HARDWARE FEATURES - TL-WN881ND Interface PCI Express(x1) Dimensions ( W x D x H ) 4.8 x 3.1 x 0.8in. (120.8 x 78.5 x 21.5mm) Antenna Type Detachable Omni Directional (RP-SMA) Antenna Gain 2dBi WIRELESS FEATURES Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Frequency 2.400-2.4835GHz Signal Rate 11n: Up to 300Mbps(dynamic)11g: Up to 54Mbps(dynamic)11b: Up to 11Mbps(dynamic) Reception Sensitivity 270M: -68dBm@10% PER130M: -68dBm@10% PER108M: -73dBm@10% PER54M: -73dBm@10% PER11M: -89dBm@8% PER6M: -87dBm@10% PER1M: -90dBm@8% PER Transmit Power <20dBm(EIRP) Wireless Modes Ad-Hoc / Infrastructure mode Wireless Security Support 64/128 bit WEP, WPA-PSK/WPA2-PSK Modulation Technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM OTHERS Certification CE, FCC, RoHS Package Contents Wireless Adapter2x Detachable Omni directional antennaResource CDQuick Installation Guide System Requirements Windows 10/8.1/8/7，Linux Environment Operating Temperature: 0℃~40℃ (32℉~104℉)Storage Temperature: -40℃~70℃ (-40℉~158℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing

Read more less

WIRELESS - Archer AX23 Standards Wi-Fi 6IEEE 802.11ax/ac/n/a 5 GHzIEEE 802.11ax/n/b/g 2.4 GHz WiFi Speeds AX18005 GHz: 1201 Mbps (802.11ax)2.4 GHz: 574 Mbps (802.11ax) WiFi Range 3 Bedroom Houses4× Fixed High-Performance AntennasMultiple antennas form a signal-boosting array to cover more directions and large areasBeamformingConcentrates wireless signal strength towards clients to expand WiFi range WiFi Capacity HighDual-BandAllocate devices to different bands for optimal performanceOFDMASimultaneously communicates with multiple Wi-Fi 6 clientsAirtime FairnessImproves network efficiency by limiting excessive occupation4 StreamsConnect your devices to more bandwidth Working Modes Router ModeAccess Point Mode SECURITY Network Security SPI FirewallAccess ControlIP & MAC BindingApplication Layer Gateway Guest Network 1× 5 GHz Guest Network1× 2.4 GHz Guest Network VPN Server OpenVPNPPTP WiFi Encryption WPAWPA2WPA3WPA/WPA2-Enterprise (802.1x) HARDWARE Processor Dual-Core CPU Ethernet Ports 1× Gigabit WAN Port4× Gigabit LAN Ports Buttons WPS/Wi-Fi ButtonPower On/Off ButtonLED On/Off ButtonReset Button Power 12 V ⎓ 1.5 A SOFTWARE Protocols IPv4IPv6 OneMesh™ OneMesh™ SupportedWithout replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.Learn More>All OneMesh Products> EasyMesh Mesh networking creates