Specifications: Capacity 1TB Form factor M.2 2280 NAND Flash 3D NAND Controller RTS5766DL Dimensions (L x W x H) 80 x 22 x 3.13mm / 3.15 x 0.87 x 0.13inch (with heat sink)80 x 22 x 2.15mm / 3.15 x 0.87 x 0.09inch (without heat sink) Weight 9g / 0.32oz (with heat sink)6.2g / 0.22oz (without heat sink) Interface PCIe Gen3 x4 Sequential Read (Max) Up to 2,400MB/s* Sequential Write (Max) Up to 1,800MB/s* 4KB Random Read IOPS(Max) Up to 200K* 4KB Random Write IOPS(Max) Up to 150K* Operating temperature 0°C - 70°C Storage temperature -40°C - 85°C Shock resistance 1500G/0.5ms MTBF 1,500,000 hours

Read more less

● PCIe Gen3 x4 interface● Excellent read/write performance● Heat sink keeps things 15% cooler● Great upgrade option for creators● High capacities● Supports NVMe 1.4● LDPC & AES 256-bit encryption● Supports Host Memory Buffer(HMB)

Read more less

Model: Adata AD-ALEG-710-512GCS Legend 710 512GB PCIe GEN3 x4 M.2 NVME 2280 SSD Capacity 512GB  Form factor M.2 2280 NAND Flash 3D NAND Controller RTS5766DL Dimensions (L x W x H) 80 x 22 x 3.13mm / 3.15 x 0.87 x 0.13inch (with heat sink)80 x 22 x 2.15mm / 3.15 x 0.87 x 0.09inch (without heat sink) Weight 9g / 0.32oz (with heat sink)6.2g / 0.22oz (without heat sink) Interface PCIe Gen3 x4 Sequential Read (Max) Up to 2,400MB/s* Sequential Write (Max) Up to 1,800MB/s* 4KB Random Read IOPS(Max) Up to 200K* 4KB Random Write IOPS(Max) Up to 150K* Operating temperature 0°C - 70°C Storage temperature -40°C - 85°C Shock resistance 1500G/0.5ms MTBF 1,500,000 hours Terabytes Written (TBW) 520TB**

Read more less

SPECIFICATIONSCapacity: 1TBForm factor: M.2 2280NAND Flash: 3D NANDController: SMI SM2264Dimensions: (L x W x H) 80.6 x 23.2 x 10.65mm / 3.17 x 0.91 x 0.42inch(with heat sink)80 x 22 x 3.3mm / 3.15 x 0.87 x 0.13inch (without heat sink)Weight: 36.6g /1.3oz (with heat sink)7.3g /0.26oz (without heat sink)Interface: PCIe Gen4 x4Sequential Read (Max): Up to 7,400MB/s (PC/Laptop)*, Up to 6,400MB/s (PS5)Sequential Write (Max): Up to 6,800MB/s*4KB Random Read IOPS(Max): Up to 750K*4KB Random Write IOPS(Max): Up to 630K*Operating temperature: 0°C - 70°CStorage temperature: -40°C-85°CShock resistance: 1,500G/0.5msMTBF: 1,500,000 hoursTerabytes Written (TBW): 3,120TB**_____________________________________________________Warranty Information:• Item compatibility is buyer’s responsibility.• For security purposes: Kindly secure unboxing video incase wrong item and defective upon received.• Check all items upon receipt.• All items/claims for warranty are carry-in.• Tampered warranty sticker voids the warranty.• Overclocking may void the warranty.• Items for warranty must be complete with original contents/packaging and accompanied by warranty receipt.• Defective items for warranty are subject for pull out and RMA services. (Shipping fee should be shoulder by customer)

Read more less
