
Heat pipe:
Ø6 mm×5 pcs
Fan Dimensions:
120×120×25 mm(L×W×H)
Fan Speed:
500~1850 RPM±10%
Fan Airflow:
68.99 CFM
Fan Air Pressure:
2.19 mmAq
Fan Noise:
≤28 dB(A)
Fan Connector:
4-pin PWM
Bearing Type:
Fluid Dynamic Bearing
Fan Rated Voltage:
12 VDC
Fan Rated Current:
0.12 A
Fan Power Consumption:
1.44 W
LED Type:
Addressable RGB LED
LED Connector:
3-pin(+5V-D-G) and 9-pin USB 2.0
LED Rated Voltage:
5 VDC
LED Power Consumption:
4.75 W
EAN:
6.93341E+12
P/N:
R-AK500-BKADMN-G
Product Description:
The Deepcool AK400 is a highly compatible CPU cooler featuring a classic four heat pipe tower layout with a unique matrix fin design and a high-performance FDB fan that delivers excellent heat dissipation and extremely low noise levels.
Application For:
Intel
LGA1700/1200/1151/1150/1155AMDAM4
Technical Specifications:
Product Dimensions:
127×97×155 mm
Heatsink Dimensions:
20×45×152 mm
Net Weight:
661 g
Heat pipe:
Ø6 mm×4 pcs
Fan Dimensions:
120×120×25 mm
Fan Speed:
500~1850 RPM±10%
Fan Airflow:
66.47 CFM
Fan Air Pressure:
2.04 mmAq
Fan Noise:
≤29 dB(A)
Fan Connector:
4-pin PWM
Bearing Type:
Fluid Dynamic Bearing
Fan Rated Voltage:
12 VDC
Fan Rated Current:
0.13 A
Fan Power Consumption:
1.56
Product Details:
The DeepCool Gammaxx AG620 120mm Dual Tower CPU Cooler is designed for gamers and PC enthusiasts seeking optimal cooling performance.
It's dual tower design enhances heat dissipation, ensuring your CPU runs at peak efficiency during intense gaming sessions.
With a sleek aesthetic, it complements any build while providing reliable cooling.
The cooler is compatible with a variety of CPU sockets, making it a versatile choice for different setups.
Enjoy peace of mind with a local supplier warranty, ensuring quality and support for your investment.
Specifications:
Product Dimensions:
129×136×157 mm
Heatsink Dimensions:
127×110×157 mm
Net Weight:
1300 g
Heat pipe:
Ø6 mm×6 pcs
Fan Dimensions:
120×120×25 mm
Fan Speed:
300~1850 RPM±10%
Fan Airflow:
67.88 CFM
Fan Air Pressure:
2.04 mmAq
Fan Noise:
≤29.4 dB(A)
Fan Connector:
4-pin PWM
Bearing Type:
Hydro Bearing
Fan Rated Voltage:
12 VDC
Fan Rated Current:
0.14 A
Fan Power Consumption:
1.68 W
EAN:
6.93341E+12
P/N:
R-AG620-BKNNMN-G-1
Product Descriptions:
Black top cover with A-RGB logo.
120mm PWM fan with upgraded performance and A-RGB lighting.
Lighting system can be controlled by either included wire controller or motherboard.
4 new-tech copper pipes improve heat transfer and dissipation efficiency.
The new fin-mounting process elevate ventilation.
The brand-new foolproof mounting kit makes GAMMAXX GT A-RGB easier and safer to use.