smooth, fast, stable roaming. Archer AX23 can flexibly build an EasyMesh network with EasyMesh-Compatible devices, which eliminates Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi. Seamless Wi-Fi connections with one network name, one-click setting and flexible scalability.Learn More> Parental Controls URL FilteringTime Controls WAN Types Dynamic IPStatic IPPPPoEPPTPL2TP Quality of Service QoS by Device Cloud Service OTA Firmware UpgradeTP-Link IDDDNS NAT Forwarding Port ForwardingPort TriggeringDMZUPnP IPTV IGMP ProxyIGMP SnoopingBridgeTag VLAN DHCP Address ReservationDHCP Client ListServer DDNS TP-LinkNO-IPDynDNS Management Tether AppWebpageCheck Web Emulator> OTHER System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access) Certifications FCC, CE, RoHS Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)Storage Temperature: -40℃~70℃ (-40℉ ~158℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing TEST DATA WiFi Transmission Power CE:<20dBm(2.4 GHz)<23dBm(5.15 GHz~5.25 GHz)FCC:<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) WiFi Reception Sensitivity EU Version5G11a 6Mbps: -96dbm11a 54Mbps:-75dbm11ac VHT20_MCS0: -95dbm11ac VHT20_MCS8: -71dbm11ac VHT40_MCS0: -92dbm11ac VHT40_MCS9: -66dbm11ac VHT80_MCS0: -89dbm11ac VHT80_MCS9:-62dbm11ax HE20_MCS0:-95dbm11ax HE20_MCS11: -64dbm11ax HE40_MCS0: -92dbm11ax HE40_MCS11: -60dbm11ax HE80_MCS0: -89dbm11ax HE80_MCS11:-59dbm2.4G11g 6Mbps:-96dbm11g 54Mbps:-75dbm11n HT20_MCS0:-95dbm11n HT20_MCS7:-75dbm11n HT40_MCS0:-92dbm11n HT40_MCS7: -72dbm11ac VHT20_MCS0:-95dbm11ac VHT20_MCS8:-72dbm11ac VHT40_MCS0:-92dbm11ac VHT40_MCS9: -67dbm11ax HE20_MCS0:-95dbm11ax HE20_MCS11: -65dbm11ax HE40_MCS0: -92dbm11ax HE40_MCS11: -62dbmUS Version5G11a 6Mbps: -96dbm11a 54Mbps:-75dbm11ac VHT20_MCS0: -95dbm11ac VHT20_MCS8: -71dbm11ac VHT40_MCS0: -92dbm11ac VHT40_MCS9: -66dbm11ac VHT80_MCS0: -89dbm11ac VHT40_MCS9:-62dbm11ax HE20_MCS0:-95dbm11ax HE20_MCS11: -64dbm11ax HE40_MCS0: -92dbm11ax HE40_MCS11: -60dbm11ax HE80_MCS0: -89dbm11ax HE80_MCS11:-59dbm2.4G11g 6Mbps:-96dbm11a 54Mbps:-75dbm11ac VHT20_MCS0:-95dbm11ac VHT20_MCS8:-72dbm11ac VHT40_MCS0:-92dbm11ac VHT40_MCS9: -67dbm11ax HE20_MCS0:-95dbm11ax HE20_MCS11: -65dbm11ax HE40_MCS0: -92dbm11ax HE40_MCS11: -62dbm PHYSICAL Dimensions (W×D×H) 10.2 × 5.3 ×1.5 in(260.2 × 135.0 × 38.6 mm) Package Contents Wi-Fi Router Archer AX23Power AdapterRJ45 Ethernet CableQuick Installation Guide

