| SPECIFICATIONS |
| Display |
| Display Size (in.): 19
|
| Viewable Area (in.): 18.5
|
| Panel Type: TN Technology
|
| Resolution: 1366 x 768
|
| Resolution Type: WXGA (Wide XGA)
|
| Static Contrast Ratio: 600:1 (typ)
|
| Dynamic Contrast Ratio: 50M:1
|
| Light Source: LED
|
| Brightness: 200 cd/m² (typ)
|
| Colors: 16.7M
|
| Color Space Support: 8 bit (6 bit + FRC)
|
| Aspect Ratio: 16:9
|
| Response Time (Typical Tr+Tf): 5ms
|
| Viewing Angles: 90º horizontal, 65º vertical
|
| Backlight Life (Hours): 30000 Hrs (Min)
|
| Curvature: Flat
|
| Refresh Rate (Hz): 60
|
| Low Blue Light: Software solution
|
| Flicker-Free: Yes
|
| Color Gamut: NTSC: 72% size (Typ)
|
| sRGB: 102% size (Typ) |
| Pixel Size: 0.3 mm (H) x 0.3 mm (V)
|
| Surface Treatment: Anti-Glare, Hard Coating (3H)
|
| Compatibility |
| PC Resolution (max): 1366x768
|
| Mac® Resolution (max): 1366x768
|
| PC Operating System: Windows 10/11 certified; macOS tested
|
| Mac® Resolution (min): 1366x768
|
| Connector |
| VGA: 1
|
| 3.5mm Audio Out: 1
|
| HDMI 1.4: 1
|
| Power in: 3-pin Socket (IEC C14 / CEE22)
|
| Power |
| Eco Mode (Conserve): 9.5W
|
| Eco Mode (optimized): 12.5W
|
| Consumption (typical): 15.3W
|
| Consumption (max): 17W
|
| Voltage: AC 100-240V
|
| Stand-by: 0.5W
|
| Power Supply: Internal Power Supply
|
| Additional Hardware |
| Kensington Lock Slot: 1
|
| Controls |
| Physical Controls: Auto, Left, Right, Menu, Power
|
| On Screen Display: Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall
|
| Operating Conditions |
| Temperature: 32°F to 104°F (0°C to 40°C)
|
| Humidity (non-condensing): 20% to 90%
|
| Wall Mount |
| VESA Compatible: 75 x 75 mm
|
| Input Signal |
| Frequency Horizontal: RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 15 ~ 82KHz
|
| Frequency Vertical: RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 50 ~ 75Hz
|
| Video Input |
| Digital Sync: TMDS - HDMI (v1.4)
|
| Analog Sync: Separate - RGB Analog
|
| Ergonomics |
| Tilt (Forward/Back): -3º / 18º
|
| Weight (imperial) |
| Net (lbs): 4.6
|
| Net Without Stand (lbs): 4
|
| Gross (lbs): 6.6
|
| Weight (metric) |
| Net (kg): 2.1
|
| Net Without Stand (kg): 1.8
|
| Gross (kg): 3
|
| Dimensions (imperial) (wxhxd) |
| Packaging (in.): 19.8 x 13.7 x 4.1
|
| Physical (in.): 17.2 x 13.5 x 6.7
|
| Physical Without Stand (in.): 17.2 x 10.7 x 1.9
|
| Dimensions (metric) (wxhxd) |
| Packaging (mm): 502 x 349 x 105
|
| Physical (mm): 438 x 344 x 170
|
| Physical Without Stand (mm): 438 x 271 x 48
|
| General |
| Regulations: cTUVus, FCC-B, ICES003, CEC, IQC-ST, MX-CoC, Mexico Energy, CB, RoHS, WEEE, BSMI, RCM, GEMS, BIS
|
| PACKAGE CONTENTS: VA1903H-2 x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, Quick Start Guide x1
|
| Recycle/Disposal: Please dispose of in accordance with local, state or federal laws.
|
