AX1800 Dual Band WiFi 6 (802.11ax) Router supporting MU-MIMO and OFDMA technology, with AiProtection Classic network security powered by Trend Micro™, compatible with ASUS AiMesh WiFi system
-
New-Gen WiFi Standard – WiFi 6(802.11ax) standard supporting MU-MIMO and OFDMA technology for better efficiency and throughput.
-
Ultra-fast WiFi Speed – RT-AX1800HP supports 1024-QAM for dramatically faster wireless connections. With a total networking speed of about 1800Mbps — 574 Mbps on the 2.4GHz band and 1201 Mbps on the 5GHz band.
-
Increase Capacity and Efficiency – Supporting not only MU-MIMO but also OFDMA technique to efficiently allocate channels, communicate with multiple devices simultaneously
-
Protection for Your Home Network – Aiprotection powered by Trend Micro™, blocks internet security threats for all your connected smart devices.
-
Better Partner with Mesh System- Compatible with ASUS AiMesh WiFi system for seamless whole-home coverage.
Get Your Home Ready for WiFi 6 (802.11ax)
The growing number of connected personal and IoT devices has led to an overall increase in network density that is pushing the limits of the current WiFi standard. The latest WiFi 6(802.11ax) standard provides future-proof technologies, higher network efficiency, faster WiFi speeds, greater coverage and improved battery life for connected devices, providing a significantly better networking experience for users.
*It requires 802.11ax-compatible devices to enjoy the benefits brought by WiFi 6(802.11ax) standard.
Next-Gen WiFi Speed
RT-AX1800HP is a 2x2 dual-band WiFi router that provides 80MHz bandwidth and 1024-QAM for dramatically faster wireless connections. With a total networking speed of about 1800Mbps — 574Mbps on the 2.4GHz band and 1201Mbps on the 5GHz band — RT-AX1800HP is 1.5X faster than 802.11ac 2x2 dual-band routers.
Built for Multi-device Households
With a revolutionary combination of OFDMA and MU-MIMO technology, 802.11ax technology provides up to 4X greater network capacity and efficiency in traffic-dense environments. Previous-generation 802.11ac WiFi can only handle one device at a time on each network channel, which is an inefficient use of available bandwidth. OFDMA support in the WiFi 6(802.11ax) standard divides each channel into small sub-channels, allowing signals from multiple devices* to be bundled together and transmitted simultaneously, reducing latency for a smoother, more responsive WiFi experience.
Protection for your Home Network
RT-AX1800HP incorporates ASUS AiProtection, a commercial-grade network security system powered by Trend Micro™ Smart Home Network. With AiProtection, all connected devices are protected, even if they have no antivirus capability of their own — such as IoT devices. AiProtection blocks common internet-based attacks before they reach the network, and if an infected device is detected on the network, AiProtection instantly blocks it to prevent it sending any personal information to malicious servers.
Powerful Whole-home WiFi System.
The Way You Want.
In most cases, your RT-AX1800HP can deliver smooth, reliable WiFi to every part of your home. But WiFi coverage can be affected by many factors — room layout, construction materials, and even furnishings. ASUS AiMesh is an innovative new router feature that fixes these problems: it creates a whole-home WiFi network using multiple ASUS routers. AiMesh is powerful, flexible and you can use a mix of ASUS router models — protecting your investment! AiMesh gives you time-saving central control, and seamless roaming capability. AiMesh is Wi-Fi you can rely on — for all your devices, all the time!
-
Turn your ASUS routers into whole-home Wi-Fi system with a simple firmware update
-
Mix and match preferred models from selected ASUS routers
-
Create a Wi-Fi network with either a single SSID or multiple SSIDs
-
All router features work across the entire Wi-Fi system
SPECIFICATIONS
|
Model Name
|
RT-AX1800HP
|
|
Network Standard
|
IPv6
IPv4
WiFi 6 (802.11ax)
WiFi 5 (802.11ac)
WiFi 4 (802.11n)
IEEE 802.11g
IEEE 802.11b
IEEE 802.11a
|
|
WIFI DATA RATE
|
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 5 (802.11ac) : up to 867 Mbps
WiFi 4 (802.11n) : up to 300 Mbps
802.11g : up to 54 Mbps
802.11b : up to 11 Mbps
802.11a : up to 54 Mbps
|
|
Antenna
|
External antenna x 4
|
|
Transmit/ Receive
|
5GHz 2x2
2.4GHz 2x2
|
|
Processor
|
Dual core (4 VPE)
|
|
Memory
|
128 MB Flash
256 MB RAM
|
|
Boosts Speed
|
OFDMA (Orthogonal Frequency Division Multiple Access)
Beamforming: standard-based and universal
1024-QAM high data rate
20/40/80 MHz bandwidth
|
|
Operating Frequency
|
2.4G Hz / 5 GHz
|
|
Operating Mode
|
Access Point, Media Bridge, Repeater, Router
|
|
I/0 PORTS
|
RJ45 for Gigabits BaseT for WAN x 1, RJ45 for Gigabits BaseT for LAN x 4
|
|
Buttons
|
WPS Button, Reset Button, Power Switch
|
|
LED Indicator
|
Power x 1
2.4G x 1
5G x 1
LAN x 1
WAN x 1
|
|
Power Supply
|
AC Input : 100V~240V(50~60Hz)
DC Output : 12 V with max. 1.5A current
|
|
Product Weight (G)
|
390g / 0.86lb
|
|
Package Content
|
RT-AX1800HP
RJ45 x1
Adapter x1
QSG x1
Warranty Card x1
|
|
AiMesh
|
• AiMesh Node
• Primary AiMesh Router
AiMesh
|
|
Parental Control
|
Customized Internet Schedule
"Allow you to block access to unwanted websites and apps."
|
|
Guest Network
|
"The Guest Network provides Internet connection for guests but restricts access to your local network."
|
|
Security
|
SSH
Firewall
Let's Encrypt
WPS
Open system, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA3-Personal
|
|
AiProtection
|
• Infected Device Prevention and Blocking
• Malicious Site Blocking
|
|
VPN
|
VPN Server PPTP
VPN Server Open VPN
VPN Server IPSec
VPN Client PPTP
VPN Client Open VPN
VPN Client L2TP
|
|
Traffic Control
|
• Wireless Traffic Monitor
• Wired Traffic Monitor
• Real-time Traffic Monitor
Traffic Monitor
Traditional QoS
• Bandwidth Limiter
|
|
WAN
|
DDNS
DMZ
Port forwarding
Dual WAN
Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP
|
|
LAN
|
Manually Assign IP Address
Wake on LAN (WOL)
IPTV
IGMP Snooping
DHCP Server
|
|
Wireless
|
RADIUS Client
Explicit Beamforming
Universal Beamforming
Airtime Fairness
Wireless Scheduler
WiFi MAC Address Filter
UTF-8 SSID
|
|
Administration
|
Configuration Backup and Restore
Diagnosis tools
Feedback System
System Log
|