Read more less

WIRELESS - Archer AX55 Standards Wi-Fi 6IEEE 802.11ax/ac/n/a 5 GHzIEEE 802.11ax/n/b/g 2.4 GHz WiFi Speeds AX30005 GHz: 2402 Mbps (802.11ax, HE160)2.4 GHz: 574 Mbps (802.11ax) WiFi Range 3 Bedroom Houses4× Fixed High-Performance AntennasMultiple antennas form a signal-boosting array to cover more directions and large areasBeamformingConcentrates wireless signal strength towards clients to expand WiFi rangeHigh-Power FEMImproves transmission power to strengthen signal coverage WiFi Capacity HighDual-BandAllocate devices to different bands for optimal performanceOFDMASimultaneously communicates with multiple Wi-Fi 6 clientsAirtime FairnessImproves network efficiency by limiting excessive occupationDFSAccess an extra band to reduce congestion4 StreamsConnect your devices to more bandwidth Working Modes Router ModeAccess Point Mode SECURITY Network Security SPI FirewallAccess ControlIP & MAC BindingApplication Layer GatewayHomeShield SecurityReal-Time IoT ProtectionMalicious Site BlockerIntrusion Prevention SystemDDoS Attack PreventionHome Network Scanner Guest Network 1× 5 GHz Guest Network1× 2.4 GHz Guest Network VPN Server OpenVPNPPTP VPN Client • Open VPN Client• PPTP VPN Client• L2TP VPN Client WiFi Encryption WPAWPA2WPA3WPA/WPA2-Enterprise (802.1x) HARDWARE Processor Dual-Core CPU Ethernet Ports 1× Gigabit WAN Port4× Gigabit LAN Ports USB Support 1× USB 3.0 PortSupported Partition Formats:NTFS, exFAT, HFS+, FAT32Supported Functions:Apple Time MachineFTP ServerMedia ServerSamba Server Buttons Wi-Fi/WPS ButtonPower On/Off ButtonReset Button Power 12 V ⎓ 2 A SOFTWARE Protocols IPv4IPv6 Service Kits HomeShieldLearn More> OneMesh™ OneMesh™ SupportedWithout replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.Learn More>All OneMesh Products> EasyMesh Mesh networking creates smooth, fast, stable roaming. Archer AX55 can flexibly build an EasyMesh network with EasyMesh-Compatible devices, which eliminates Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi. Seamless Wi-Fi connections with one network name, one-click setting and flexible scalability.Learn More> Parental Controls HomeShield Parental ControlsCustom ProfilesProfessional Content Filter LibraryFamily TimeBedtimeOff TimeTime RewardsFamily Online Time RankingPause the InternetWeekly and Monthly Reports WAN Types Dynamic IPStatic IPPPPoEPPTPL2TP Quality of Service QoS by Device Cloud Service Auto Firmware UpgradeOTA Firmware UpgradeTP-Link IDDDNS NAT Forwarding Virtual ServersPort ForwardingPort TriggeringDMZUPnP IPTV IGMP ProxyIGMP SnoopingBridgeTag VLAN DHCP Address ReservationDHCP Client ListServer DDNS TP-LinkNO-IPDynDNS Management Tether AppWebpageCheck Web Emulator> OTHER System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access) Certifications FCC, CE, RoHS Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)Operating Humidity: 10%~90% non-condensing TEST DATA WiFi Transmission Power CE:<20dBm(2.4GHz)<23dBm(5.15GHz~5.35GHz)<30dBm(5.47GHz~5.725GHz)FCC:<30dBm(2.4GHz & 5.15GHz~5.825GHz) WiFi Reception Sensitivity 5GHz:11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS8:-75dBm11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS9:-70dBm11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS9:-67dBm11ac VHT160_MCS0:-88dBm, 11ac VHT160_MCS9:-63dBm11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-66dBm11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-63dBm11ax HE80_MCS0:-91dBm, 11ax HE80_MCS11:-61dBm11ax HE160_MCS0:-87dBm, 11ax HE160_MCS11:-58dBm2.4GHz:11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS8:-74dB11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS9:-70dB11ax HE20_MCS0:-96dBm, 11ax HE20_MCS11:-66dBm11ax HE40_MCS0:-93dBm, 11ax HE40_MCS11:-63dBm PHYSICAL Dimensions (W×D×H) 10.2 × 5.3 × 1.5 in(261.1 × 134.5 × 41.0 mm) Package Contents Wi-Fi Router Archer AX55Power AdapterRJ45 Ethernet CableQuick Installation Guide

