Model
PRIME-RTX5070TI-O16G
Graphic Engine
NVIDIA® GeForce RTX™ 5070 Ti
AI Performance
1432 TOPs
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
16GB GDDR7
Engine Clock
OC mode: 2527MHzDefault mode: 2497MHz (Boost Clock)OC mode: 2527MHzDefault mode: 2497MHz (Boost Clock)
CUDA Core
8960
Memory Speed
28 Gbps
Memory Interface
256-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 1 (Native HDMI 2.1b)Yes x 3 (Native DisplayPort 2.1b)HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x Speedsetup Manual1 x ASUS Velcro Hook & Loop1 x Thank You Card1 x Adapter Cable (1 to 3)
Software
ASUS GPU Tweak III & MuseTree & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
304 x 126 x 50 mm12 x 5 x 2 inch304 x 126 x 50 mm12 x 5 x 2 inch
Recommended PSU
750W
Power Connectors
1 x 16-pin
Slot
2.5 Slot
SFF Ready
Compatible
GameRock: A Fusion of Art and Power
The Palit GameRock series combines stunning aesthetics with powerful performance.
Its Chameleon Panel offers dynamic, ever-changing colors with ARGB Sync Evo support for easy synchronization of lighting. Advanced cooling features like TurboFan 4.0, Air Deflector, Composite Heat Pipes, and a Vapor Chamber ensure optimal thermal performance.
Designed to dazzle and deliver, GameRock is perfect for gamers, creators, and AI enthusiasts.
Powered by NVIDIA Blackwell, GeForce RTX™ 50 Series GPUs bring game-changing AI capabilities to gamers and creators.
SPECIFICATIONS
Memory Amount
16 GB
Memory Interface
256 bits
DRAM Type
GDDR7
Graphics Clock
2295 MHz
Boost Clock
2452 MHz
Memory Clock
28 Gbps
CUDA Cores
8960
Memory Bandwidth (GB/sec)
896
Microsoft DirectX
Microsoft DirectX® 12 Ultimate
OpenGL
4.6
Bus Support
PCI-E 5.0
HDMI
HDMI 2.1b
DisplayPort
DP2.1b x 3
Maximum Digital Resolution
4K at 480Hz or 8K at 120Hz with DSCR
Height
3.5 slot
Board Size
331.9 x 150 x 70.4 mm
Graphics Card Power
300 W
Recommended System Power
750 W
Supplementary Power Connectors
16-pin x1
Accessory
Power Cable, ARGB Cable, VGA Holder, Holder Extender
ARGB SYNC EVO
✔
TurboFan Blade
4
2-Ball Bearing
✔
Air Deflector
✔
Superior Rigidity
✔
Composite Heat Pipe
✔
High Performance Vapor Chamber
✔
Dual BIOS
BIOS 1: Performance Mode, BIOS 2:Silent Mode
Digital PWM
✔
DrMOS
✔
0-dB TECH
✔
NVIDIA Architecture
Blackwell
Ray Tracing Cores
4th Generation
Tensor Cores
5th Generation
NVIDIA DLSS 4
✔
NVIDIA Reflex 2
✔
NVIDIA Broadcast
✔
Resizable BAR
✔
NVIDIA App
✔
NVIDIA Ansel
✔
NVIDIA FreeStyle
✔
NVIDIA ShadowPlay
✔
NVIDIA® Highlights
✔
NVIDIA G-SYNC
✔
Game Ready Drivers
✔
NVIDIA Studio Drivers
✔
NVIDIA Omniverse
✔
RTX Remix
✔
NVIDIA GPU Boost
✔
Vulkan 1.4, OpenGL 4.6
✔
NVIDIA Encoder (NVENC)
2 x 9th Generation
NVIDIA Decoder (NVDEC)
1 x 6th Generation
AV1 Encode
✔
AV1 Decode
✔
CUDA Capability
12.8
VR Ready
✔
Multi Monitor
4
Specifications
Memory Amount
16 GB
Memory Interface
256 bits
DRAM Type
GDDR7
Graphics Clock
2295 MHz
Boost Clock
2617 MHz
Memory Clock
30 Gbps
CUDA Cores
10752
Memory Bandwidth (GB/sec)
960
Microsoft DirectX
Microsoft DirectX® 12 Ultimate
OpenGL
4.6
Bus Support
PCI-E 5.0
HDMI
HDMI 2.1b
DisplayPort
DP2.1b x 3
Maximum Digital Resolution
4K at 480Hz or 8K at 120Hz with DSC
Height
3.5 slot
Board Size
331.9 x 150 x 70.4 mm
Graphics Card Power
360 W
Recommended System Power
850 W
Supplementary Power Connectors
16-pin x1
Accessory
Power Cable, ARGB Cable, VGA Holder, Holder Extender
Primed for Power
Experience Primal performance with the Prime GeForce RTX 5080, an SFF-Ready Enthusiast GeForce Card featuring a 2.5-slot design for expansive compatibility, enhanced by a triple-fan setup for supreme airflow and vapor chamber design for supreme cooling.
Unmatched Reliability
Engineering
SPECIFICATION
Model
PRIME-RTX5080-O16G
Graphic Engine
NVIDIA® GeForce RTX™ 5080
AI Performance
1827 TOPs
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
16GB GDDR7
Engine Clock
OC mode: 2685 MHzDefault mode: 2655 MHz (Boost Clock)
CUDA Core
10752
Memory Speed
30 Gbps
Memory Interface
256-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 1 (Native HDMI 2.1b)Yes x 3 (Native DisplayPort 2.1b)HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x Speedsetup Manual1 x ASUS Velcro Hook & Loop1 x Thank You Card1 x Adapter Cable (1 to 3)
Software
ASUS GPU Tweak III & MuseTree & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
304 x 126 x 50 mm12 x 5 x 2 inch
Recommended PSU
850W
Power Connectors
1 x 16-pin
Slot
2.5 Slot
SFF Ready
Compatible
