Core Specifications Cores:  6 Threads:  12 Base Clock:  3.6 GHz Max Boost Clock:  Up to 4.2 GHz L1 Cache:  384KB L2 Cache:  3MB L3 Cache:  16MB Total Cache:  19MB (384KB + 3MB + 16MB) TDP:  65W  Platform and Connectivity Socket:  AM4 Architecture:  Zen 3 PCI Express Version:  PCIe 3.0 Max Memory Speed:  DDR4-3200 Number of Memory Channels: 2 Other Features Integrated Graphics:  No, a discrete GPU is required Unlocked for Overclocking:  Yes Thermal Solution:  AMD Wraith Stealth cooler included Supported Chipsets:  X570, X470, X370, B550, B450, B350, A520 OS Support:  Windows 11, 64-Bit Edition; Windows 10, 64-Bit Edition; RHEL x86 64-Bit; Ubuntu x86 64-Bit

Read more less

SPECIFICATIONS AMD Ryzen™ 5 5600G Platform: Desktop Integrated Graphics:  Yes Graphics Model:  Radeon™ Graphics Graphics Core Count: 7 Graphics Frequency: 1900MHz Number of CPU Cores: 6 Number of Threads: 12 Multithreading (SMT): Yes Base Clock: 3.9GHz Max Boost Clock: Up to 4.4GHz L2 Cache: 3MB L3 Cache: 16MB Default TDP:  65W AMD Configurable TDP (cTDP): 45-65W Processor Technology for CPU Cores: TSMC 7nm FinFET CPU Socket:  AM4 Unlocked for Overclocking: Yes Supported Chipsets: X570 | X470 | X370 | B550 | B450 | B350 | A520 Thermal Solution (PIB): Wraith Stealth Max Operation Temperature: 95°C OS Support Windows 11:  64-Bit Edition Windows 10:  64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit Operating System (OS) support will vary by manufacturer. Connectivity PCI Express® Version: PCIe 3.0 PCIe Lanes (Total/Usable): 24 / 20 System Memory Type: DDR4 Memory Channels: 2 System Memory Specifications: Up to 3200MHz

Read more less

AMD Ryzen™ 5 5600 General Specifications Platform Desktop Product Family AMD Ryzen™ Processors Product Line AMD Ryzen™ 5 Desktop Processors # of CPU Cores 6 # of Threads 12 Max. Boost Clock Up to 4.4GHz Base Clock 3.5GHz L1 Cache 384KB L2 Cache 3MB L3 Cache 32MB Default TDP 65W Processor Technology for CPU Cores TSMC 7nm FinFET Unlocked for Overclocking Yes CPU Socket AM4 Socket Count 1P Thermal Solution (PIB) AMD Wraith Stealth Max. Operating Temperature (Tjmax) 90°C Launch Date 4/4/2022 *OS Support Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. Connectivity PCI Express® Version PCIe 4.0 System Memory Type DDR4 Memory Channels 2 System Memory Specification Up to 3200MT/s Max Memory Speed 2x1R DDR4-3200 2x2R DDR4-3200 4x1R DDR4-2933 4x2R DDR4-2667 Product IDs Product ID Boxed 100-100000927BOX Product ID Tray 100-000000927 Key Features Supported Technologies AMD StoreMI Technology AMD Ryzen™ VR-Ready Premium

Read more less

Base Clock:  3.9 GHz Max. Boost Clock:  Up to 4.4 GHz Total L2 Cache:  3MB Total L3 Cache:  16MB  Graphics Graphics Model:  Radeon Graphics Graphics Core Count:  7 Graphics Frequency:  1900 MHz  General and power TDP:  65W cTDP:  45-65W (configurable) Processor Technology:  7nm FinFET CPU Socket:  AM4 Unlocked for Overclocking:  Yes  Memory support System Memory Specification:  Up to 3200MHz System Memory Type:  DDR4 Memory Channels:  2 Other features PCIe Version:  PCIe 3.0 Thermal Solution (PIB):  Wraith Stealth cooler OS Support:  Windows 10, Windows 11, RHEL x86 64-bit, Ubuntu x86 64-bit