Read more less

WIRELESS - Archer AX95 Standards Wi-Fi 6• IEEE 802.11ax/ac/n/a 5 GHz• IEEE 802.11ax/n/b/g 2.4 GHz WiFi Speeds •AX7800• 5 GHz-1: 4804 Mbps (802.11ax, HE160)• 5 GHz-2: 2402 Mbps (802.11ax)• 2.4 GHz: 574 Mbps (802.11ax) WiFi Range 4 Bedroom Houses8× Fixed High-Performance AntennasMultiple antennas form a signal-boosting array to cover more directions and large areasBeamformingConcentrates wireless signal strength towards clients to expand WiFi rangeHigh-Power FEMImproves transmission power to strengthen signal coverage4T4RMultiple streams in the same band strengthen the fault tolerance in transmission WiFi Capacity Very HighTri-BandAllocate devices to different bands for optimal performance4×4 MU-MIMOSimultaneously communicates with multiple MU-MIMO clientsOFDMASimultaneously communicates with multiple Wi-Fi 6 clientsAirtime FairnessImproves network efficiency by limiting excessive occupationDFSAccess an extra band to reduce congestion8 StreamsConnect your devices to more bandwidth Working Modes • Router Mode• Access Point Mode SECURITY Network Security • SPI Firewall• Access Control• IP & MAC Binding• Application Layer Gateway• HomeShield SecurityReal-Time IoT ProtectionMalicious Site BlockerIntrusion Prevention SystemDDoS Attack PreventionHome Network Scanner Guest Network • 1× 5 GHz-1 Guest Network• 1× 5 GHz-2 Guest Network• 1× 2.4 GHz Guest Network VPN Server • OpenVPN• PPTP• L2TP VPN Client • OpenVPN• PPTP• L2TP WiFi Encryption • WPA• WPA2• WPA3• WPA/WPA2-Enterprise (802.1x) HARDWARE Processor 1.7 GHz Quad-Core CPU Ethernet Ports • 1× 2.5 Gbps WAN/LAN Port• 1× 1 Gbps WAN/LAN Port• 3× 1 Gbps LAN Ports USB Support • 1× USB 3.0 Port• 1× USB 2.0 Port• Supported Partition Formats:NTFS, exFAT, HFS+, FAT32• Supported Functions:FTP ServerMedia ServerSamba Server Buttons • LED On/Off Button• WPS Button• Wi-Fi On/Off Button• Power On/Off Button• Reset Button Power 12 V ⎓ 3.3 A SOFTWARE Protocols • IPv4• IPv6 Service Kits HomeShieldLearn More> OneMesh™ OneMesh™ SupportedWithout replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.Learn More>All OneMesh Products> Parental Controls HomeShield Parental ControlsCustom ProfilesProfessional Content Filter LibraryFamily TimeBedtimeOff TimeTime RewardsFamily Online Time RankingPause the InternetWeekly and Monthly Reports WAN Types • Dynamic IP• Static IP• PPPoE• PPTP• L2TP Quality of Service QoS by Device Cloud Service Auto Firmware UpgradeTP-Link IDDDNS NAT Forwarding • Port Forwarding• Port Triggering• DMZ• UPnP IPTV • IGMP Proxy• IGMP Snooping• Bridge• Tag VLAN DHCP • Address Reservation• DHCP Client List• Server DDNS • TP-Link• NO-IP• DynDNS Management • Tether App• Webpage OTHER System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access) Certifications FCC, CE, RoHS Environment • Operating Temperature: 0℃~40℃ (32℉ ~104℉)• Storage Temperature: -40℃~70℃ (-40℉ ~158℉)• Operating Humidity: 10%~90% non-condensing• Storage Humidity: 5%~90% non-condensing TEST DATA WiFi Transmission Power • FCC:≤30dBm (5.17GHz~5.25GHz);≤23dBm (5.25GHz~5.35GHz);≤23dBm (5.49GHz~5.725GHz);≤28dBm (5.725GHz~5.825GHz);≤28dBm (2.4GHz)• CE:≤23dBm EIRP (5.17GHz~5.35GHz);≤30dBm EIRP (5.47GHz~5.725GHz);≤20dBm EIRP (2.4GHz) WiFi Reception Sensitivity • 2.4 GHz:11ac VHT20 MCS0: -98dBm, 11ac VHT20 MCS11: -66dBm,11ac VHT40 MCS0: -96dBm, 11ac VHT40 MCS11: -64dBm,11ax HE20 MCS0: -95dBm, 11ax HE20 MCS11: -64dBm,11ax HE40 MCS0: -93dBm, 11ac HE40 MCS11: -62dBm• 5 GHz:11ac VHT20 MCS0: -94dBm, 11ac VHT20 MCS11: -63dBm,11ac VHT40 MCS0: -93dBm, 11ac VHT40 MCS11: -61dBm,11ac VHT80 MCS0: -89dBm, 11ac VHT80 MCS11: -58dBm,11ac VHT160 MCS0: -84dBm, 11ac VHT160 MCS11: -53dBm,11ax HE20 MCS0: -92dBm, 11ax HE20 MCS11: -60dBm,11ax HE40 MCS0: -89dBm, 11ax HE40 MCS11: -58dBm,11ax HE80 MCS0: -86dBm, 11ax HE80 MCS11: -55dBm,11ax HE160 MCS0: -84dBm, 11ax HE160 MCS11: -53dBm PHYSICAL Dimensions (W×D×H) 10.9 × 7.2 × 2.3 in (277.3 × 183.9 × 57.3 mm) Package Contents • Wi-Fi Router Archer AX95• Power Adapter• RJ45 Ethernet Cable• Quick Installation Guide

