CPU
|
|
LGA1200 package:
|
| 1. 11th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors |
| 2. 10th Generation Intel® Core™ i9 processors/Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors |
| L3 cache varies with CPU |
|
| (Please refer "CPU Support List" for more information.) |
|
Chipset
|
|
| 1. Intel® H510 Express Chipset |
|
Memory
|
|
| 1. 11th Generation Intel® Core™ i9/i7/i5 processors: |
| Support for DDR4 3200/3000/2933/2666/2400/2133 MT/s memory modules |
| 2. 10th Generation Intel® Core™ i9/i7 processors: |
| Support for DDR4 2933/2666/2400/2133 MT/s memory modules |
| 3. 10th Generation Intel® Core™ i5/i3/Pentium®/Celeron® processors: |
| Support for DDR4 2666/2400/2133 MT/s memory modules |
| 4. 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory |
| 5. Dual channel memory architecture |
| 6. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) |
| 7. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
| 8. Support for Extreme Memory Profile (XMP) memory modules |
| (Please refer "Memory Support List" for more information.) |
|
Onboard Graphics
|
|
Integrated Graphics Processor-Intel® HD Graphics support:
|
| 1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz |
| * Support for HDMI 1.4 version and HDCP 2.3. |
| (Graphics specifications may vary depending on CPU support.) |
|
Audio
|
|
| 1. Realtek® Audio CODEC |
| 2. High Definition Audio |
| 3. 2/4/5.1/7.1-channel |
| * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
|
LAN
|
|
| 1. Realtek® GbE LAN chip (1 Gbps/100 Mbps) |
|
Expansion Slots
|
|
CPU:
|
| 1. 1 x PCI Express x16 slot: |
| Supporting PCIe 4.0 and running at x16 |
| (PCIe 4.0 is only supported by 11th Generation processors.) |
| Chipset: |
| 1. 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
|
Storage Interface
|
|
Chipset:
|
| 1. 1 x M.2 connector: |
| Socket 3, M key, type 2280 PCIe 3.0 x4/x2 SSD |
| 2. 2 x SATA 6Gb/s connectors |
|
USB
|
|
Chipset:
|
| 1. 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) |
| 2. 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header) |
|
Internal I/O Connectors
|
|
| 1. 1 x 24-pin ATX main power connector |
| 2. 1 x 8-pin ATX 12V power connector |
| 3. 1 x CPU fan header |
| 4. 1 x system fan header |
| 5. 1 x RGB LED strip header |
| 6. 1 x M.2 Socket 3 connector |
| 7. 2 x SATA 6Gb/s connectors |
| 8. 1 x front panel header |
| 9. 1 x front panel audio header |
| 10. 1 x USB 3.2 Gen 1 header |
| 11. 1 x USB 2.0/1.1 header |
| 12. 1 x serial port header |
| 13. 1 x Clear CMOS jumper |
|
Back Panel Connectors
|
|
| 1. 1 x HDMI port |
| 2. 2 x USB 3.2 Gen 1 ports |
| 3. 4 x USB 2.0/1.1 ports |
| 4. 1 x RJ-45 port |
| 5. 3 x audio jacks |
|
I/O Controller
|
|
| 1. iTE® I/O Controller Chip |
|
H/W Monitoring
|
|
| 1. Voltage detection |
| 2. Temperature detection |
| 3. Fan speed detection |
| 4. Fan fail warning |
| 5. Fan speed control |
| * Whether the fan speed control function is supported will depend on the cooler you install. |
|
BIOS
|
|
| 1. 1 x 128 Mbit flash |
| 2. Use of licensed AMI UEFI BIOS |
| 3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
Unique Features
|
|
| 1. Support for APP Center |
| * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. |
| @BIOS |
| Ambient LED |
| EasyTune |
| ON/OFF Charge |
| Smart Backup |
| System Information Viewer |
| 2. Support for Q-Flash |
| 3. Support for Xpress Install |
|
Bundled Software
|
|
| 1. Norton® Internet Security (OEM version) |
| 2. LAN bandwidth management software |
|
Operating System
|
|
| 1. Support for Windows 11 64-bit |
| 2. Support for Windows 10 64-bit |
|
Form Factor
|
|
| 1. Micro ATX Form Factor; 22.6cm x 18.5cm |