Read more less

General Specifications Platform Desktop Market Segment Enthusiast Desktop Product Family AMD Ryzen™ Processors Product Line AMD Ryzen™ 7 Desktop Processors Consumer Use Yes Regional Availability Global, China, NA, EMEA, APJ, LATAM # of CPU Cores 8 Multithreading (SMT) Yes # of Threads 16 Max. Boost Clock Up to 4.6GHz Base Clock 3.4GHz L1 Cache 512KB L2 Cache 4MB L3 Cache 32MB Default TDP 65W Processor Technology for CPU Cores TSMC 7nm FinFET Processor Technology for I/O Die 12nm (Globalfoundries) CPU Compute Die (CCD) Size 74mm² I/O Die (IOD) Size 125mm² Package Die Count 2 Unlocked for Overclocking Yes CPU Socket AM4 Socket Count 1P Supporting Chipsets X570 X470 X370 B550 B450 B350 A520 CPU Boost Technology Precision Boost 2 Instruction Set x86-64 Supported Extensions AES, AMD-V, AVX, AVX2, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 Thermal Solution (PIB) Not included Max. Operating Temperature (Tjmax) 90°C Launch Date 4/4/2022 *OS Support Windows 11 - 64-Bit Edition Windows 10 - 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit *Operating System (OS) support will vary by manufacturer. Connectivity USB Type-C® Support Yes Native USB 3.2 Gen 2 (10Gbps) Ports 4 Native USB 3.2 Gen 1 (5Gbps) Ports 0 Native USB 2.0 (480Mbps) Ports 0 Native SATA Ports 2 PCI Express® Version PCIe 4.0 Native PCIe® Lanes (Total/Usable) 24 / 20 Additional Usable PCIe Lanes from Motherboard AMD X570 16x Gen 4 AMD X470 2x Gen 3 AMD X470 8x Gen 2 NVMe Support Boot, RAID0, RAID1, RAID10 System Memory Type DDR4 Memory Channels 2 Max. Memory 128GB System Memory Subtype UDIMM System Memory Specification Up to 3200MT/s Max Memory Speed DDR4-3200 2x1R DDR4-3200 2x2R DDR4-2933 4x1R DDR4-2667 4x2R ECC Support Yes (Requires mobo support) ECC Support Graphics Capabilities Integrated Graphics No Graphics Model Discrete Graphics Card Required Product IDs Product ID Boxed 100-100000926WOF Product ID Tray 100-000000926 Key Features Supported Technologies AMD StoreMI Technology AMD Ryzen™ VR-Ready Premium

Read more less

F5-6400J3239G16GX2-TZ5NRW Trident Z5 Neo RGBDDR5-6400 CL32-39-39-102 1.40V32GB (2x16GB)AMD EXPO Trident Z5 Neo RGB DDR5 memory is designed for ultra-high overclocked performance on DDR5-enabled AMD platforms. Featuring AMD EXPO overclocking technology for easy memory overclocking on supported AMD platforms, the Trident Z5 Neo RGB series is the ideal choice for building high-performance systems.Check memory compatibility for your motherboard with the RAM Configurator tool, or check the QVL for a list of compatible motherboards with this memory kit.   Specification:  Memory Type DDR5 Capacity 32GB (16GBx2) Multi-Channel Kit Dual Channel Kit OC Profile Support AMD EXPO Tested Speed (EXPO) 6400 MT/s Tested Latency (EXPO) 32-39-39-102 Tested Voltage (EXPO) 1.40V Registered/Unbuffered Unbuffered Error Checking (ECC) Non-ECC SPD Speed (Default) 4800 MT/s SPD Voltage (Default) 1.10V Fan Included No Features AMD EXPO Profile Ready Additional Notes Do not mix memory kits. Memory kits are sold in matched kits that are designed to run together as a set. Mixing memory kits will result in stability issues or system failure. Memory kits that are "Intel XMP 3.0 Ready" / "AMD EXPO Profile Ready" includes support for the respective OC profile. Prior to enabling XMP or EXPO, memory kits will boot at default BIOS settings with compatible hardware. For memory kits with XMP or EXPO, enable XMP/EXPO/DOCP/A-XMP profile in BIOS to reach the rated potential XMP or EXPO overclock speed of the memory kit, subject to the use of compatible hardware. Please refer to the "How to Enable XMP/EXPO" guide. Reaching the rated XMP/EXPO overclock speed and system stability will depend on the compatibility and capability of the motherboard and CPU used. Usage in any manner inconsistent with manufacturer specifications, warnings, designs, or recommendations will result in lower speeds, system instability, or damage to the system or its components. Memory module height can be found in the FAQ, under the question "How tall are the memory modules?". For product support and related questions, please contact the G.SKILL technical support team via email.