Read more less

Archer BE230 New BE3600 Dual-Band Wi-Fi 7 Router 3.6 Gbps Dual-Band WiFi 7: Enables your devices to run at full speed. Enjoy fluent 4K/8K streaming, immersive AR/VR gaming, and blazing-fast downloads. 2× 2.5G Ports: 1× 2.5 Gbps WAN port, 1× 2.5 Gbps LAN port and 3× 1 Gbps LAN ports offer high-speed data transmissions. Maximized Coverage:  4× external antennas along with Beamforming deliver more capacity, stronger and more reliable connections, and less interference. EasyMesh-Compatible: Works with EasyMesh routers and range extenders to form seamless whole home Mesh WiFi, preventing drops and lag when moving between signals. Easy Setup and Use: Network management has never been easier with the Tether app. TP-Link HomeShield: Enhanced security defends against the latest cyber threats. Great Compatibility: Supports all Wi-Fi generations and devices**and all internet providers.   WIRELESSWiFi SpeedsBE3600• 5 GHz: 2882 Mbps (802.11be)• 2.4 GHz: 688 Mbps (802.11be) WiFi Range    3 Bedroom Houses4× External AntennasMultiple antennas form a signal-boosting array to cover more directions and large areas BeamformingConcentrates wireless signal strength towards clients to expand WiFi range WiFi Capacity    HighDual-BandAllocate devices to different bands for optimal performance2×2 MU-MIMOSimultaneously communicates with multiple MU-MIMO clientsOFDMASimultaneously communicates with multiple clientsAirtime FairnessImproves network efficiency by limiting excessive occupationDFSAccess an extra band to reduce congestion4 StreamsConnect your devices to more bandwidth Advanced Functions• Multi-Link Operation (MLO)• 4K-QAM• Multi-RUs• EasyMesh-Compatible• Works with Alexa and Google Assistant• IoT Network Wireless Mode    • Router Mode• Access Point Mode SECURITYNetwork Security    • SPI Firewall• Access Control• IP & MAC Binding• Application Layer Gateway • HomeShield SecurityReal-Time IoT ProtectionMalicious Site BlockerIntrusion Prevention SystemDDoS Attack PreventionHome Network Scanner Guest Network    • 1× 5 GHz Guest Network• 1× 2.4 GHz Guest Network VPN Server    • OpenVPN Server• PPTP VPN Server• L2TP VPN Server• WireGuard VPN Server VPN Client    • Open VPN Client• PPTP VPN Client• L2TP VPN Client• WireGuard VPN Client WiFi Encryption    • WPA• WPA2• WPA3• WPA/WPA2-Enterprise (802.1x) HARDWAREEthernet Ports    • 1× 2.5 Gbps WAN• 1× 2.5 Gbps LAN• 3× 1 Gbps LAN USB Support    1× USB 3.0 • Supported Partition Formats:NTFS, exFAT, HFS+, FAT32 • Supported Functions:FTP ServerMedia ServerSamba Server Buttons    • Power On/Off Button• Wi-Fi On/Off Button• LED Button• WPS Button• Reset Button Power    12 V ⎓ 2 A (US)12 V ⎓ 1.5 A (EU) SOFTWAREProtocol    • IPv4• IPv6Service Kit    HomeShield EasyMesh    Compatible with EasyMesh Parental Controls    HomeShield Parental ControlsCustom ProfilesProfessional Content Filter LibraryFamily TimeBedtimeOff TimeTime RewardsFamily Online Time RankingPause the InternetWeekly and Monthly Reports WAN Type    • Dynamic IP• Static IP• PPPoE• PPTP• L2TP Quality of Service    QoS by Device Cloud Service    • Auto Firmware Upgrade• TP-Link ID• DDNS NAT Forwarding    • Port Forwarding• Port Triggering• DMZ• UPnP IPTV    • IGMP Proxy• IGMP Snooping• Bridge• Tag VLAN DHCP    • Address Reservation• DHCP Client List• Server DDNS    • TP-Link• NO-IP• DynDNS Management    • Tether App• Webpage OTHERSystem Requirements    Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access)Certifications    CE, FCC, RoHS Environment    • Operating Temperature: 0℃~40℃ (32℉ ~104℉)• Operating Humidity: 10%~90% non-condensing

