| LAN |
Realtek RTL8111H (V.6.1)
RTL8111E-VL-CG / RTL8111HNM-CG / RTL8111E-VC-CG / RTL8168H-CG (V6.0)
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
|
| AUDIO CODEC |
ALC897
7.1 Channels, High Definition Audio
|
| USB |
3 x USB 3.2 (Gen1) ports (1 on rear I/Os and 2 via internal headers)
8 x USB 2.0 ports (4 on rear I/Os and 4 via internal headers)
|
| EXPANSION SLOT |
Intel 12th/13th/14th Processors
1 x PCIe 4.0 x16 Slot
Intel H610 Chipset
1 x PCIe 3.0 x1 Slot
* Specifications vary by CPU types |
| REAR I/O |
1 x PS/2 Keyboard/ Mouse Port
1 x HDMI
1 x DP Port
1 x USB 3.2 (Gen1) port
4 x USB 2.0 ports
1 x LAN port
3 x Audio Jack
|
| INTERNAL I/O |
4 x SATA III Connectors (6Gb/s)
2 x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1 x USB 3.2 (Gen1) Header (each header supports 2 USB 3.2 (Gen1) ports)
1 x 8-Pin Power Connector
1 x 24-Pin Power Connector
1 x CPU Fan Connector
1 x System Fan Connector
1 x Front Panel Header
1 x Front Audio Header
1 x Internal Stereo Speaker Header
1 x Clear CMOS Header
1 x COM Port Header
1 x CIO:Chassis Intrusion Header
1 x TPM Header
|
| H/W MONITORING |
CPU / System Temperature Monitoring
Smart / Manual CPU Fan Control
CPU/DDR Voltage Monitoring
|
| DIMENSION |
Micro ATX Form Factor Dimension: 21.6cm x 22.8cm ( W x L )
|
| OS SUPPORT |
Supports Windows 10(64bit) / 11(64bit)
※Biostar reserves the right to add or remove support for any OS with or without notice. |