Read more less

Feature Specification GPU AMD Radeon™ RX 7800 XT Process Node 5nm Architecture AMD RDNA™ 3 Engine Clock Boost: Up to 2430 MHz Game: Up to 2124 MHz Stream Processors 3840 Compute Units 60 CU (with RT+AI Accelerators) Infinity Cache 64MB Ray Accelerators 60 Memory Size / Bus 16GB / 256-bit GDDR6 Memory Clock 19.5 Gbps Effective Displays Supported Maximum 4 Displays Resolution HDMI™: 7680×4320 DisplayPort 2.1: 7680×4320 Interface PCI-Express 4.0 x16 Output Ports 2 × HDMI, 2 × DisplayPort BIOS Support UEFI Game Index 4K Sapphire Features Digital Power Design, Ultra High Performance Conductive Polymer Aluminum Capacitors, Fuse Protection, High TG Copper PCB, Optimized Composite Heatpipe, Dual-X Cooling Technology, Intelligent Fan Control, Precision Fan Control, Metal Backplate, Angular Velocity Fan Blade, Dual-Ball Bearing Fans, TriXX Supported, TriXX Boost AMD Features RDNA™ 3 Architecture, 60 Compute Units, 64MB Infinity Cache, DisplayPort 2.1 Support, Radiance Display Engine, 16GB GDDR6 on 256-Bit Memory Bus, PCI® Express 4.0 Ready, FidelityFX™ Super Resolution, DirectX® 12 Ultimate, DirectStorage, Vulkan® Optimized, AMD Smart Technologies, Adrenalin Edition Software, Noise Suppression, Privacy View, Radeon™ Super Resolution, AMD Link, FreeSync™ Cooler Type 2 Fans Form Factor 2.5-slot, ATX Dimensions (L×W×H) 280 × 128.75 × 52.57 mm Power Consumption 266W Total Board Power OS Support Linux®, Windows® 10/11 64-bit System Requirements Minimum 700W PSU, 2 × 8-pin Power Connector, PCIe x16 Slot, 8GB RAM (16GB Recommended)

Read more less

Specification Details Brand AMD Model RYZEN 5 7600 Series AMD Ryzen™ 5 Processors CPU Socket Type AM5 Core Name Raphael AM5 Max Turbo Frequency 5.1 GHz Manufacturing Tech 5 nm Memory Types DDR5 Memory Channel 2 Thermal Design Power 65 W

Read more less

AMD A520 Motherboard with Pure Digital VRM Solution, High Quality Audio, GIGABYTE Gaming LAN with Bandwidth Management, PCIe 3.0 x4 M.2, Intel Dual Band 802.11ac WIFI, RGB FUSION 2.0, Smart Fan 5, Q-Flash Plus Supports AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors Dual Channel ECC/ Non-ECC Unbuffered DDR4, 4 DIMMs 5+3 Phases Pure Digital VRM Solution with Low RDS(on) MOSFETs Ultra-Fast NVMe PCIe 3.0 x4 M.2 Connector Onboard Intel® Dual Band 802.11ac Wireless & BT 4.2 with WIFI Antenna GIGABYTE Exclusive 8118 Gaming LAN with Bandwidth Management HDMI, DVI-D, Display Ports for Multiple Display RGB FUSION 2.0 Supports Addressable LED & RGB LED Strips Smart Fan 5 Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP Q-Flash Plus Update BIOS without Installing the CPU, Memory and Graphics Card Category Specification CPU AMD Socket AM4, support for Ryzen™ 5000 Series / Ryzen™ 5000 G-Series / Ryzen™ 4000 G-Series / Ryzen™ 3000 / Ryzen™ 3000 G-Series Processors (Refer to CPU Support List) Chipset AMD A520 Memory 4 x DDR4 DIMM sockets, up to 128 GB total (32 GB per DIMM); Dual channel; Supports ECC and non-ECC unbuffered memory; XMP supported Supported Memory Speeds Up to DDR4 4733(O.C.) depending on CPU model Onboard Graphics 1 x DVI-D (1920x1200@60Hz), 1 x DisplayPort (5120x2880@60Hz), 1 x HDMI (4096x2160@60Hz); Supports up to 3 displays Audio Realtek® Audio CODEC, High Definition Audio, 2/4/5.1/7.1-channel support LAN Realtek® GbE LAN (1 Gbps / 100 Mbps) Wireless Communication Intel® Wireless-AC 3168 (Wi-Fi 5, Bluetooth 4.2) or Intel® Wireless-AC 9260 (Wi-Fi 5, Bluetooth 5.1) or Realtek® RTL8821CE (Wi-Fi 5, Bluetooth 5.0) depending on PCB revision Expansion Slots 1 x PCIe 3.0 x16 slot (CPU), 2 x PCIe 3.0 x1 slots (Chipset) Storage Interface 1 x M.2 (PCIe 3.0 x4/x2 & SATA), 4 x SATA 6Gb/s ports, supports RAID 0/1/10 USB Ports Rear: 4 x USB 3.2 Gen 1, 2 x USB 2.0; Internal: 2 x USB 3.2 Gen 1, 2 x USB 2.0 Internal I/O 24-pin ATX, 8-pin CPU, CPU fan, 2 system fan headers, RGB/ARGB headers, front panel audio, SATA, USB headers, TPM, serial port, Q-Flash Plus button Back Panel I/O PS/2 combo, DVI-D, DisplayPort, HDMI, 2 x SMA antenna connectors, 4 x USB 3.2 Gen 1, 2 x USB 2.0, RJ-45, 3 x audio jacks I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage, temperature, and fan speed detection; Fan speed and failure warnings BIOS 128 Mbit flash, AMI UEFI BIOS, supports Q-Flash and Q-Flash Plus Unique Features GIGABYTE APP Center, @BIOS, EasyTune, RGB Fusion, Smart Backup, System Information Viewer Bundled Software Norton® Internet Security (OEM), LAN Bandwidth Management Software Operating System Windows 10 64-bit, Windows 11 64-bit Form Factor Micro ATX (24.4 cm x 24.4 cm)

