A950RG
A950RG wireless router complies with the latest IEEE 802.11ac wave2 Wi-Fi standard, with MU-MIMO technology offering continual high speed data transmission for multiple devices at the same time.
Built-in 1GHz processor provides powerful data handling capacity to improve Wi-Fi transfer efficiency.
Meanwhile, simultaneous dual band with middle power design on both bands make wireless connection more flexible and stable, especially over long distance.
Generally, A950RG is designed for medium-size homes with increasing demand of high-speed Wi-Fi network.
FEATURES:
Complies with the next generation IEEE 802.11ac Wi-Fi standard.
867Mbps on 5GHz and 300Mbps on 2.4GHz band for total 1167Mbps simultaneously.
Middle power design on both bands is perfect for long distance wireless transmission.
MU-MIMO technology allows data transfer to multiple devices at the same time.
Gigabit WAN ensures high speed Internet access and Wi-Fi speed.
Supports DHCP, Static IP, PPPoE, PPTP and L2TP broadband functions.
Provides 64/128-bit WEP, WPA, WPA2 and WPA/WPA2 (TKIP+AES) security.
Connects to secure network easily and fast using WPS.
QoS: Bandwidth Control based on IP.
Supports IP, MAC, URL filtering and Port Forwarding.
Universal Repeater and WDS function for easy Wi-Fi extension.
Multi-SSID function enables users to create multiple Wi-Fi networks.
Supports easy and fast IPTV settings.
SPECIFICATIONS:
HARDWARE
Interface:
- 4 * 100Mbps LAN Ports
- 1 * 100Mbps WAN Port
Power Supply:
- DC 9V/0.8A
Button:
1 * RST/WPS Button
LED Indicators:
1 * Status,
4 * LAN,
1 * WAN
Antenna:
- 4 * 5dBi fixed antennas
Dimensions (L x W x H):
- 170.2 x 138.0 x 40.6 mm (not including antennas)
WIRELESS
Standards:
IEEE 802.11ac,
IEEE 802.11a,
IEEE 802.11b,
IEEE 802.11g,
IEEE 802.11n
RF Frequency:
- 2.4GHz/5GHz
Data Rate:
2.4GHz: Up to 300Mbps
5GHz: Up to 867Mbps
EIRP:
2.4GHz < 22dBm
5GHz < 20dBm
Wireless Security:
64/128-bit WEP, WPA, WPA2 and WPA-Mixed
Reception Sensitivity:
- 2.4G: 11b: <-81dbm.
11g: <-68dbm.
11n: HT20<-65dbm HT40: <-62dbm
- 5G: 11a:<-68dbm:
11n: HT20<-65dbm HT40: <-62dbm
11ac: <-51dbm
SOFTWARE
Operation Mode:
Gateway Mode Bridge Mode
Repeater Mode
WISP Mode
Network:
Static DHCP Setting, IPTV, IPV6
WAN Type:
Static IP, DHCP, PPPoE/Russia PPPoE, PPTP/Russia PPTP, L2TP/Russia L2TP
Wireless Functions:
Multiple SSID,
MAC Authentication,
Universal Repeater,
WDS,
WPS
QoS:
QoS Setup,
Connect Limit Control
Schedule:
Reboot Schedule,
Wireless Schedule
Firewall:
MAC Filtering,
IP Filtering,
Port Filtering,
URL Filtering Port Forwarding,
DMZ
Management:
Administrator Setting,
Time Setting,
DDNS, Remote Management,
UPnP,
Upgrade Firmware,
System Configuration,
System Log, and more
OTHERS
Package Contents:
A950RG Wireless Router *1
Power Adapter *1
Ethernet Cable *1
Quick Installation Guide *1
Environment:
Operating Temperature: 0℃~50 ℃ (32 ℉~122℉)
Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
Operating Humidity: 5%~95% non-condensing
Storage Humidity: 5%~95% non-condensing
