| CPU |
AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor |
| CPU Architecture |
64-bit x86 |
| Graphic Processors |
Optional via a PCIe adapter |
| Floating Point Unit |
✓ |
| Encryption Engine |
(AES-NI) |
| Hardware-accelerated Transcoding |
Optional via a PCIe adapter |
| System Memory |
8 GB SODIMM DDR4 (1 x 8 GB) |
| Maximum Memory |
64 GB (2 x 32 GB) |
| Memory Slot |
2 x SODIMM DDR4 |
| Support ECC memory |
Support ECC memory |
|
For dual-DIMM configurations, you must use a pair of identical DDR4 modules. |
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
8 x 3.5-inch SATA 6Gb/s, 3Gb/s |
| Drive Compatibility |
3.5-inch SATA hard disk drives |
|
2.5-inch SATA solid state drives |
| Hot-swappable |
✓ |
| M.2 Slot |
2 x M.2 2280 PCIe Gen3 x1 slots |
| SSD Cache Acceleration Support |
✓ |
| GPU pass-through |
✓ |
| 2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
2 (2.5G/1G/100M) |
| 5 Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional via a PCIe adapter |
| 10 Gigabit Ethernet Port |
Optional via a PCIe adapter |
| Wake on LAN (WOL) |
✓ |
| Jumbo Frame |
✓ |
| PCIe Slot |
2 |
|
Slot 1: PCIe Gen 3 x4 |
|
Slot 2: PCIe Gen 3 x4 |
| USB 3.2 Gen 2 (10Gbps) Port |
3 x Type-A USB 3.2 Gen 2 10Gbps |
|
1 x Type-C USB 3.2 Gen 1 5Gbps |
| HDMI™ Output |
Optional via a PCIe adapter |
| Form Factor |
Tower |
| LED Indicators |
Status/Power, USB, LAN, Drive 1-8, M.2 SSD 1-2 |
| Buttons |
Power, Reset, USB Auto Copy |
| Dimensions (HxWxD) |
180.2 × 329.3 × 279.6 mm |
|
Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
| Weight (Net) |
7.4 kg |
| Weight (Gross) |
8.3 kg |
| Operating Temperature |
0 - 40 °C (32°F - 104°F) |
| Storage Temperature |
-20 - 70°C (-4°F - 158°F) |
| Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Power Supply Unit |
250W, 100-240V AC, 50-60Hz, 3.5A |
| Power Consumption: HDD Sleep Mode |
25.668 W |
| Power Consumption: Operating Mode, Typical |
54.067 W |
|
Tested with drives fully populated. |
| Fan |
System fan: 2 x 120mm |
|
CPU fan: 1 x 60mm |
| System Warning |
Buzzer |
| Kensington Security Slot |
✓ |
