Specifications Main Range of product AvatarOn A Product or component type Switch load type Resistive loadInductiveFluorescent load Colour tint White (WE) Colour tint White Complementary Device presentation Complete product Rated current 16 AX at 250 V AC 50 Hz Switch function 1-way Switch application Control switch Number of gangs 3 gangs Clamping connection capacity 2 x 1.5 mm² for solid cable(s)2 x 2.5 mm² for stranded cable(s)2 x 4 mm² Connections - terminals Screwless type terminals Local signalling Fluorescent (white) Material PC: dollyPC 10 % GF: basePC 10 % GF: base cover Device mounting Flush Width 120 mm Height 70 mm Depth 33 mm Embedding depth 22 mm Environment IP degree of protection IP20 Maximum ambient air temperature for operation 45 °C Ambient air temperature for storage -5…60 °C Operating altitude <= 2000 m Relative humidity 0…95 % Standards IEC 60669-1 Product certifications IECTIS Packing Units Unit Type of Package 1 PCE Number of Units in Package 1 1 Package 1 Height 3.2 cm Package 1 Width 7 cm Package 1 Length 12 cm Package 1 Weight 128 g Unit Type of Package 2 BB1 Number of Units in Package 2 10 Package 2 Height 8.8 cm Package 2 Width 18.5 cm Package 2 Length 26.5 cm Package 2 Weight 1.386 kg Unit Type of Package 3 S03 Number of Units in Package 3 60 Package 3 Height 30 cm Package 3 Width 30 cm Package 3 Length 40 cm Package 3 Weight 8.966 kg