Specifications:
Application For Intel
LGA2066/2011-v3/2011/LGA1200/1151/1150/1155/1366
AMD
AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1
Product Dimensions
129×86×158mm
Heatsink Dimensions
127×50×155 mm
Net Weight
676 g
Heatpipe
Ø6 mm×4 pcs
Fan Dimensions
120×120×25mm
Fan Speed
500~1650 RPM±10%
Fan Airflow
64.5 CFM
Fan Air Pressure
2.1 mmAq
Fan Noise
≤27.8 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Hydro Bearing
Fan Rated Voltage
12 VDC
Fan Rated Current
0.14 A
Fan Power Consumption
1.68 W
LED Type
Addressable RGB LED
LED Connector
3-pin(+5V-D-G)
LED Rated Voltage
5 VDC
LED Power Consumption
2.2 W
Application For
Intel
LGA1851/1700/1200/1151/1150/1155
AMD
AM5/AM4
Technical Spec
Product Dimensions
125×95×155 mm(L×W×H)
Heatsink Dimensions
120×93×150 mm(L×W×H)
Net Weight
861 g
Heatpipe
Ø6 mm×5 pcs
Fan Dimensions
120×120×25 mm(L×W×H)
Fan Speed
300~1850 RPM±10%
Fan Airflow
67.88 CFM
Fan Air Pressure
2.04 mmAq
Fan Noise
≤29.4 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Hydro Bearing
Fan Rated Voltage
12 VDC
Fan Rated Current
0.14 A
Fan Power Consumption
1.68 W
LED Type
Addressable RGB LED
LED Connector
3-pin(+5V-D-G)
LED Rated Voltage
5 VDC
LED Power Consumption
1.05 W
EAN
6933412727873
P/N
R-AG500-BKANMN-G-1
Application For
Intel
LGA2066/2011-v3/2011/1851/1700/1200/1151/1150/1155
AMD
sTRX4/sTR4/AM5/AM4
Technical Spec
Net Weight
1607 g
Radiator Dimensions
402×120×27 mm(L×W×H)
Radiator Material
Aluminum
Tube length
410 mm(L×W×H)
Pump Dimensions
86×74×57 mm(L×W×H)
Pump Speed
3100 RPM±10%
Pump Noise
19 dB(A)
Pump Connector
3-pin
Pump Rated Voltage
12 VDC
Pump Rated Current
0.47 A
Pump Power Consumption
5.64 W
Fan Dimensions
120×120×25 mm(L×W×H)
Fan Speed
500~2250 RPM±10%
Fan Airflow
85.85 CFM
Fan Air Pressure
3.27 mmAq
Fan Noise
≤32.9 dB(A)
Fan Connector
4-pin PWM
Bearing Type
Fluid Dynamic Bearing
Fan Rated Voltage
12 VDC
Fan Rated Current
0.29 A
Fan Power Consumption
3.48 W
LED Type
Addressable RGB LED
LED Connector
3-pin(+5V-D-G)
LED Rated Voltage
5 VDC
LED Power Consumption
2.2 W(PUMP)/ 5.4 W(FAN×3)
EAN
6933412727644
P/N
R-LS720-WHAMNT-G-1
Twister DXV2.6 240 Liquid CPU Cooler
Redesign water pump infinity mirror with 360 degree rotation
Cooling fans synchronizable with most motherboards.
Dense liquid channels for a better cooling effect.
Supports both Intel and AMD
TDP : 275W
Main Spec
Water Block Size :78.5 x 70 x 54mm
Radiator Size:274 x 120 x 27mm
Pipe Length:400mm
Block Speed:2700±10%RPM
Rate Voltage:12V
Start Voltage:6V
Rate Current:0.35A
Power Comsumption:4.20W
Fan Spec
Fan Size:120 x 120 x 25mm
Fan Rated Voltage:12V
Fan Start Voltage:6V
Fan Speed:800~1800RPM
Fan Rated Current:0.65A
Air Flow:51CFM±10%
Air Pressure:1.5mm H2O
Noise Level:32dBA±10%
Socket
Intel:LGA 20xx(v3)1200115x17xx
AMD:AM5AM4AM3(+)AM2(+)FM2(+)
Radiant DC 360 Liquid CPU Cooler
Elegantly rhombus diverages infinitely outward design
Redesign water pump make perfevt and stability performance
High strength cooling pipes
Supports both Intel and AMD
TDP : 280W
Main Spec
Water Block Size :71 x 66.5 x 45mm
Radiator Size:394 x 120 x 27mm
Pipe Length: 450mm
Block Speed:3200±10%RPM
Rate Voltage:12V
Start Voltage:6V
Rate Current:0.60A
Power Comsumption:7.20W
Fan Spec
Fan Size:120 x 120 x 25mm
Fan Rated Voltage:12V
Fan Start Voltage:6V
Fan Speed: 800~2000±10%RPM
Fan Rated Current:0.26A
Air Flow:84.2CFM
Air Pressure:2.54mmH2O
Noise Level:16.0-30.15dBA
Socket
Intel:LGA 20xx(v3)1200115x17xx
AMD:AM5AM4AM3(+)AM2(+)FM2(+)
