| Picture/Display |
| Panel Size |
21.5 inch / 54.6 cm
|
| Aspect ratio |
16:09
|
| LCD panel type |
VA LCD
|
| Backlight type |
W-LED system
|
| Pixel pitch |
0.2493 x 0.241 mm
|
| Brightness |
250 cd/m²
|
| Display colors |
16.7 M (8 bit)
|
| Contrast ratio (typical) |
3000:01:00
|
| SmartContrast |
Mega Infinity DCR
|
| Response time (typical) |
4 ms (GtG)*
|
| Viewing angle |
178º (H) / 178º (V) /@ C/R > 10
|
| Picture enhancement |
SmartImage
|
| Maximum resolution |
1920 x 1080 @ 120 Hz (Overclock) *
|
| Effective viewing area |
478.656 (H) x 260.28 (V)
|
| Scanning Frequency |
30k - 140 kHz (H) / VGA 48 - 60 Hz (V), HDMI 48-120 Hz
|
| sRGB |
Yes
|
| Flicker-free |
Yes
|
| Pixel Density |
102 PPI
|
| LowBlue Mode |
Yes
|
| Display Screen Coating |
Anti-glare, 3H, Haze 25%
|
| MPRT |
1 ms
|
| EasyRead |
Yes
|
| Adaptive sync |
Yes
|
| Connectivity |
| Signal Input |
VGA (Analog), HDMI 1.4
|
| Sync Input |
Separate Sync / Sync on Green
|
| Audio (In/Out) |
Audio out
|
| HDCP |
HDCP 1.4 (HDMI)
|
| Convenience |
| Plug & Play Compatibility |
DDC/CI / Mac OS X/ sRGB/ Windows 11 / 10 / 8.1 / 8
|
| User convenience |
Power On/Off /Menu/OK /Brightness/UP /Input/Down /SmartImage/Back
|
| Stand |
| Tilt |
-5/20 degree
|
| Power |
| Power supply |
Built-in /100-240VAC, 50-60Hz
|
| Off mode |
0.3 W (typ.)
|
| On mode |
14.8 W (typ.)
|
| Standby mode |
0.5 W (typ.)
|
| Power LED indicator |
Operation - White/ Standby mode- White (blinking)
|
| Dimensions |
| Product with stand (mm) |
493 x 369 x 220 mm
|
| Packaging in mm (WxHxD) |
570 x 436 x 109 mm
|
| Product without stand (mm) |
493 x 286 x 44 mm
|
| Weight |
| Product with packaging (kg) |
4.35 kg |
| Product with stand (kg) |
4.35 kg |
| Product without stand (kg) |
2.23 kg
|
| Operating conditions |
| Altitude |
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
|
| Temperature range (operation) |
0°C to 40°C °C
|
| MTBF |
50,000 (Excluded backlight) hour(s)
|
| Relative humidity |
20%-80 %
|
| Temperature range (storage) |
-20°C to 60°C °C
|
| Sustainability |
| Environmental and energy |
RoHS
|
| Recyclable packaging material |
100 %
|
| Compliance and standards |
| Regulatory Approvals |
BSMI/ CB/ CE MARK/ Cetlus/ fcc Class B/ ICES - 003
|
| Cabinet |
| Color |
Black
|
| Finish |
Textured
|
