LCD Panel Type
|
VA LCD
|
|
Backlight Type
|
W-LED system
|
|
Panel Size
|
23.8 inch / 60.5 cm
|
|
Display Screen Coating
|
Anti-Glare, 3H, Haze 25%
|
|
Effective Viewing Area
|
527.04 (H) x 296.46 (V)
|
|
Aspect Ratio
|
16:9
|
|
Maximum Resolution
|
1920 x 1080 @ 165 Hz*
|
|
Pixel Density
|
93 PPI
|
|
Response Time (Typical)
|
4 ms (Gray to Gray)*
|
|
MPRT
|
1 ms
|
|
Brightness
|
350 cd/m²
|
|
Contrast Ratio (Typical)
|
3500:1
|
|
SmartContrast
|
Mega Infinity DCR
|
|
Pixel Pitch
|
0.2745 x 0.2745 mm
|
|
Viewing Angle
|
178º (H) / 178º (V) @ C/R > 10
|
|
Flicker-Free
|
Yes
|
|
Picture Enhancement
|
SmartImage game
|
|
Color Gamut (Typical)
|
NTSC 96.1%, sRGB 125.9%
|
|
Display Colors
|
16.7 M
|
|
Scanning Frequency
|
HDMI: 30 - 160 kHz (H) / 48 - 144 Hz (V), DP: 30 - 200 kHz (H) / 48 - 165 Hz (V)
|
|
LowBlue Mode
|
Yes
|
|
EasyRead
|
Yes
|
|
sRGB
|
Yes
|
|
Adaptive Sync
|
Yes
|
|
Connectivity
|
|
|
Signal Input
|
HDMI (digital, HDCP), DisplayPort x 1
|
|
Sync Input
|
Separate Sync
|
|
Audio (In/Out)
|
Audio out
|
|
Convenience
|
|
|
Built-in Speakers
|
3 W x 2
|
|
User Convenience
|
Power On/Off, Menu, Volume, Input, SmartImage Game
|
|
OSD Languages
|
Multiple languages (e.g., English, French, German, Spanish, etc.)
|
|
Other Convenience
|
Kensington Lock, VESA Mount (100x100mm), Plug & Play Compatibility (DDC/CI, Mac OS X, Windows 10/8.1/8/7)
|
|
Stand
|
|
|
Height Adjustment
|
100 mm
|
|
Tilt
|
-5/20 degrees
|
|
Power
|
|
|
On Mode
|
13.92 W (typ.) (EnergyStar test method)
|
|
Standby Mode
|
0.5 W (typ.)
|
|
Off Mode
|
0.3 W (typ.)
|
|
Power LED Indicator
|
Operation - White, Standby Mode - White (blinking)
|
|
Power Supply
|
External, 100-240VAC, 50-60Hz
|
|
Dimensions
|
|
|
Product with Stand (Max Height)
|
540 x 498 x 187 mm
|
|
Product Without Stand (mm)
|
540 x 325 x 43 mm
|
|
Packaging in mm (WxHxD)
|
590 x 571 x 196 mm
|
|
Weight
|
|
|
Product with Stand (kg)
|
4.10 kg
|
|
Product Without Stand (kg)
|
2.54 kg
|
|
Product with Packaging (kg)
|
6.55 kg
|
|
Operating Conditions
|
|
|
Temperature Range (Operation)
|
0 to 40 °C
|
|
Temperature Range (Storage)
|
-20 to 60 °C
|
|
Relative Humidity
|
20%-80%
|
|
Altitude
|
Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)
|
|
MTBF
|
50,000 hrs (excluding backlight) hour(s)
|
|
Sustainability
|
|
|
Environmental and Energy
|
EnergyStar 8.0, RoHS, Mercury Free, Recyclable Packaging Material 100%
|
|
Compliance and Standards
|
Regulatory Approvals (e.g., UKRAINIAN, CB, TUV/GS, TUV Ergo, CU-EAC, EAEU RoHS, CE Mark, PSB)
|
|
Cabinet
|
Color: Black / Dark Chrome, Finish: Textured
|
