| CPU |
|
|
AMD Socket AM5, support for: AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors |
|
(Please refer "CPU Support List" for more information.) |
| Chipset |
|
|
AMD B650 |
| Memory |
|
|
Support for DDR5 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MT/s memory modules |
|
4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory |
|
Dual channel memory architecture |
|
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules |
|
Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules |
|
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.) |
| Onboard Graphics |
|
| Integrated Graphics Processor: |
1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz |
|
Support for DisplayPort 1.4 version. |
|
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz |
|
Support for HDMI 2.1 version and HDCP 2.3. |
|
Support native HDMI 2.1 TMDS compatible ports. |
|
(Graphics specifications may vary depending on CPU support.) |
| Audio |
|
|
Realtek® Audio CODEC |
|
High Definition Audio |
|
2/4/5.1/7.1-channel |
|
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
| LAN |
|
|
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Expansion Slots |
|
|
1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: |
|
AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x16 mode |
|
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x8 mode |
|
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4 mode |
|
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. |
|
Chipset: |
|
1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 (PCIEX1) |
| Storage Interface |
|
|
1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2580/2280 SSDs: |
|
AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x4/x2 SSDs |
|
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs |
|
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x4/x2 SSDs |
|
1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs: |
|
AMD Ryzen™ 7000 Series Processors/ Ryzen™ 9000 Series Processors support PCIe 4.0 x4/x2 SSDs |
|
AMD Ryzen™ 8000 Series-Phoenix 1 Processors support PCIe 4.0 x4/x2 SSDs |
|
AMD Ryzen™ 8000 Series-Phoenix 2 Processors support PCIe 4.0 x2 SSDs |
|
4 x SATA 6Gb/s connectors |
|
RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices |
|
RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| USB |
|
|
CPU: |
|
1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support |
|
1 x USB 3.2 Gen 2 Type-A port (red) on the back panel |
|
2 x USB 2.0/1.1 ports on the back panel |
|
Chipset: |
|
1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header |
|
4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through the internal USB header) |
|
4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) |
| Internal I/O Connectors |
|
|
1 x 24-pin ATX main power connector |
|
1 x 8-pin ATX 12V power connector |
|
1 x CPU fan header |
|
2 x system fan headers |
|
1 x addressable LED strip header (D_LED1) |
|
1 x RGB LED strip header |
|
2 x M.2 Socket 3 connectors |
|
4 x SATA 6Gb/s connectors |
|
1 x front panel header |
|
1 x front panel audio header |
|
1 x USB Type-C® header, with USB 3.2 Gen 1 support |
|
1 x USB 3.2 Gen 1 header |
|
1 x USB 2.0/1.1 header |
|
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) |
|
1 x reset jumper |
|
1 x Clear CMOS jumper |
| Back Panel Connectors |
|
|
1 x DisplayPort |
|
1 x HDMI port |
|
4 x USB 2.0/1.1 ports |
|
1 x PS/2 keyboard/mouse port |
|
1 x USB 3.2 Gen 2 Type-A port (red) |
|
1 x USB Type-C® port, with USB 3.2 Gen 2 support |
|
1 x Q-Flash Plus button |
|
1 x RJ-45 port |
|
2 x USB 3.2 Gen 1 ports |
|
3 x audio jacks |
| I/O Controller |
iTE® I/O Controller Chip |
| H/W Monitoring |
|
|
Voltage detection |
|
Temperature detection |
|
Fan speed detection |
|
Water cooling flow rate detection |
|
Fan fail warning |
|
Fan speed control |
|
* Whether the fan speed control function is supported will depend on the cooler you install. |
| BIOS |
1 x 256 Mbit flash |
|
Use of licensed AMI UEFI BIOS |
|
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features |
|
|
Support for GIGABYTE Control Center (GCC) |
|
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. |
|
Support for Q-Flash |
|
Support for Q-Flash Plus |
| Bundled Software |
|
|
Norton® Internet Security (OEM version) |
|
LAN bandwidth management software |
| Operating System |
|
|
Support for Windows 11 64-bit |
|
Support for Windows 10 64-bit |
| Form Factor |
|
|
Micro ATX Form Factor; 24.4cm x 24.4cm |