Read more less

SECURITY - Archer C24 Network Security SPI FirewallAccess ControlIP & MAC BindingApplication Layer Gateway Guest Network 1× 5 GHz Guest Network1× 2.4 GHz Guest Network WiFi Encryption WEPWPAWPA2WPA/WPA2-Enterprise (802.1x) WIRELESS Standards Wi-Fi 5IEEE 802.11ac/n/a 5 GHzIEEE 802.11n/b/g 2.4 GHz WiFi Speeds AC7505 GHz: 433 Mbps (802.11ac)2.4 GHz: 300 Mbps (802.11n) WiFi Range 2 Bedroom Houses4× Fixed AntennasMultiple antennas form a signal-boosting array to cover more directions and large areas WiFi Capacity MediumDual-BandAllocate devices to different bands for optimal performance Working Modes Router ModeAccess Point ModeRange Extender Mode HARDWARE Processor Single-Core CPU Ethernet Ports 1× 10/100 Mbps WAN Port4× 10/100 Mbps LAN Ports Buttons WPS/Reset Button Power 9 V ⎓ 0.6 A SOFTWARE Protocols IPv4IPv6 Parental Controls URL FilteringTime Controls WAN Types Dynamic IPStatic IPPPPoEPPTPL2TP Quality of Service QoS by Device NAT Forwarding Port ForwardingPort TriggeringDMZUPnP IPTV IGMP ProxyIGMP SnoopingBridgeTag VLAN DHCP Address ReservationDHCP Client ListServer DDNS NO-IPDynDNS Management Tether AppWebpageCheck Web Emulator> OTHER System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access) Certifications FCC, CE, RoHS Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)Storage Temperature: -40℃~60℃ (-40℉ ~140℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing TEST DATA WiFi Transmission Power CE:<20dBm(2.4GHz)<23dBm(5GHz) WiFi Reception Sensitivity 5GHz:11a 54M: -76dBm;11ac VHT20 MCS8: -71dBm;11ac VHT40 MCS9: -66dBm;11ac VHT80 MCS9: -62dBm2.4GHz:11g 54M: -76dBm;11n HT20 MCS7: -73dBm;11n HT40 MCS7: -71dBm PHYSICAL Dimensions (W×D×H) 4.5 × 4.2 × 1.0 in(115 × 106.7 × 24.3 mm) Package Contents Wi-Fi Router Archer C24Power AdapterRJ45 Ethernet CableQuick Installation Guide

Read more less

SECURITY - Archer C54 Network Security SPI FirewallAccess ControlIP & MAC BindingApplication Layer Gateway Guest Network 1× 5 GHz Guest Network1× 2.4 GHz Guest Network WiFi Encryption WEPWPAWPA2WPA/WPA2-Enterprise (802.1x) WIRELESS Standards Wi-Fi 5IEEE 802.11ac/n/a 5 GHzIEEE 802.11n/b/g 2.4 GHz WiFi Speeds AC12005 GHz: 867 Mbps (802.11ac)2.4 GHz: 300 Mbps (802.11n) WiFi Range 3 Bedroom Houses4× Fixed AntennasMultiple antennas form a signal-boosting array to cover more directions and large areasBeamformingConcentrates wireless signal strength towards clients to expand WiFi range WiFi Capacity MediumDual-BandAllocate devices to different bands for optimal performanceMU-MIMOSimultaneously communicates with multiple MU-MIMO clients Working Modes Router ModeAccess Point ModeRange Extender Mode HARDWARE Processor Single-Core CPU Ethernet Ports 1× 10/100 Mbps WAN Port4× 10/100 Mbps LAN Ports Buttons WPS/Reset Button Power 9 V ⎓ 0.85 A SOFTWARE Protocols IPv4IPv6 Parental Controls URL FilteringTime Controls WAN Types Dynamic IPStatic IPPPPoEPPTPL2TP Quality of Service QoS by Device NAT Forwarding Port ForwardingPort TriggeringDMZUPnP IPTV IGMP ProxyIGMP SnoopingBridgeTag VLAN DHCP Address ReservationDHCP Client ListServer DDNS NO-IPDynDNS Management Tether AppWebpageCheck Web Emulator> OTHER System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access) Certifications FCC, CE, RoHS Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)Storage Temperature: -40℃~60℃ (-40℉ ~140℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing TEST DATA WiFi Transmission Power CE EIRP:<20dBm(2.4GHz)<23dBm(5GHz)FCC:<30dBm(2.4GHz & 5GHz) WiFi Reception Sensitivity 5GHz:11a 6Mbps:-93dBm；11a 54Mbps:-78dBm；11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-66dBm;11ac HT80 mcs9:-62dBm;2.4GHz:11g 54Mbps:-78dBm;11n HT20 mcs7:-74dBm;11n HT40 mcs7:-71dbm； PHYSICAL Dimensions (W×D×H) 4.5 × 4.2 × 1.0 in(115 × 106.7 × 24.3 mm) Package Contents Wi-Fi Router Archer C54Power AdapterRJ45 Ethernet CableQuick Installation Guide