Read more less

Feature Specification Brand AMD Model AMD Ryzen 5 3400G with Radeon RX Vega 11 Graphics Series AMD Ryzen 5 Desktop Processors with Radeon Vega Graphics CPU Socket Type AM4 Core Name Picasso Max Turbo Frequency 4.2 GHz Manufacturing Technology 12nm Memory Types DDR4 2933 Memory Channel 2 Thermal Design Power (TDP) 65W # of Cores 4 # of Threads 8 Operating Frequency 3.7 GHz L1 Cache 384 KB L2 Cache 2 MB L3 Cache 4 MB Integrated Graphics AMD Radeon RX Vega 11 Graphics Base Frequency 1400 MHz PCI Express Revision 3.0 Max Number of PCI Express Lanes 8 Cooling Device Heatsink and fan included

Read more less

Description of AMD Ryzen 3 3200g 3.6GHz AM4 4-Core 4MB CPU w/o Fan: Cores:  4 Threads:  4 with SMT (Simultaneous Multithreading) Base Clock:  3.6 GHz Max Boost Clock:  Up to 4.0 GHz Cache:  4 MB L3 Cache Socket:  AM4 TDP (Thermal Design Power):  65W Memory Support:  DDR4-2933 MHz Integrated Graphics:  Yes (Radeon Vega 8 Graphics) CPU Cooler:  Not Included Manufacturing Process:  12nm FinFET Unlocker Multiplier:  No (not overclockable)

Read more less

Specification  Details CPU 4 Cores / 4 Threads Base Clock 3.6 GHz Max Boost Clock Up to 4.0 GHz Integrated Graphics AMD Radeon™ Vega 8 Graphics (8 GPU Cores) Graphics Frequency 1250 MHz L1 Cache 384 KB L2 Cache 2 MB L3 Cache 4 MB TDP 65W (AMD configurable TDP of 45-65W) Process Technology 12nm FinFET Socket AM4 Unlocked for Overclocking Yes Max. Operating Temperature 95°C Memory Support DDR4 Up to 2933 MHz, Dual Channel PCI Express® Version PCIe 3.0 x8 _____________________________________________________ Warranty Information: •     Item compatibility is buyer’s responsibility. •     For security purposes: Kindly secure unboxing video incase wrong item and defective upon received. •     Check all items upon receipt. •     All items/claims for warranty are carry-in. •     Tampered warranty sticker voids the warranty. •     Overclocking may void the warranty. •     Items for warranty must be complete with original contents/packaging and accompanied by warranty receipt. •     Defective items for warranty are subject for pull out and RMA services. (Shipping fee should be shoulder by customer)
