Appearance |
Dimensions |
Single-sided: 80.0 mm x 22.0 mm x 2.23 mm (3.15" x 0.87" x 0.09") |
Double-sided: 80.0 mm x 22.0 mm x 3.58 mm (3.15" x 0.87" x 0.14") |
Type |
M.2 2280 |
Weight |
9 g (0.32 oz) |
Interface |
Bus Interface |
SATA III 6Gb/s |
Storage |
Flash Type |
3D NAND flash |
Capacity |
128 GB/ 256 GB/512 GB/1 TB/2 TB/4 TB
|
Operating Environment |
Operating Temperature |
0°C (32°F) ~ 70°C (158°F) |
Operating Voltage |
3.3V±5% |
Performance |
Sequential Read/Write (CrystalDiskMark) |
|
4 TB Up to 560/520 MB/s |
2 TB Up to 560/520 MB/s |
1 TB Up to 560/500 MB/s |
512 GB Up to 560/500 MB/s |
256 GB Up to 530/400 MB/s |
128 GB Up to 560/350 MB/s |
4K Random Read/Write (IOmeter) |
|
4 TB Up to 90,000/85,000 IOPS |
2 TB Up to 90,000/85,000 IOPS |
1 TB Up to 85,000/85,000 IOPS |
512 GB Up to 80,000/85,000 IOPS |
256 GB Up to 45,000/70,000 IOPS |
128 GB Up to 30,000/65,000 IOPS |
Terabytes Written (TBW) |
4 TB 2240 TBW |
2 TB 1120 TBW |
1 TB 560 TBW |
512 GB 280 TBW |
256 GB 140 TBW |
128 GB 70 TBW |
Mean Time Between Failures (MTBF) |
2,000,000 hour(s) |
Drive Writes Per Day (DWPD) |
0.3 (5 yrs) |
Note |
Speed may vary due to host hardware, software, usage, and storage capacity. |
The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity. |
Terabytes Written (TBW) expresses the endurance under the highest capacity. |
System Requirement |
Operating System |
Microsoft Windows 7 or later |
Linux Kernel 2.6.31 or later |
Note |
Please make sure that your computer has a M.2 slot. |