Read more less

WIRELESS - Archer C64 Standards Wi-Fi 5IEEE 802.11ac/n/a 5 GHzIEEE 802.11n/b/g 2.4 GHz WiFi Speeds AC12005 GHz: 867 Mbps (802.11ac)2.4 GHz: 400 Mbps (802.11n) WiFi Range 3 Bedroom Houses4× Fixed High-Performance AntennasMultiple antennas form a signal-boosting array to cover more directions and large areasBeamformingConcentrates wireless signal strength towards clients to expand WiFi range WiFi Capacity MediumDual-BandAllocate devices to different bands for optimal performanceMU-MIMOSimultaneously communicates with multiple MU-MIMO clientsAirtime FairnessImproves network efficiency by limiting excessive occupation Working Modes Router ModeAccess Point Mode SECURITY Network Security SPI FirewallAccess ControlIP and MAC Binding Guest Network 1× 2.4 GHz Guest Network1× 5 GHz Guest Network WiFi Encryption WPAWPA2WPA3WPA/WPA2-Enterprise (802.1x) HARDWARE Processor 1.2 GHz CPU Ethernet Ports 1× Gigabit WAN Port4× Gigabit LAN Ports Buttons WPS/Reset Button Power 12V = 1A SOFTWARE Protocols IPv4IPv6 EasyMesh Mesh networking creates smooth, fast, stable roaming. Archer C64 can flexibly build an EasyMesh network with EasyMesh-Compatible devices, which eliminates Wi-Fi dead zones, expand your network, and fill your entire home with high-speed Wi-Fi. Seamless Wi-Fi connections with one network name, one-click setting and flexible scalability.Learn More> Parental Controls URL FilteringTime Controls WAN Types Dynamic IPStatic IPPPPoE(Dual Access)PPTP(Dual Access)L2TP(Dual Access) Quality of Service QoS by Device Cloud Service OTA Firmware UpgradeTP-Link IDDDNS NAT Forwarding Port ForwardingPort TriggeringUPnPDMZ IPTV IGMP ProxyIGMP SnoopingBridgeTag VLAN DHCP ServerDHCP Client ListAddress Reservation DDNS TP-LinkNO-IPDynDNS Management Tether AppWebpageCheck Web Emulator> OTHER System Requirements Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access) Certifications CE, RoHS Environment Operating Temperature: 0℃~40℃ (32℉ ~104℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing TEST DATA WiFi Transmission Power CE:<20dBm(2.4 GHz), <23dBm(5.15 GHz~5.25 GHz)FCC:<30dBm(2.4 GHz & 5 GHz) WiFi Reception Sensitivity 5 GHz:11a 6Mbps:-95dBm11a 54Mbps:-77dBm11ac VHT20 MCS8:-71dBm11ac VHT40 MCS9:-67dBm11ac VHT80 MCS9:-63dBm2.4 GHz:11g 6Mbps: -96dBm11g 54Mbps: -78dBm11n HT20 MCS7:-77dBm11n HT40 MCS7:-74dBm11ac VHT20 MCS8:-73dBm11ac VHT40 MCS9:-68dBm PHYSICAL Dimensions (W×D×H) 4.7 × 4.7 × 1.1 in(120 × 120 × 27.9 mm) Package Contents Wireless Router Archer C64Power AdapterRJ45 Ethernet CableQuick Installation Guide
