PRINT |
|
|
|
Number of Nozzles |
Total 1,280 nozzles |
Ink Cartridges (Type/Colours) |
PG-745S (Pigment Ink/Black), CL-746S (Dye-Based Ink/Colour) |
|
[Optional: PG-745, CL-746 / PG-745XL, CL-746XL] |
Maximum Print Resolution |
4,800 (horizontal)*1 x 600 (vertical) dpi
|
Print Speed*2 (Approx.)
|
Based on ISO/IEC 24734 |
|
Click here for summary report |
|
Click here for Document Print and Copy Speed Measurement Conditions |
Document (ESAT/Simplex) |
8 / 4 ipm (mono/colour) |
Print Width |
Up to 203.2 mm (8") |
Recommended Printing Area |
Top margin: 31.6 mm |
|
Bottom margin: 29.2 mm |
|
|
Scanner Type
|
Flatbed (Platen) |
Scanner Technology |
Contact Image Sensor (CIS) |
Optical Resolution*4
|
600 x 1,200 dpi |
Scanning Bit Depth (Input/Output) |
|
Greyscale |
16 bit / 8 bit |
Colour |
48 bit / 24 bit (RGB each 16 bit / 8 bit) |
Maximum Document Size |
|
Flatbed |
A4, LTR (216 x 297 mm) |
|
Copy Speed*5 (Approx.)
|
|
Based on ISO/IEC 24734 |
|
Click here for summary report |
Document (Colour): (sFCOT/Simplex) / (sESAT/Simplex) |
31 sec / 1.6 ipm |
Maximum Copies |
21 pages |
Maximum Document Size |
A4, LTR |
|
|
Print Margin
|
|
Bordered Printing |
LTR/LGL: |
|
Top margin: 3 mm, Bottom margin: 16.7 mm |
|
Left margin: 6.4 mm, Right margin: 6.3 mm |
|
|
|
Others: |
|
Top margin: 3 mm, Bottom margin: 16.7 mm |
|
Left/Right margin: 3.4 mm |
Supported Media |
|
Rear Tray |
Plain Paper (64 - 105 g/m²) |
|
High Resolution Paper (HR-101N) |
|
Photo Paper Plus Glossy II (PP-201, PP-208) |
|
Envelope |
Paper Size |
|
Rear Tray |
A4, A5, B5, LTR, LGL, Envelope (COM10, DL), 4 x 6", 5 x 7" |
|
|
|
[Custom Size] |
|
Width: 101.6 - 215.9 mm |
|
Length: 152.4 - 676 mm |
|
|
|
*F4 is possible via custom settings. |
Maximum Capacity |
|
Rear Tray |
Plain Paper, 64 g/m² (A4, A5, B5, LTR, ): 60 |
|
Photo Paper Plus Glossy II (PP-201, PP-208, 4 x 6"): 20 |
|
Envelope (COM10, DL): 5 |
Paper Weight |
|
Rear Tray |
Plain Paper: 64 - 105 g/m² |
|
Canon Paper: Approx. 275 g/m² (Max.) |
|
(Photo Paper Plus Glossy II, PP-201) |
|
|
OS System Compatibility*6
|
Windows 8 / 7 / Windows Vista / Windows XP |
|
macOS X 10.7.5 or later |
|
|
Interface
|
USB 2.0 |
Operating Environment*7
|
|
Temperature |
5 - 35°C |
Humidity |
10 - 90% RH (no dew condensation) |
Recommended Environment*8
|
|
Temperature |
15 - 30°C |
Humidity |
10 - 80% RH (no dew condensation) |
Storage Environment |
|
Temperature |
0 - 40°C |
Humidity |
5 - 95% RH (no dew condensation) |
Power Requirements |
AC 100 - 240 V, 50/60 Hz |
Power Consumption (Approx.) |
|
OFF |
0.4 W |
Standby |
1 W |
Operation*9
|
9 W |
Dimensions (W x D x H) |
|
Factory Configuration |
426 x 306 x 145 mm |
Weight |
3.5 kg |
|
|
Plain Paper
|
A4 Colour Documents*11:
|
Click here for more information |
PG-745S / CL-746S: 100 |
|
|
|
Optional: |
|
PG-745/CL-746: 180 |
|
PG-745XL/CL-746XL: 300 |
