| Model Parameters - C6N
|
| Model |
CS-C6N-A0-1C2WFR |
| Camera |
| Image Sensor |
1/4" Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
4mm@ F2.4, view angle: 85° diagonal, 75° horizontal, 45° vertical |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto-switching |
| DNR |
3D DNR |
| WDR |
Digital WDR |
| Compression |
| Video Compression |
H.264 |
| Video Bit Rate |
Full HD, HD, Standard. Adaptive bit rate. |
| Image |
| Max. Resolution |
1920 × 1080 |
| Frame Rate |
Max. 15fps; Self-adaptive during network transmission |
| Network |
| Smart Alarm |
Motion detection |
| Wi-Fi Pairing |
AP Pairing |
| Protocol |
EZVIZ Cloud Proprietary Protocol |
| Interface Protocol |
EZVIZ Cloud Proprietary Protocol |
| Interface |
| Storage |
MicroSD card slot (Max. 256 GB) |
| Power |
Micro USB |
| Wired Network |
RJ45 X 1 (10M/100M self-adaptive Ethernet port) |
| Wi-Fi |
| Standard |
IEEE802.11 b/g/n |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
Supports 20MHz |
| Security |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
| Transmission Rate |
11b: 11 Mbps, 11g: 54 Mbps, 11n: 72 Mbps |
| General |
| Power Supply |
DC 5V/1A |
| Power Consumption |
5W max |
| IR Range |
MAX. 10m (32.81 fts) |
| Dimensions |
88 mm x 88.2 mm x 119 mm (3.46” x 3.47” x 4.69”) |
| Packaging Dimensions |
103 mm x 103 mm x 168 mm (4.06” x 4.06” x 6.61”) |
| Bare Weight |
218g (0.48lb) |
| Packaging Contents |
| Packaging Contents |
C6N camera; Base; Screw Kit; Power Cable 3m (9.8 ft.); Drill Template; Power Adapter; Quick Start Guide |
| Operating Environment |
| Temperature |
-10° C to 45° C (14° F to 113° F) |
| Humidity |
95% or less (non-condensing) |
| Certifications |
| Certifications |
FCC / UL / CE / WEEE / REACH / RoHS |
